Method for calculating loosening earth pressure during construction of shield tunnels
-
摘要: 在盾构隧道施工中,因管片支护和注浆填充,隧道拱顶土体位移受限制,土拱效应不完全发挥,土体剪应力小于其抗剪强度,使得Terzaghi松动土压力理论不适用于盾构隧道。针对这一情况,在Handy理论基础上推导了土的侧压力系数计算公式,得出侧压力系数的变化规律,其值与主应力旋转角度相关,其大小在主动土压力系数和被动土压力系数之间变化;并认为土拱效应的发挥和隧道拱顶位移相关,据此,在Terzaghi松动土压力理论基础上推导了一种可以考虑地层损失和管片刚度的松动土压力计算公式;并通过对土拱高度的讨论,提出一种简化的隧道施工扰动范围判断方法。Abstract: Due to the limitations on vault displacement, such as lining segment support and synchronous grouting, the soil arching effect only plays partial function during construction of shield tunnels, and the shear stress of soil is less than its shear strength. Terzaghi's loosening earth pressure theory cannot be used for this case. To solve this problem, a method for calculating lateral pressure coefficient is deduced based on the Handy's theory. The results show that the lateral pressure coefficient is associated with the rotation angle of the principal stress, and its value varies between coefficients of active and passive earth pressures. Subsequently, the development of soil arching effect is related to the vault displacement of the tunnels. Accordingly, a computational formula for loosening earth pressure is proposed considering the ground loss and the stiffness of the segment based on the Terzaghi's theory. Finally, a simplified method for predicting construction disturbance scope of tunnels is put forward by studying soil arching height.
-
[1] TERZAGHI K. Stress distribution in dry and in saturated sand above a yielding trap-door[C]// Proceedings of First International Conference on Soil Mechanics and Foundation Engineering. Cambridge, Massachusetts, 1936: 307-311. [2] 朱 伟, 钟小春, 加 瑞. 盾构隧道垂直土压力松动效应的颗粒流模拟[J]. 岩土工程学报, 2008, 30(5): 750-754. (ZHU Wei, ZHONG Xiao-chun, JIA Rui. Simulation on relaxation effect of vertical earth pressure for shield tunnels by particle flow code[J]. Chinese Journal of Geotechnical Engineering, 2008, 30(5): 750-754. (in Chinese)) [3] KEZDI A. Lateral earth pressure[M]// Foundation Engineering Handbook, WINTERKORN H F, FANG H Y, ed. New York: Van Nostrand Reinhold Co., 1986: 147-220. [4] TIEN H J. A literature study of the arching effect[D]. Taiwan: Taiwan University, 1996. [5] HANDY R L. The arch in soil arching[J]. Journal of Geotechnical Engineering, 1985, 111(3): 302-317. [6] GIROUND J P, BONAPARTE R, BEECH J F, et al. Design of soil layer-geosynthetic systems overlying voids[J]. Geo- textiles and Geomembranes, 1990, 9(1): 11-50. [7] 陈若曦, 朱 斌, 陈云敏, 等. 基于主应力轴旋转理论的修正Terzaghi 松动土压力[J]. 岩土力学, 2010, 31(5): 1402-1406. (CHEN Ruo-xi, ZHU Bin, CHEN Yun-min, et al. Modified Terzaghi loozening earth pressure based on theory of main stress axes rotation[J]. Rock and Soil Mechanics, 2010, 31(5): 1402-1406. (in Chinese)) [8] 武 军, 廖少明, 张 迪. 基于颗粒流椭球体理论的隧道极限松动区与松动土压力[J]. 岩土工程学报, 2013, 35(4): 714-721. (WU Jun, LIAO Shao-ming, ZHANG Di. Loosening zone and earth pressure around tunnels in sandy soils based on ellipsoid theory of particle flows[J]. Chinese Journal of Geotechnical Engineering, 2013, 35(4): 714-721. (in Chinese)) [9] 王 非, 缪林昌. 落水洞上覆路堤土工加筋设计新方法[J].东南大学学报, 2009, 39(6): 1217-1221. (WANG Fei, MIAO Lin-chang. New designmethod of geosynthetic- reinforced embankment over sinkholes[J]. Journal of Southeast University：Natural Science, 2009, 39(6): 1217-1221. (in Chinese)) [10] 吕伟华, 缪林昌, 王 非. 基于不完全土拱效应的土工格栅加固机制与设计方法[J]. 岩石力学与工程学报, 2012, 31(3): 632-639. (LÜ Wei-hua, MIAO Lin-chang, WANG Fei. Mechanism of geogrid reinforcement based on pratially developed soil arch effect and design method[J]. Chinese Journal of Rock Mechanics and Engineering, 2012, 31(3): 632-639. (in Chinese)) [11] 张凤祥, 朱合华, 傅德明. 盾构隧道[M]. 北京: 人民交通出版社, 2004. (ZHANG Feng-xiang, ZHU He-hua, FU De-ming. Shield tunnel[M]. Beijing: China Communications Press, 2003. (in Chinese)) [12] TERZAGHI K. Theoretical soil mechanics[M]. New York: John Wiley and Sons, 1943: 66-76. [13] WARD W H. Ground support for tunnels in weak rocks[J]. Géotechnique, 1978(2): 133-170. -
