砂岩裂纹起裂损伤强度及脆性参数演化试验研究

刘泉声; 魏莱; 雷峰; 刘琪; 彭星新; 刘鹤

doi:10.11779/CJGE201810004

砂岩裂纹起裂损伤强度及脆性参数演化试验研究 English Version

刘泉声^1,2,
魏莱^1,3,
雷峰^1,3,
刘琪²,
彭星新^1,3,
刘鹤^1,3

1. 中国科学院武汉岩土力学研究所岩石力学与工程国家重点实验室,湖北武汉 430071;
2. 武汉大学岩土与结构工程安全湖北省重点实验室,湖北武汉 430072;
3. 中国科学院大学,北京 100049

基金项目: 国家重点基础研究发展计划（“973”计划）项目（2014CB046904,2015CB058102）; 国家自然科学基金青年基金项目（41602324）

详细信息

作者简介:
刘泉声(1962- ),男,博士,1983年毕业于山东矿业学院矿山建设专业,现任研究员、博士生导师,主要从事岩土工程方面的教学与研究工作。E-mail：liuqs@whrsm.ac.cn。

中图分类号: TU45
计量
- 文章访问数: 0281
- HTML全文浏览量: 0
- PDF下载量: 0278
出版历程
- 收稿日期: 2017-08-04
- 发布日期: 2018-10-24

Experimental study on damage strength of crack initiation and evaluation of brittle parameters of sandstone

1. State Key Laboratory of Geomechanics and Geotechnical Engineering, Institute of Rock and Soil Mechanics, Chinese Academy of Sciences, Wuhan 430071, China;
2. Key Laboratory of Safety for Geotechnical and Structural Engineering of Hubei Province, Wuhan University, Wuhan 430072, China;
3. Graduate University of Chinese Academy of Sciences, Beijing 100049, China

摘要

摘要: 岩石起裂强度σ_ci及损伤强度σ_cd作为岩石重要的强度特征值,其研究对于分析岩石的渐进破坏过程及预测隧洞脆性破坏有着重要意义。首先采用应变分析及声发射监测方法,研究了两组硬质砂岩试样在单轴及三轴压缩过程中的裂纹演化特征。试验结果表明,试样的侧向膨胀变形及声发射计数值可以较好地反映其内部的裂纹演化情况,二者随着裂纹的萌生积累都表现出一致的阶段性变化规律。同时通过进一步分析应变及声发射曲线中的阶段性变化拐点,确定了砂岩试样的起裂强度及损伤强度值。其中青砂岩平均起裂强度约为其峰值强度的0.42倍,红砂岩平均起裂强度则约为其峰值强度的0.48倍。最后通过对比不同围压下的试验结果,发现两组砂岩试样起裂阶段内摩擦角均小于其峰值阶段,初始φ₀约为终值的1/2。由此定义了可反映岩石脆性程度的起裂摩擦水平φ₀/φ,并建立考虑摩擦作用的线性起裂准则。
- 岩石力学 /
- 裂纹演化 /
- 裂纹起裂 /
- 脆性参数 /
- 声发射
Abstract: The strengths of crack initiation and damage are the important stress thresholds for their significance in analyzing the progressive failure process of rock, which can be applied in the prediction of brittle failure in tunnels. Firstly, the uniaxial and triaxial compression tests are conducted on two sets of hard sandstones, while their strain and acoustic emission (AE) characteristics are analyzed to study the evolution process of crack. The measured lateral dilation strains and the AE counts of rock samples can characterize their crack accumulation accurately according to the test results. And also, there is a consistent segmented transformation law in these two figures as the inner micro-cracks are accumulated. Thus the strengths of crack initiation and damage of the sandstone samples can be determined based on a detailed analysis on stage boundaries of the above curves. The average strength of crack initiation of green sandstone samples is 0.42 of its peak strength, while that of red sandstone samples is 0.48 of its peak strength. Furthermore the confinement influence on evolution process of crack is discussed by comparing different test results under varying confinements. It is found that the initial internal friction angle (φ₀) of sandstone samples at the crack initiation stage is less than its ultimate value (φ) when the peak load is applied. And the calculated initial φ₀ is about 1/2 of the ultimate φ. As a result, the initial internal friction level φ₀/φ of rock is defined, which has an inverse relation with the ratio of uniaxial compressive strength to tensile strength σ_c /σ_t , and it can also reflect the brittleness of rock. And the linear strength threshold of crack initiation is established, while the slope of curve represents the influence of friction effects.
- rock mechanics /
- crack evaluation /
- crack initiation /
- brittle parameter /
- acoustic emission

HTML全文

参考文献(22)

[1]	MARTIN C D.The strength of massive Lac Du Bonnet granite around underground openings[D]. Manitoba, Canada: University of Manitoba, 1993.
[2]	MARTIN C D, CHRISTIANSSON R.Estimating the potential for spalling around a deep nuclear waste repository in crystalline rock[J]. International Journal of Rock Mechanics & Mining Sciences, 2009, 46(2): 219-228.
[3]	DIEDERICHS M S, KAISER P K, EBERHARDT E.Damage initiation and propagation in hard rock during tunnelling and the influence of near-face stress rotation[J]. International Journal of Rock Mechanics & Mining Sciences, 2004, 41(5): 785-812.
[4]	侯文诗, 李守定, 李晓, 等. 岩石扩容起始特性与峰值特性的比较[J]. 岩土工程学报, 2013, 35(8): 1478-1485. (HOU Wen-shi, LI Shou-ding, LI Xiao, et al.Comparison between dilatancy onset and peak of different rocks[J]. Chinese Journal of Geotechnical Engineering, 2013, 35(8): 1478-1485. (in Chinese))
[5]	NICKSIAR M, MARTIN C D.Evaluation of methods for determining crack initiation in compression tests on low-porosity rocks[J]. Rock Mechanics & Rock Engineering, 2012, 45(4): 607-617.
[6]	周辉, 孟凡震, 卢景景, 等. 硬岩裂纹起裂强度和损伤强度取值方法探讨[J]. 岩土力学, 2014, 35(4): 913-920. (ZHOU Hui, MENG Fan-zhen, LU Jing-jing.Discussion on methods for calculating crack initiation strength and crack damage strength for hard rock[J]. Rock and Soil Mechanics, 2014, 35(4): 913-920. (in Chinese))
[7]	刘泉声, 胡云华, 刘滨. 基于试验的花岗岩渐进破坏本构模型研究[J]. 岩土力学, 2009, 30(2): 289-296. (LIU Quan-sheng, HU Yun-hua, LIU Bing.Progressive damage constitutive models of granite based on experimental results[J]. Rock and Soil Mechanics, 2009, 30(2): 289-296. (in Chinese))
[8]	刘宁, 张春生, 褚卫江. 锦屏深埋大理岩破裂特征与损伤演化规律[J]. 岩石力学与工程学报, 2012, 31(8): 1606-1613. (LIU Ning, ZHANG Chun-sheng, CHU Wei-jiang.Fracture characteristics and damage evolution law of Jinping deep marble[J]. Chinese Journal of Rock Mechanics and Engineering, 2012, 31(8): 1606-1613. (in Chinese))
[9]	彭俊, 荣冠, 周创兵, 等. 水压影响岩石渐进破裂过程的试验研究[J]. 岩土力学, 2013, 34(4): 941-954. (PENG Jun, RONG Guan, ZHOU Chuang-bing, et al.Experimental study of effect of water pressure on progressive failure process of rocks under compression[J]. Rock and Soil Mechanics, 2013, 34(4): 941-954. (in Chinese))
[10]	HAJIABDOLMAJID V, KAISER P K, MARTIN C D.Modelling brittle failure of rock[J]. International Journal of Rock Mechanics & Mining Sciences, 2002, 39(6): 731-741.
[11]	卢兴利, 刘泉声, 苏培芳. 考虑扩容碎胀特性的岩石本构模型研究与验证[J]. 岩石力学与工程学报, 2013, 32(9): 1886-1893. (LU Xing-li, LIU Quan-sheng, SU Pei-fang.Constitutive model of rocks considering dilatancy-bulking behaviour and its calibration[J]. Chinese Journal of Rock Mechanics and Engineering, 2013, 32(9): 1886-1893. (in Chinese))
[12]	BRACE W F, PAULDING B W, SCHOLZ C.Dilatancy in the fracture of crystalline rocks[J]. Journal of Geophysical Research, 1966, 71(16): 3939-3953.
[13]	李浩然, 杨春和, 刘玉刚, 等. 花岗岩破裂过程中声波与声发射变化特征试验研究[J]. 岩土工程学报, 2014, 36(10): 1915-1923. (LI Hao-ran, YANG Chun-he, LIU Yu-gang, et al.Experimental research on ultrasonic velocity and acoustic emission properties of granite under failure process[J]. Chinese Journal of Geotechnical Engineering, 2014, 36(10): 1915-1923. (in Chinese))
[14]	朱泽奇, 盛谦, 冷先伦, 等. 三峡花岗岩起裂机制研究[J]. 岩石力学与工程学报, 2007, 26(12): 2570-2575. (ZHU Ze-qi, SHENG Qian, LENG Xian-lun, et al.Research on relationship between crack initiation stress level and brittleness indices for brittle rocks[J]. Chinese Journal of Rock Mechanics and Engineering, 2007, 26(12): 2570-2575. (in Chinese))
[15]	CAI M, KAISER P K, TASAKA Y, et al.Generalized crack initiation and crack damage stress thresholds of brittle rock masses near underground excavations[J]. International Journal of Rock Mechanics & Mining Sciences, 2004, 41(5): 833-847.
[16]	HOEK E, BIENIAWSKI Z T.Brittle fracture propagation in rock under compression[J]. International Journal of Fracture, 1965, 1(3): 137-155.
[17]	黄书岭. 高应力下脆性岩石的力学模型与工程应用研究[D]. 武汉: 中国科学院武汉岩土力学研究所, 2008. (HUANG Shu-ling.Study on mechanical model of brittle rock under high stress condition and its engineering applications[D]. Wuhan: Institute of Rock and Soil Mechanics, Chinese Academy of Sciences, 2008. (in Chinese))
[18]	CAI M.Practical estimates of tensile strength and Hoek-Brown strength parameter m_i, of brittle rocks[J]. Rock Mechanics and Rock Engineering, 2010, 43(2): 167-184.
[19]	PESTMAN B J, MUNSTER J G V. An acoustic emission study of damage development and stress-memory effects in sandstone[J]. International Journal of Rock Mechanics & Mining Sciences & Geomechanics Abstracts, 1996, 33(6): 585-593.
[20]	LAU JSO, GORSKI B.Uniaxial and triaxial compression tests on URL rock samples from boreholes 207-045-GC3 and 209-069-PH3[M]. Mining Research Laboratories, 1992.
[21]	ZHAO X G, CAI M, WANG J, et al.Damage stress and acoustic emission characteristics of the Beishan granite[J]. International Journal of Rock Mechanics and Mining Sciences, 2013, 64: 258-269.
[22]	LI C, NORDLUND E.Experimental verification of the Kaiser effect in rocks[J]. Rock Mechanics and Rock Engineering, 1993, 26(4): 333-351.
