灌浆岩石锚杆 拉拔变形和刚度的理论解析

许宏发; 王武; 江淼; 佟佺

灌浆岩石锚杆拉拔变形和刚度的理论解析 English Version

解放军理工大学工程兵工程学院，江苏南京 210007

基金项目: 国家重点基础研究发展计划项目(973 计划） (2009CB724608)

详细信息

作者简介:
许宏发 (1964 – ) ，男，江苏泰州人，教授，主要从事岩土工程方面的教学与研究工作。

中图分类号: TU47
计量
- 文章访问数: 1487
- HTML全文浏览量: 2
- PDF下载量: 873
出版历程
- 发布日期: 2011-10-14

Theoretical analysis of pullout deformation and stiffness of grouted rockbolts

Engineering Institute of Engineering Corps, PLA University of Science and Technology, Nanjing 210007, China

摘要

摘要: 岩石锚杆的变形计算是锚固工程设计中的一个关键因素。基于协调剪切变形段锚杆和岩体间剪切变形刚度的线性假定，不协调剪切变形段锚杆和岩体间剪应力沿杆长呈幂函数型分布的假定，通过荷载传递微分方程，对全灌浆锚杆和有自由端灌浆锚杆的拉拔变形和刚度进行了理论分析，推导出沿杆长剪应力分布函数、轴力分布函数和位移分布函数，进而可获得锚杆最大拉拔力和拉拔荷载–位移曲线。根据剪滞理论，由灌浆锚杆周围岩体单元应力平衡微分方程，推导出锚杆与岩体之间剪切弹性变形刚度的计算公式。与其它理论结果比较，表明本分析方法是合理的、可行的，对于灌浆锚杆变形、刚度及强度设计具有参考价值。
- 灌浆岩石锚杆 /
- 拉拔变形 /
- 拉拔刚度 /
- 拉拔荷载–位移曲线 /
- 剪滞理论
Abstract: The deformation calculation of rockbolts is one of key factors in anchor engineering design. In the segment of the shear deformation compatibility between the rockblots and the surrounding rockmass, the linear shear deformation stiffness is assumed. In the segment of the deformation incompatibility, the power function model of the shear stress distribution along the rockblots is presented. By means of the loading transfer differential equation, the pullout deformation and stiffness on the fully grouted and the grouted rockbolts with free end are analyzed. And the shear stress distribution function, the axial force distribution function and the displacement distribution function along the rockbolt are derived. Thus the maximum pullout force and pullout load-displacement curve on the grouted rockbolts can be obtained. Based on the shear-lag theory, from the equilibrium differential equation on an infinitesimal element of the rockmass around rockbolts, the calculation formulae for elastic deformation stiffness on the interface between the rockbolts and the rockmass are deduced. The comparison between the present results and other theoretical estimates shows that the proposed method is reasonable and feasible and has reference value for the design of deformation, stiffness and strength of grouted rockbolts.
- grouted rockbolt /
- pullout deformation /
- pullout stiffness /
- pullout load-displacement curve /
- shear-lag theory

HTML全文

参考文献(15)

[1]	FARMER I W. Stress distribution along a resin grouted rock anchor[J]. Int J Rock Mech Min Sci and Geomech Abstr, 1975, 12 : 347 – 351.
[2]	KILIC A, YASAR E, CELIK A G. Effect of grout properties on the pull-out load capacity of fully grouted rock bolt[J]. Tunnelling and Underground Space Technology, 2002, 17 : 355 – 362.
[3]	HYETT A J, BAWDEN W F, REICHERT R D. The effect of rock mass confinement on the bond strength of fully grouted cable bolts[J]. Int J Rock Mech Min Sci Geomech bstr, 1992, 29 : 503 – 524.
[4]	XU Hong-fa, WANG Fa-jun, CHENG Xue-xin. Pullout creep properties of grouted soil anchors[J]. Chinese Journal of Central South University of Technology (English Edit), 2006, 14 (S1): 474 – 477.
[5]	许宏发 , 卢红标 , 钱七虎 . 土层灌浆锚杆的蠕变损伤特性研究 [J]. 岩土工程学报 , 2002, 24 (1): 61 – 63. (XU Hong-fa, LU Hong-biao, QIAN Qi-hu. Creep damage effects of pulling grouting anchor in soil[J]. Chinese Journal of Geotechnical Engineering, 2002, 24 (1): 61 – 63. (in Chinese))
[6]	GURUNG N. 1-D analytical solution for extensible and inextensible soil/rock reinforcement in pull-out tests[J]. Geotextiles and Geomembranes, 2001, 19 : 195 – 212.
[7]	INDRARATNA B, KAISER P K. Design for grouted rock bolts based on the convergence control method[J]. Int J Rock Mech Min Sci Geomech Abstr, 1990, 27 : 269 – 281.
[8]	CAI Yue, ESAKI Tetsuro, JIANG Yu-jing. An analytical model to predict axial load in grouted rock bolt for soft rock tunneling[J]. Tunnelling and Underground Space Technology, 2004, 19 : 607 – 618.
[9]	LI C, STILLBORG B. Analytical models for rock bolts[J]. International Journal of Rock Mechanics and Mining Sciences, 1999, 36 : 1013 – 1029.
[10]	FARMER I W. Stress distribution along a resin grouted rock anchor[J]. Int J Rock Mech Min Sci and Geomech Abstr, 1975, 12 : 347 – 351.
[11]	STILLBORG B. Experimental investigation of steel cables for rock reinforcement in hard rock[D]. Sweden: Lulea University of Technology, 1984.
[12]	赵震英 , 曾亚武 . 岩锚吊车梁承载机理模型试验研究 [J]. 岩土工程学报 , 2002, 24 (2): 4 – 7. (ZHAO Zhen-ying, ZENG Ya-wu. Researches on load bearing mechanism of rock bolt crane girder with model tests[J]. Chinese Journal of Geotechnical Engineering, 2002, 24 (2): 4 – 7. (in Chinese))
[13]	MOOSAVI M, KHOSRAVI A, JAFARI A. A laboratory study of bond failure mechanism in deformed rock bolts using a modified Hoek cell[C]// Proceedings of the 2001 ISRM International Symposium—Second Asian Rock Mechanics Symposium (ISRM 2001-2nd ARMS), 2001: 239 – 42.
[14]	CAI Yue, ESAKIA Tetsuro, JIANG Yu-jing. A rock bolt and rock mass interaction model[J]. International Journal of Rock Mechanics & Mining Sciences, 2004, 41 : 1055 – 1067.
[15]	WINDSOR C R. Rock Reinforcement System[J]. Int J Rock Mech Min Sci, 1997, 34 (6): 919 – 951.
