可液化场地框架式地铁车站结构振动台模型试验与数值模拟的对比分析

黄营; 陈国兴; 戚承志; 杜修力

可液化场地框架式地铁车站结构振动台模型试验与数值模拟的对比分析 English Version

黄营^{1, 2},
陈国兴^1,2,,
戚承志³,
杜修力⁴

1. 南京工业大学岩土工程研究所,江苏南京 210009; 2. 江苏省土木工程防震技术研究中心,江苏南京 210009; 3. 北京建筑大学土木与交通工程学院,北京 100044; 4. 北京工业大学建筑工程学院,北京 100022

基金项目: 国家自然科学基金重大研究计划集成项目（91215301）

详细信息

作者简介:
黄营(1986- )，男，山东济宁人，硕士研究生，主要从事地下结构抗震研究。E-mail: hying4189@163.com。

中图分类号: TU352；U311.4
计量
- 文章访问数: 0212
- HTML全文浏览量: 0
- PDF下载量: 0435
出版历程
- 收稿日期: 2013-06-23
- 发布日期: 2013-11-24

Comparative analysis between shaking table model test and numerical simulation of frame subway station structure in liquefiable ground

1. Institute of Geotechnical Engineering, Nanjing University of Technology, Nanjing 210009, China; 2. Civil Engineering ＆ Earthquake Disaster Prevention Center of Jiangsu Province, 210009 ,China; 3.School of Civil and Transportation Engineering,Beijing University of Civil Engineering and Architecture, Beijing 100044, China; 4.College of Architecture and Civil Engineering, Beijing University of Technology, Beijing, 100022, China

摘要

摘要: 根据可液化地基土-地铁车站结构动力相互作用大型振动台模型试验结果,以ABAQUS软件为平台,将地基土-地铁车站结构体系视为平面应变问题,采用动塑性损伤模型描述地铁车站结构混凝土的动力特性,采用修正的Davidenkov黏弹性动力本构模型和孔压应变模型分别描述土体的动力非线性特性和孔隙水压力的发展过程,建立地基土-地铁车站结构非线性动力相互作用有限元分析模型。对不同试验工况下地基土-地铁车站结构体系的地震反应进行数值模拟,分别与试验结果进行了对比分析。结果表明：模拟值与试验值基本一致,呈现出相似的规律性,相互验证了数值模拟结果和振动台试验结果的正确性。
- 可液化场地 /
- 地铁车站 /
- 振动台试验 /
- 数值模拟 /
- 有效应力法
Abstract: Based on the results of the large shaking table test on frame subway station structure in liquefiable ground, considering the influence of the soil-structure nonlinear dynamic interaction by 2D finite element method, the nonlinear dynamic interaction of soil-subway station is modeled by ABAQUS software. In the modeling, the dynamic plastic-damage model is used to simulate the dynamic characteristics of station concrete, the modified Devidenkov viscoelastic constitutive model is used to simulate the dynamic characteristics of soil, and the dynamic pore water pressure strain model is used to simulate the development of pore water pressure. The seismic response of soil and subway station system under different test conditions is analyzed by means of the numerical simulation method. And then, the simulated results and the shaking table test records are compared. The results show that the simulated results are basically identical with the shaking table test records. So that, the modeling results and the shaking table test results are proved to be correct.
- liquefiable ground /
- subway station structure /
- shaking table test /
- numerical simulation /
- effective stress method
