基于速度脉冲地震动的边坡地震位移统一预测模型

宋健; 高广运

基于速度脉冲地震动的边坡地震位移统一预测模型 English Version

宋健^{1, 2},
高广运^{1, 2}

1. 同济大学地下建筑与工程系,上海 200092; 2. 同济大学岩土及地下工程教育部重点实验室,上海 200092

基金项目: 国家自然科学基金项目（41372271）

详细信息

作者简介:
宋健(1988- )，男，安徽滁州人，博士研究生，主要从事土动力学与岩土地震工程研究。E-mail: songjian1988@gmail.com。

中图分类号: TU457
计量
- 文章访问数: 352
- HTML全文浏览量: 1
- PDF下载量: 498
出版历程
- 收稿日期: 2013-04-24
- 发布日期: 2013-11-19

Empirical predictive model for seismic displacement of slopes under velocity pulse-like ground motions

SONG Jian^{1, 2},
GAO Guang-yun^{1, 2}

1. Department of Geotechnical Engineering, Tongji University, Shanghai 200092, China; 2. Key Laboratory of Geotechnical and Underground Engineering of Ministry of Education, Tongji University, Shanghai 200092, China

摘要

摘要: 采用基于小波变换的多向地震动速度脉冲特性鉴定方法,从NGA数据库及汶川地震动记录中提取出了196条速度脉冲地震动数据；基于Newmark非耦合滑动模型,考虑土体非线性特征。通过计算速度脉冲地震动作用下不同强度(k_y)及初始自振周期(T_s)边坡模型的地震位移,对比分析了边坡地震位移与速度脉冲地震动参数之间的相关性,并建立了适用于近断层速度脉冲地震动的边坡地震位移统一预测模型。结果表明：既有边坡地震位移预测模型低估了近断层速度脉冲地震动引起的位移值,而用于预测近断层非脉冲地震动引起的边坡地震位移离散较小；近断层速度脉冲地震动引起的边坡地震位移与其速度脉冲特性密切相关,地震位移与速度脉冲地震动参数(峰值速度PGV)相关性最好；采用1.5倍边坡自振周期对应的加速度反应谱(S_a(1.5T_s))和 PGV分别代表速度脉冲地震动的频谱成分及速度脉冲特征,能够综合反映速度脉冲地震动对边坡地震位移的影响；建立了基于边坡参数(k_y, T_s)和脉冲地震动参数(PGV, S_a(1.5T_s))的边坡地震位移预测模型,为考虑近断层地震动速度脉冲特性影响的边坡地震位移概率灾害分析提供了基础。
- 边坡 /
- 近断层地震动 /
- 速度脉冲 /
- 地震位移 /
- 预测模型
Abstract: Based on the procedure to identify the velocity pulse for multi-component ground motions, 196 ground motions from NGA database and Wenchuan Earthquake are selected as pulse-like ground motions. The newmark decoupled model considering the nonlinear properties of soils is used to calculate the seismic displacement of slopes with different parameters (k_y, T_s) subjected to near-fault pulse-like ground motions, and the efficiency of different pulse-like ground motion parameters for predicting the displacement is also investigated. A seismic displacement model for the slopes under near-fault pulse-like ground motions is developed. The results indicate that the existing empirical models for seismic displacement of slopes significantly underestimate the displacement value induced by near-fault pulse-like ground motions, while they can be used to predict the seismic displacement caused by near-fault non-pulse ground motions. A close relationship between the seismic displacement and the velocity pulse characteristics for the pulse-like ground motions is shown, and the peak ground velocity (PGV) is the most efficient parameter in terms of the seismic displacement. The spectral acceleration at a degrade period equals to 1.5T_s (S_a(1.5T_s)) and PGV can represent the frequency content and velocity pulse characteristics of the pulse-like ground motions, respectively. Thus, an empirical predictive model for seismic displacements is developed using the vector intensity measures of S_a(1.5T_s) and PGV, which can be used in probabilistic seismic hazard analysis for the seismic displacement including the effects of near-fault pulse-like characteristics.
- slope /
- near-fault ground motion /
- velocity pulse /
- seismic displacement /
- predictive model

HTML全文

参考文献(20)

[1]	NEWMARK N M. Effects of earthquakes on dams and embankments[J]. Géotechnique, 1965, 15(2): 139-160.
[2]	MAKDISI F I, SEED H B. Simplified procedure for estimation dam and embankment earthquake induced deformations[J]. Journal of the Geotechnical Engineering Division, ASCE, 1978, 104(GT7): 849-868.
[3]	RATHJE E M, BRAY J D. An examination of simplified earthquake induced displacement procedures for earth structures[J]. Canadian Geotechnical Journal, 1999, 36(1): 72-87.
[4]	RATHJE E M, BRAY J D. Nonlinear coupled seismic analysis of earth structure[J]. Journal of Geotechnical and Geoenvironmental Engineering, 2000, 126(11): 1002-1215.
[5]	李红军, 迟世春, 林皋. 基于黏着滑动耦合动力分析的 Newmark 滑块位移法[J]. 岩石力学与工程学报, 2007, 26(9): 1787-1793. (LI Hong-jun, CHI Shi-chun, LIN Gao. An improved Newmark sliding block method based on stick-slip coupled dynamic response[J]. Chinese Journal of Rock Mechanics and Engineering, 2007, 26(9): 1787-1793. (in Chinese))
[6]	AMBRASEYS N N, MENU J M. Earthquake-induced ground displacements[J]. Earthquake Engineering and Structural Dynamics, 1988, 16(7): 985-1006.
[7]	JIBSON R W. Regression models for estimating coseismic landslide displacement[J]. Engineering Geology, 2007, 91(2/3/4): 209-218.
[8]	SAYGILI G, RATHJE E M. Empirical predictive models for earthquake-induced sliding displacements of slopes[J]. Journal of Geotechnical and Geoenvironmental Engineering, 2008, 134(6): 790-803.
[9]	RATHJE E M, SAYGILI G. Probabilistic assessment of earthquake-induced sliding displacements of natural slopes[J]. Bulletin of the New Zealand Society for Earthquake Engineering, 2009, 42(1): 18-27.
[10]	徐光兴, 姚令侃, 李朝红, 等. 基于汶川地震强震动记录的边坡永久位移预测模型[J]. 岩土工程学报, 2012, 34(6): 1131-1136. (XU Guang-xing, YAO Ling-kan, LI Chao-hong, et al. Predictive models for permanent displacement of slopes based on recorded strong-motion data of Wenchuan Earthquake [J]. Chinese Journal of Geotechnical Engineering, 2012, 34(6): 1131-1136. (in Chinese))
[11]	BRAY J D, TRAVASAROU T. Simplified procedure for estimating earthquake-induced deviatoric slope displacements[J]. Journal of Geotechnical and Geoenvironmental Engineering, 2007, 133(4): 381-392.
[12]	KALKAN E, KUNNATH S K. Effects of fling step and forward directivity on seismic response of building[J]. Earthquake Spectra, 2006, 22(2): 367-390.
[13]	MALLAT S G. A wavelet tour of signal processing[M]. San Diego: Academic Press, 1999.
[14]	BAKER J W. Quantitative classification of near-fault ground motions using wavelet analysis[J]. Bulletin of the Seismological Society of America, 2007, 97(5): 1486-1501.
[15]	谢俊举, 温增平, 李小军, 等. 基于小波方法分析汶川地震近断层地震动的速度脉冲特性[J]. 地球物理学报, 2012, 55(6): 1963-1972. (XIE Jun-ju, WEN Zeng-ping, LI Xiao-jun, et al. Analysis of velocity pulses for near-fault strong motions from the Wenchuan earthquake based on wavelet method[J]. Chinese Journal of Geophysics, 2012, 55(6): 1963-1972. (in Chinese))
[16]	HOWARD J K, TRACY C A, BURNS R G. Comparing observed and predicted directivity in near-source ground motion[J]. Earthquake Spectra, 2005, 21(4): 1063-1092.
[17]	SHAHI S K, BAKER J W. An empirically calibrated framework for including the effects of near-fault directivity in probabilistic seismic hazard analysis[J]. Bulletin of the Seismological Society of America, 2011, 101(2): 742-755.
[18]	RATHJE E M, FARAJ F, RUSSELL S, et al. Empirical relationship for frequency content parameters of earthquake ground motions[J]. Earthquake Spectra, 2004, 20(1): 119-144.
[19]	KOTTKE A R, RATHJE E M. Technical manual for strata[R]. Berkeley: University of California, 2008.
[20]	DARENDELI M B, STOKOE K H. Development of a new family of normalized modulus reduction and material damping curves[R]. Austin: University of Texas, 2001.
