软土地铁盾构隧道环间接头可靠度评价方法

王慧; 黄宏伟

软土地铁盾构隧道环间接头可靠度评价方法 English Version

王慧^1,2,
黄宏伟^1,2

1. 同济大学地下建筑与工程系，上海 200092 ; 2. 同济大学岩土及地下工程教育部重点实验室，上海 200092

基金项目: 国家自然科学基金项目 (50879058)

详细信息

作者简介:
王慧 (1986 – ) ，男，硕士研究生，从事隧道及地下工程风险管理与评估、软土隧道纵向稳定性与长期沉降研究工作。

中图分类号: TU45
计量
- 文章访问数: 1189
- HTML全文浏览量: 1
- PDF下载量: 492
出版历程
- 收稿日期: 2011-04-26
- 发布日期: 2011-11-30

Reliability evaluation method for segment joints of metro shield tunnels in soft soils

WANG Hui^1,2,
HUANG Hong-wei^1,2

1. Department of Geotechnical Engineering, Tongji University, Shanghai 200092, China; 2. Key Laboratory of Geotechnical and Underground Engineering of Ministry of Education, Tongji University, Shanghai 200092, China

摘要

摘要: 运营中的软土地铁盾构隧道，受各种内外部因素影响，隧道产生较大的纵向不均匀沉降，进而产生不同程度的环间接头张开，防水性能恶化。利用 4 阶 B 样条插值曲线拟合沉降监测数据并计算纵向附加曲率，可准确反映不均匀沉降程度。综合考虑隧道纵向附加曲率半径、衬砌几何尺寸及沿隧道纵向抗压抗拉刚度比，同时考虑认识不确定性及随机不确定性，分不同显著性水平通过区间 Monte Carlo 抽样模拟计算环间接头的失效概率区间。对失效概率上界值用 4 级评判可直观反映运营隧道环间接头的性能状况，并将评价结果与现场巡检进行对照验证，两者一致性良好。表明该方法可为地铁隧道运营养护决策的制定提供依据。
- 软土地铁盾构隧道 /
- 环间接头 /
- 可靠度 /
- 蒙特卡罗
Abstract: When the metro is in operation, there are increasing longitudinal nonuniform settlements of shield tunnels due to various interior and exterior causes. Therefore, some expansion of shield tunnel segment joints develops in varying degree and the water resistance deteriorates. By using the 4th order B-spline interpolation curve to fit monitoring data and calculate additional longitudinal curvature, the degree of nonuniform settlements can be accurately reflected. Then considering the additional curvature radius, geometrical dimension of segment and longitudinal stiffness ratio, that means aleatory uncertainty and epistemic uncertainty are all considered, an interval Monte Carlo method at different levels of significance is developed to estimate the probability of shield tunnel segment joint failure. Grading the upper bound of the failure probability using four level assessments can directly reflect the operational performance of the segment joints. Inspection and evaluation results are compared and show good consistency. It is proved that the proposed method can provide guidance for the maintenance of shield tunnels in soft soils.
- shield driven tunnel in soft soil /
- segment joint /
- reliability /
- Monte Carlo method

HTML全文

参考文献(15)

[1]	胡志平 , 罗丽娟 . 管片衬砌结构可靠度分析的优化方法 [J]. 岩石力学与工程学报 . 2005, 24 (22): 4145 – 4150. (HU Zhi-ping ， LUO Li-juan. Study on reliability optimization of segments lining in shield tunnel[J]. Chinese Journal of Rock Mechanics and Engineering, 2005 , 24 (22): 4145 – 4150. (in Chinese))
[2]	李罡 . 软土公路运营盾构隧道纵向结构安全性态评估 [D]. 上海 : 同济大学 , 2009. (LI Gang. Safety behavior assessment of longitudinal structure of operated road shield tunnel[D]. Shanghai: Tongji University, 2010. (in Chinese))
[3]	金伟良 , 贡金鑫 , 赵国藩 . 结构可靠度理论 [M]. 北京 : 中国建筑工业出版社 , 2000. (JIN Wei-liang, GONG Jin-xin, ZHAO Guo-fan. Theory of structure reliability[M]. Beijing: China Architecture and Building Press, 2000. (in Chinese))
[4]	刘宁 . 可靠度随机有限元法及其工程应用 [M]. 北京 : 中国水利水电出版社 , 2001. ( LIU Ning . The reliability stochastic finite element method and engineering applications[M]. Beijing: China Water Power Press, 2001. ( in Chinese ) )
[5]	FARAVELLI. A response surface approach for reliability analysis[J]. Journal of Engineering Mechanics, 1989, 115 (12): 2763 – 2781.
[6]	ANG AH-S, TANG W H. Probability concepts in engineering planning and design[M]. New York: Wiley, 1975.
[7]	廖少明 . 圆形隧道纵向剪切传递效应研究 [D]. 上海 : 同济大学 , 2002. (LIAO Shao-ming. Research on the effect of longitudinal shear transfer on circular tunnel lining[D]. Shanghai: Tongji University , 2002. ( in Chinese))
[8]	朱合华 , 桥本正 , 杨林德 , 等 . 盾构隧道管片接头衬砌系统的两种受力设计模型 [J]. 工程力学 . 1996(A03): 395 – 399. (ZHU He-hua , HASHIMOTO, YANG Lin-de. Two design model for shield lining segments and Joint system[J]. Engineering Mechanics, 1996(A03) : 395 – 399. ( in Chinese))
[9]	小泉淳，村上博智，西野健三 . ツ－ルドトネルの軸方向特性のモデルイヒにつぃて [J]. 土木学会論文集 . 1988: 79 – 88. (KOIZUMI J, MURAKAMI H, NISHINO K. Study on the analytical model of shield tunnel in longitudinal direction[J]. Journal of Geotechnical Engineering, 1988: 79 – 88. (in Japanese))
[10]	志波由纪夫，川島一彦，大日方尚己，等 . 応答変位法にょるツ－ルドトンネルの耐震設計法 [J]. 土木技術資料 , 1986, 28 (5): 45 – 50. (SHIWA Y, KAWA SHIMA K, SHANG. Evaluation procedure for seismic stress developed in shield tunnels eismi deformation method[J]. Journal of Structure Mechanics and Earthquake Engineering, 1986, 28 (5): 45 – 50. (in Japanese))
[11]	樊振宇 . 软土盾构隧道衬砌结构计算方法及纵向变形分析 [D]. 上海 : 同济大学 , 2009. (FAN Zheng-yu. Calculation method and deformation analysis on the longitudinal settlement of shield tunnel[D]. Shanghai : Tongji University ， 2005. (in Chinese))
[12]	FAN Zheng-yu, ZHANG Dong-mei, HUANG Hong-wei. Safety analysis on longitudinal settlement and crack width of shield tunnel segments in operation period[C]// Progress in Safety Science and Technology. Beijing, 2008.
[13]	DBJ08 — 50 — 96 盾构法隧道防水技术规程 [S]. 1996. (DBJ08 — 50 — 96 Waterproof technical rules for shield-driven tunnel[S]. 1996. (in Chinese))
[14]	GB50157 — 92 地下铁道设计规范 [S]. 1993. (GB50157-92 Design code for subway[S]. 1993. (in Chinese))
[15]	GB50299 — 1999 地下铁道工程施工及验收规范 [S]. 1999. (GB50299 — 1999 Code for construction and acceptance of subway[S]. 1999. (in Chinese))
