水平方向桶土相互作用土弹簧构建及优化研究

    Research on optimization of p-y spring model applied in bucket foundation-soil interaction along horizontal direction

    • 摘要: 桶形基础作为一种新型的海洋基础型式,已逐步推广应用于海上风电开发领域,其服役的稳定性能往往与桶形基础与海洋土之间的相互作用息息相关。为高效、准确地评价桶土相互作用行为,以传统应用于桩基稳定性评估的p-y弹簧法为基础,通过对比三维有限元模拟结果与API规范p-y曲线,引入p-因子和y-因子双修正参数,提出了可服务于评估水平向桶土相互作用不排水行为的修正p-y弹簧法。此外,基于可有效再现土体材料非线性的NGI-ADP模型,考虑土体剪切刚度系数Gmax/su,破坏剪应变\gamma _\textf^\textp等因素,对海洋常见的单层及分层黏土地质条件开展了系统化参数分析,研究发现y-因子受分层土影响显著,p-因子基本处于1.38~ 2.08。依托实际工程,进行了修正p-y弹簧法的应用分析,结果表明修正p-y弹簧法对实际工程场地条件具备良好适应性,最后针对部分土体工况,对多自由度下的桶土相互作用响应进行了研究。



      Abstract: As a new type of marine foundation, bucket foundation has been increasingly applied in the offshore wind turbine engineering. Its stable service performance is closely related to the interaction between bucket foundation and marine soil. In order to evaluate the undrained horizontal bucket foundation-soil interaction efficiently and accurately, a modified p-y spring method is proposed, based on the conventional p-y spring method for pile foundation. The three-dimensional finite element analyses are compared with the p-y curve recommended by API standard, and the p-factor and y-factor are introduced as double correction parameters. In addition, a parametric analysis is also carried out on common single-layer and layered clay geological conditions in the ocean, varying the soil shear stiffness coefficient Gmax/su, failure shear strain\gamma _\textf^\textpand other factors. The NGI-ADP soil model is used to effectively represent the nonlinearity property of soil. It is found that the y-factor can be significantly affected by multi-layer soil. The p-factor is generally within the range between 1.38 and 2.08. Furthermore, the modified p-y spring method has shown good adaptability to the actual project site conditions based on an application case study. And for some working conditions the application of the modified p-y spring method also extends to consider the bucket foundation-soil interaction under multiple degrees of freedom.



    /
