类岩石裂纹压剪流变断裂与亚临界扩展实验及破坏机制

赵延林, 万文, 王卫军, 赵伏军, 曹平

赵延林, 万文, 王卫军, 赵伏军, 曹平. 类岩石裂纹压剪流变断裂与亚临界扩展实验及破坏机制[J]. 岩土工程学报, 2012, 34(6): 1050-1059.
引用本文: 赵延林, 万文, 王卫军, 赵伏军, 曹平. 类岩石裂纹压剪流变断裂与亚临界扩展实验及破坏机制[J]. 岩土工程学报, 2012, 34(6): 1050-1059.
shu
ZHAO Yan-lin, WAN Wen, WANG Wei-jun, ZHAO Fu-jun, CAO P ing. Compressive-shear rheological fracture of rock-like cracks and subcritical crack propagation test and fracture mechanism[J]. Chinese Journal of Geotechnical Engineering, 2012, 34(6): 1050-1059.
Citation: ZHAO Yan-lin, WAN Wen, WANG Wei-jun, ZHAO Fu-jun, CAO P ing. Compressive-shear rheological fracture of rock-like cracks and subcritical crack propagation test and fracture mechanism[J]. Chinese Journal of Geotechnical Engineering, 2012, 34(6): 1050-1059.
shu

类岩石裂纹压剪流变断裂与亚临界扩展实验及破坏机制  English Version

  • 1.湖南科技大学能源与安全工程学院，湖南 湘潭 411201; 2. 湖南科技大学煤矿安全开采技术湖南省重点实验室，湖南 湘潭 411201; 3. 中南大学资源与安全工程学院，湖南 长沙 410083

基金项目: 国家自然科学基金项目(51174088, 51074071, 50974059)；湖南省自然科学基金项目(10JJ3007)；湖南省教育厅项目(11C0539)；湖南省高校科技创新团队支持计划项目；湖南省优秀博士学位论文获奖作者科研资助项目(YB2011B040)
详细信息
    作者简介:

    赵延林 (1973 – ),男，湖南湘潭人，博士，副教授，主要从事岩体流变断裂理论研究。

  • 中图分类号: TU452

Compressive-shear rheological fracture of rock-like cracks and subcritical crack propagation test and fracture mechanism

  • 1. School of Energy and Safty Enginerring, Hunan University of Science and Technology, Xiangtan 411201, China; 2. Hunan Provincial Key Laboratory of Safe Mining Techniques of Coal Mines, Hunan University of Science and Technology, Xiangtan 411201, China; 3. School of Resources and Safety Engineering, Central South University, Changsha 410083, China

摘要

    摘要
  • 摘要: 进行双轴压缩条件下类岩石裂纹的压剪流变断裂实验，采用双扭试件的常位移松弛法对类岩石材料进行亚临界裂纹扩展与断裂韧度试验。在实验室尺度上证实了类岩石裂纹流变断裂现象的存在，并且得到了翼形裂纹–翼形裂纹贯通、翼形裂纹–原生裂纹贯通和翼形裂纹–翼形裂纹–剪切裂纹贯通的 3 种流变断裂贯通模式。类岩石材料的流变断裂是一种稳定的裂纹扩展，其本质原因是类岩石裂纹的亚临界扩展。以黏弹性断裂力学、流变力学和能量准则为理论依据，推导以应力强度因子、翼形裂纹长度和时间为内变量的相应势函数，建立多种破坏机制的 压剪岩石裂纹的流变断裂 判据和计算模型。 利用 流变断裂 实验对计算模型进行验证，得出裂纹流变 贯通的 理论时间与实验时间较为吻合，当翼形裂纹的扩展方向与最大压应力方向偏离较大时实验结果与理论模型误差较大。提出的计算方法和理论判据为研究岩石裂纹的流变断裂的细观机理及岩体工程流变破坏的宏观机制提供了一个新而实用的研究手段。
    Abstract: Based on the experiments of creep fracture of rock-like cracks under compressive-shear load and biaxial compression, a subcritical propagation fracture toughness test on rock-like materials is made by using the constant displacement load relaxation method of double torsion specimens. The presence of creep fracture is confirmed on a laboratory-scale, and three creep fracture coalescence patterns are obtained: wing crack to wing crack, wing crack to primary crack, and wing crack to wing crack to shear crack. The creep fracture of rock-like materials is a stable crack growth essentially due to the subcritical propagation of rock-like cracks. Subcritical propagation occurs in rock-like cracks. Based on viscoelastic fracture mechanics, rheologic mechanics and energy principles, the corresponding potential functions are deduced in which inner variables are stress intensity factor, wing crack length and time. The creep fracture criterion and computational model for various damage effects and rock cracks under compressive-shear load are established. Using the experiments of creep fracture to verify these computational models, the theoretical time agrees with the experimental one of creep coalescence. The error between the experimental results and theoretical models will be larger when the propagation direction of wing crack is far away from the direction of the maximum pressure stress. The proposed method and theoretical criterion will provide a new and practical tool for studying the microscopic mechanism of creep fracture of rock cracks and the macro-mechanism of creep fracture in rock engineering.
    • HTML全文
    • 参考文献(21)
  • [1] KNAUSS W G. Delayed failure materials — the Griffith problem for linearly viscoelastic[J]. International Journal of Fracture Mechanics, 1970, 6 (1): 7 – 20.
    [2] CHRISTENSEN R M. A rate-dependent criterion for crack growth[J]. International Journal of Fracture, 1979, 15 (1): 3 – 21.
    [3] 袁龙蔚 . 论裂纹扩展过程中的流变与耗散现象 [J]. 力学进展 , 1989, 19 (1): 20 – 35. (YUAN Long-wei. On the rheological and dissipative phenomen in the process of crack propagation[J]. Advances in Mechanics, 1989, 19 (1): 20 – 35. (in Chinese))
    [4] KRANZ R L. Crack growth and development during creep of barre granite[J]. International Journal of Rock Mechanics and Mining Sciences, 1979, 16 (1): 23 – 35.
    [5] 陈有亮 , 孙 钧 . 岩石的流变断裂特性 [J] . 岩石力学与工程学报 , 1996, 15 (4): 323 – 327. ( CHEN You-liang, SUN Jun. Creep fracture of rock[J]. Chinese Journal of Rock Mechanics and Engineering, 1996, 15 (4): 323 – 327. (in Chinese))
    [6] 陈有亮 . 岩石蠕变断裂特性的试验研究 [J]. 力学学报 , 2003, 35 (4): 480 – 484. ( CHEN You-liang . The experimental study on creep fracture of rock[J]. Acta Mechanica Sinica , 2003, 35 (4): 480 – 484. (in Chinese))
    [7] 邓广哲 , 朱维申 . 蠕变裂隙扩展与岩石长时强度效应实验研究 [J]. 实验力学 , 2002, 14 (2): 177 – 183. (DENG Guang-zhe, ZHU Wei-shen. An experiment research on the crack propagation in rockmass[J]. Journal of Experimental Mechanics, 2002, 14 (2): 177 – 183. (in Chinese))
    [8] 杨延毅 . 裂隙岩体非线性流变性态与裂隙损伤扩展过程关系研究 [J]. 工程力学 , 1994, 11 (2): 81 – 90. (YANG Yan-yi. The underlying relationship between nonlinear rheological property of fissured rocks and damage development[J]. Engineering Mechanics, 1994, 11 (2): 81 – 90. (in Chinese))
    [9] 陈卫忠 , 朱维申 . 节理岩体断裂损伤耦合的流变模型及其应用 [J]. 水 利 学报 , 1999(12): 33 – 37. ( CHEN Wei-zhong, ZHU Wei-shen, et al. Rheology and fracture damage-coupled model for rock mass[J]. Journal of Hydraulic Engineering, 1999(12): 33 – 37. (in Chinese))
    [10] 赵延林 , 曹 平 , 林 杭 , 等 . 渗透压作用下压剪岩石裂纹流变断裂贯通机制及破坏准则探讨 [J]. 岩土工程学报 , 2008, 30. (ZHAO Yan-lin, CAO Ping, LIN Hang, et al. Study on fracture mechanism and rheologic fracture failure criterion of compressive-shear rock cracs under saturated pressure[J]. Chinese Journal of Geotechnical Engineering, 2008, 30. (in Chinese))
    [11] LI Jiang-teng, CAO Ping, YUAN Hai-ping. Testing study of subcritical crack growth velocity and fracture toughness of marble[J]. Journal of Coal Science & Engineering (China), 2005, 11 (1): 23 – 25.
    [12] SHETTY D K, VIRKAR A V. Determination of the useful range of crack length in double torsion specimens[J]. Journal of the American Ceramic Society, 1978, 61 (1): 93 – 94.
    [13] EBRAHIMI M E, CHEVALIER J, FANTOZZI G. Slow crack growth behavior of alumina ceramics[J]. J Master Res, 2000, 15 (1): 142 – 147.
    [14] KEMMENY J M. A model for non-linear rock deformation under compression due to sub-critical crack growth[J]. International Journal of Rock Mechanics and Mining Sciences and Geomechanics Abstracts, 1991, 28 (6): 459 – 467.
    [15] 赵延林 , 曹 平 , 文有道 , 等 . 岩石弹黏塑性流变实验和非线性流变模型研究 [J]. 岩石力学与工程学报 , 2008, 27 (3): 477 – 487. (ZHAO Yan-lin, CAO Ping, WEN You-dao, et al. Elastovisco-plastic rheological experiment and nonlinear rheological model of rocks[J]. Chinese Journal of Rock Mechanics and Engineering, 2008, 27 (3): 477 – 487. (in Chinese))
    [16] ZHAO Yan-lin, CAO Ping, WANG Wen-jun, et al. Viscoelasto-Plastic rheological experiment under circular increment step load and unload and nonlinear creep model of soft rocks[J]. Journal of Central South University of Technology, 2009, 16 (3): 484 – 491.
    [17] 赵延林 , 张 英 , 万 文 . 层状盐岩力学特性及蠕变破坏模型 [J]. 矿业工程研究 , 2010, 25 (1): 16 – 20. (ZHAO Yan-lin, ZHANG Ying, WAN Wen. Mechanical properties of bedded rock salt and creep failure model[J]. Mineral Engineering Research, 2010, 25 (1): 16 – 20. (in Chinese) )
    [18] 衣永亮 , 曹 平 , 蒲成志 . 静载下预制裂隙类岩石材料断裂实验分析 [J]. 湖南科技大学学报 ( 自然科学版 ), 2010, 25 (1): 67 – 71. (YI Yong-liang, CAO Ping, PU Cheng-zhi. Fracture experiment and analysis of rock-like material with prefabricated-fissures under static loading[J]. Journal of Huanan University of Science & Technology (Natural Science Edition), 2010, 25 (1): 67 – 71. (in Chinese))
    [19] 孙小康 , 朱单慧 , 徐燕飞 . 分级加卸载条件下岩石的弹塑性流变特性 [J]. 矿业工程研究 , 2011, 26 (4): 1 – 5. (SUN Xiao-kang, ZHU Zhuo-hui, XU Fan-fei. Elasto-plastic rheology properties of rock under the conditions of step loading and unloading[J]. Mineral Engineering Research, 2011, 26 (4): 1 – 5. (in Chinese))
    [20] CICCOTTI M, GONZATO G, MULARGIA F. The double torsion loading configuration for fracture propagation: an improved methodology for the load-relaxation at constant displacement[J]. International Journal of Rock Mechanics and Mining Sciences, 2000, 37 (7): 1103 – 1113.
    [21] 叶洲元 , 周志华 , 马建军 , 等 . 大冶铁矿软岩巷道围岩松动圈的测试研究 [J]. 矿业工程研究 , 2009, 24 (1): 18 – 21. (YE Zhou-yuan, ZHOU Zhi-hua, MA Jian-jun, et al. Study of measuring the broken zone in soft rock roads in Daye Iron Mine[J]. Mineral Engineering Research, 2009, 24 (1): 18 – 21. (in Chinese) )
