钻孔回填料与直埋式应变传感光缆耦合性研究

张诚成; 施斌; 刘苏平; 顾凯; 张磊; 魏广庆

doi:10.11779/CJGE201811001

钻孔回填料与直埋式应变传感光缆耦合性研究 English Version

张诚成¹,
施斌^1, ,,
刘苏平¹,
顾凯¹,
张磊¹,
魏广庆²

1. 南京大学地球科学与工程学院,江苏南京 210023;
2. 苏州南智传感科技有限公司,江苏苏州 215123

基金项目: 国家重大科研仪器研制项目（41427801）; 国家自然科学基金重点项目（41230636）; 国家自然科学基金青年基金项目（41502274）; 江苏省研究生科研与实践创新计划项目（KYCX17_0031）; 国家留学基金项目（201706190165）

详细信息

作者简介:
张诚成(1990- ),男,江苏苏州人,博士研究生,主要从事工程地质和计算岩土力学研究。E-mail：cczhang@smail.nju.edu.cn。

通讯作者:
施斌，E-mail：shibin@nju.edu.cn

中图分类号: TU43
计量
- 文章访问数: 305
- HTML全文浏览量: 17
- PDF下载量: 197
出版历程
- 收稿日期: 2017-08-28
- 发布日期: 2018-11-24

Mechanical coupling between borehole backfill and fiber-optic strain-sensing cable

1. School of Earth Sciences and Engineering, Nanjing University, Nanjing 210023, China;
2. Suzhou NanZee Sensing Technology Co., Ltd., Suzhou 215123, China

摘要

摘要: 钻孔回填料与直埋式应变传感光缆之间的耦合性,是决定分布式光纤感测（DFOS）技术能否利用一个钻孔精细化监测钻孔地层剖面变形分布的关键。利用自主研制的可控围压光缆-土体相互作用特性试验装置,探究了0~1.6 MPa围压下传感光缆与松填砂土以及击实砂-黏混合土之间的耦合性。试验与理论分析结果表明：在拉拔状态下,光缆-土体界面呈现渐进性破坏特征;在低围压下,光缆轴向应变随拉拔位移的增大而增大,且不断向光缆尾部传递;在高围压下,应变的扩展与传递被限制在很小的范围内;理想弹-塑性拉拔模型可较好地描述光缆-土体界面的渐进性破坏特性。提出采用光缆-土体耦合系数ζ_c-s定量描述光缆与土体之间的耦合性,将10000 με下的ζ_c-s值作为评价长期监测条件下两者耦合性的指标,并根据0.5,0.75,0.9三个ζ_c-s值将两者的耦合性分为强、较强、较弱以及弱4类。一定围压下,光缆与土体具有强耦合性;对于松填砂土与击实砂-黏混合土,该临界围压值分别为0.55 MPa与0.17 MPa。以苏州盛泽地面沉降为例,分析了钻孔回填料与传感光缆之间的耦合性,结果表明：距地表约16 m深度以内两者具有较强耦合性;而约16 m深度以下两者具有强耦合性,传感光缆的应变数据可准确反映地层的变形。这一研究成果为DFOS技术应用于钻孔剖面地面沉降监测提供了坚实的理论依据。
- 地面沉降监测 /
- 钻孔回填料 /
- 传感光缆 /
- 围压 /
- 界面效应 /
- 分布式光纤感测技术
Abstract: The mechanical coupling between borehole backfill and fiber-optic strain-sensing cable is the key factor affecting distributed fiber-optic sensing (DFOS)-based land subsidence monitoring. A new pullout apparatus is designed to investigate the interaction mechanism between cable and soil under confining pressures (CPs) ranging from 0 to 1.6 MPa. The test results and analytical analyses show that the cable-soil interface fails progressively under pullout conditions. Under low CPs, the axial strain increases and propagates toward the cable toe under increasing pullout displacements. In contrast, the propagation of strain is restrained around the cable head under high CPs. The ideal elasto-plastic pullout model can reasonably describe the progressive failure behavior of the cable-soil interface. A new coefficient is proposed to characterize the cable-soil mechanical coupling for long-term monitoring purposes (the maximum axial strain of 10000με), together with a classification of the mechanical coupling based on this coefficient. The case of the Shengze land subsidence in Suzhou of China is presented to illustrate how these findings can be applied to the field. The analyses demonstrate the strong coupling of the cable to the borehole backfill below a depth of 16 m. It may provide a sound basis for monitoring land subsidence using the DFOS technique.
- land subsidence monitoring /
- borehole backfill /
- fiber-optic sensing cable /
- confining pressure /
- interfacial effect /
- distributed fiber-optic sensing technique

HTML全文

参考文献(15)

[1]	薛禹群, 张云, 叶淑君, 等. 中国地面沉降及其需要解决的几个问题[J]. 第四纪研究, 2003, 23(6): 585-593. (XUE Yu-qun, ZHANG Yun, YE Shu-jun, et al.Land subsidence in China and its problems[J]. Quaternary Sciences, 2003, 23(6): 585-593. (in Chinese))
[2]	AMELUNG F, GALLOWAY D L, BELL J W, et al.Sensing the ups and downs of Las Vegas: InSAR reveals structural control of land subsidence and aquifer-system deformation[J]. Geology, 1999, 27(6): 483-486.
[3]	叶淑君, 薛禹群, 张云, 等. 上海区域地面沉降模型中土层变形特征研究[J]. 岩土工程学报, 2005, 27(2): 140-147. (YE Shu-jun, XUE Yu-qun, ZHANG Yun, et al.Study on the deformation characteristics of soil layers in regional land subsidence model of Shanghai[J]. Chinese Journal of Geotechnical Engineering, 2005, 27(2): 140-147. (in Chinese))
[4]	刘杰, 施斌, 张丹, 等. 基于BOTDR的基坑变形分布式监测实验研究[J]. 岩土力学, 2006, 27(7): 1224-1229. (LIU Jie, SHI Bin, ZHANG Dan, et al.Experimental study of foundation pit monitoring using BOTDR-based on distributed optical fiber sensor[J]. Rock and Soil Mechanics, 2006, 27(7): 1224-1229. (in Chinese))
[5]	MOORE J R, GISCHIG V, BUTTON E, et al.Rockslide deformation monitoring with fiber optic strain sensors[J]. Natural Hazards & Earth System Sciences, 2010, 10(2): 191-201.
[6]	MOHAMAD H, SOGA K, BENNETT P J, et al.Monitoring twin tunnel interaction using distributed optical fiber strain measurements[J]. Journal of Geotechnical and Geoenvironmental Engineering, 2011, 138(8): 957-967.
[7]	WU J, JIANG H, SU J, et al.Application of distributed fiber optic sensing technique in land subsidence monitoring[J]. Journal of Civil Structural Health Monitoring, 2015, 5(5): 587-597.
[8]	GALLOWAY D, JONES D R, INGEBRITSEN S E.Land subsidence in the United States[M]. Denver: US Geological Survey Circular 1182, 1999.
[9]	ZHANG C C, ZHU H H, LIU S P, et al.A kinematic method for calculating shear displacements of landslides using distributed fiber optic strain measurements[J]. Engineering Geology, 2018, 234: 83-96.
[10]	管振德, 蒋小珍, 高明. 岩溶塌陷光纤传感试验装置的标定试验[J]. 中国岩溶, 2012, 31(2): 173-178. (GUAN Zhen-de, JIANG Xiao-zhen, GAO Ming.A calibration test on optical fiber sensing device for karst collapse monitoring[J]. Carsologica Sinica, 2012, 31(2): 173-178. (in Chinese))
[11]	ITEN M.Novel applications of distributed ﬁber-optic sensing in geotechnical engineering[D]. Zurich: Swiss Federal Institute of Technology in Zurich, 2011.
[12]	ZHANG C C, ZHU H H, SHI B, et al.Interfacial characterization of soil-embedded optical fiber for ground deformation measurement[J]. Smart Materials and Structures, 2014, 23(9): 095022.
[13]	佘骏宽, 朱鸿鹄, 张诚成, 等. 传感光纤-砂土界面力学性质的试验研究[J]. 工程地质学报, 2014, 22(5): 855-860. (SHE Jun-kuan, ZHU Hong-hu, ZHANG Cheng-cheng, et al.Experiment study on mechanical properties of interface between sensing optical fiber and sand[J]. Journal of Engineering Geology, 2014, 22(5): 855-860. (in Chinese))
[14]	ZHANG C C, ZHU H H, SHI B.Role of the interface between distributed fibre optic strain sensor and soil in ground deformation measurement[J]. Scientific Reports, 2016, 6: 36469.
[15]	DAS B M.Principles of geotechnical engineering[M]. 7 ed. Stamford: Cengage Learning, 2010.
