Experimental study on drying-wetting properties of carbonated reactive MgO-stabilized soils
-
摘要: 碳化固化技术是一种利用二氧化碳对搅拌有活性氧化镁的土体进行碳化,以达到快速提高强度的低碳搅拌处理软土的创新技术。通过室内试验研究干湿循环对碳化固化土物理力学特性的影响,并与相同掺量下水泥固化土进行对比。结果表明：活性MgO固化粉土碳化3 h试样的无侧限抗压强度可达5 MPa,粉质黏土碳化24 h试样可达2.6 MPa;干湿循环后碳化固化土的干密度降低,而水泥土干密度基本不变;6次干湿循环后粉土碳化试样的无侧限抗压强度仍然能达到4 MPa以上,为水泥固化粉土强度的2倍,具有较好的抗干湿循环性能;经过6次干湿循环后,粉质黏土碳化试样的残余强度仅为35%,而水泥固化粉质黏土降到65%,表明固化粉质黏土的抗干湿循环性能均较差,且粉质黏土碳化试样的抗干湿循环能力不及水泥固化粉质黏土试样。通过X射线衍射（XRD）、电镜扫描（SEM）及压汞试验（MIP）测试表明干湿循环对粉土碳化试样的累计孔隙影响不大,因此粉土试样仍然具有比较大的密实度来保证试样强度;粉质黏土碳化试样因孔隙增加明显而变得疏松,因此强度显著降低。Abstract: The carbonated curing technology is an innovative ground improvement method, in which the reactive magnesia (MgO) is firstly mixed with the soft soils and then carbon dioxide is injected for carbonation in short time. Laboratory tests are performed to investigate the physical and mechanical properties of carbonated reactive MgO-stabilized soils under drying-wetting cycles. The test results are compared with those of cemented soils. It is shown that the maximum unconfined compressive strength of MgO-stabilized silts can reach 5 MPa after 3 hours carbonation, and that of MgO-stabilized silty clay can only reach 2.6 MPa after 24 hours carbonation. The dry density of carbonated MgO-stabilized soils decreases after drying-wetting cycles, while that of cemented soils has significant variation. Silt samples have better performance after drying-wetting cycles, and the maximum unconfined compressive strength of carbonated silt samples is still able to reach 4 MPa after 6 drying-wetting cycles which is twice that of cemented silts. However, the residual compressive strength of the carbonated silty clay is only 35% after 6 cycles, and it is consistently about 65% for the cemented silty clay, therefore the resistance to drying-wetting cyclic performance is worse than that of silt samples, and the resistance to drying-wetting cyclic performance of carbonated silty clay is worse than cemented silty clay. XRD, SEM and MIP tests reveal that the cumulative volume of pore void of carbonated silt is essentially constant. Thus the carbonated silt samples can still show relatively high strength in the unconfined compressive tests. Whereas, the void ratio of carbonated silty clay increases after cyclic drying-wetting tests and further reduces the density, which is responsible for the significant strength reduction.
-
Keywords:
- soil stabilization /
- carbonation /
- drying-wetting cycle /
- cemented soil
-
[1] 刘松玉, 钱国超, 章定文. 粉喷桩复合地基理论与工程应用[M]. 北京: 中国建筑工业出版社, 2006: 18-21. (LIU Song-yu, QIAN Guo-chao, ZHANG Ding-wen. The principle and application of dry jet mixing composite foundation[M]. Beijing: China Architecture and Building Press, 2006: 18-21. (in Chinese)) [2] 王定才. 粉磨-搅拌一体化：中国商品混凝土产业的发展策略[J]. 混凝土, 2003(2): 20-23. (WANG Ding-cai. Grinding-stirring integration: The development strategy of China's commercial concrete industry[J]. Concrete, 2003(2): 20-23. (in Chinese)) [3] 寇 新, 李金峰. 煤炭是我国能源节约的重点[J]. 煤炭经济研究, 2004(8): 12-13. (KOU Xin, LI Jin-fen. Coal is the focus of China's energy conservation[J]. Coal Economic Research, 2004(8): 12-13. (in Chinese)) [4] 李涛平. 中国水泥工业能效现状和节能潜力报告[J]. 水泥工程, 2004(4): 1-10. (LI Tao-ping. China's cement industry energy efficiency and energy saving potential Situation Report[J]. Cement Engineering, 2004(4): 1-10. (in Chinese)) [5] Intergovernmental Panel on Climate Change. Sources of CO2 [C]// IPCC Special Report on Carbon Dioxide Capture and Storage, IPCC. Switzerland, 2004: 77-103. [6] World Business Council for Sustainable Development. The Cement Sustainability Initiative-Our Agenda for Action[C]// WBCSD, Conches-Geneva. Switzerland, 2002. [7] YI Y L, LISKA M, UNLUER C, et al. Carbonating magnesia for soil stabilisation[J]. Canadian Geotechnical Journal, 2013, 50: 899-905. [8] CAI G H, LIU S Y, DU Y J, et al. Strength and deformation characteristics of carbonated reactive magnesia treated silt soil[J]. Journal of Central South University, 2015, 22(5): 1859-1868. [9] CAI G H, DU Y J, LIU S Y, et al. Physical properties, electrical resistivity and strength characteristics of carbonated silty soil admixed with reactive magnesia[J]. Canadian Geotechnical Journal, 2015: 52(11): 1699-1713. [10] 易耀林, MARTIN Liska, ABIR Al-Tabbaa, 等. 一种土壤的碳化固化方法及其装置[P]. 中国, 201010604013.1, 2010. (YI Yao-lin, LISKA M, AL-TABBAA A, et al. A kind of soil carbonation curing method and device: China, 201010604013.1[P]. 2010. (in Chinese)) [11] 易耀林, Martin Liska, Abir Al-Tabbaa, 等. 一种用于土体固化的绿色低碳固化剂[P]. 中国发明专利, 201010604325.2, 2010. (YI Yao-lin, LISKA M, AL-TABBAA A, et al. A kind of low-carbon curing agent used for soil stabilization: China, 201010604325.2[P]. 2010. (in Chinese)) [12] 易耀林. 基于可持续发展的搅拌桩新技术与理论[D]. 南京: 东南大学, 2013. (YI Yao-lin. Sustainable novel deep mixing methods and theory[D]. Nanjing: Southeast University, 2013. (in Chinese)) [13] 李 晨. 氧化镁活性对碳化搅拌桩加固效果影响研究[D].南京: 东南大学, 2014. (LI Chen. Influence of MgO activity on the stabilization efficiency of carbonated mixing method[D]. Nanjing: Southeast University, 2014. (in Chinese)) [14] American Society for Testing and Materials (ASTM). Standard test method for wetting and drying test of solid wastes[S]. US: ASTM International, 2009 [15] ESTABRAGH A R, PERESHKAFTIB M R S, PARSAEIC B, et al. Stabilised expansive soil behavior during wetting and drying[J]. International Journal of Pavement Engineering, 2013, 14(4): 418-427. [16] AHMED A, UGAI K. Environmental effects on durability of soil stabilized with recycled gypsum[J]. Cold Regions Science and Technology, 2011, 66: 84-92. [17] UNLUER C, Al-Tabbaa A. Enhancing the carbonation of MgO cement porous blocks through improved curing conditions[J]. Cement and Concrete Research, 2014(59): 55-65. -
