浅覆盾构隧道开挖面挤出刚性锥体破坏模式极限分析

张箭; 杨峰; 刘志; 阳军生

doi:10.11779/CJGE201407019

浅覆盾构隧道开挖面挤出刚性锥体破坏模式极限分析 English Version

张箭¹,
杨峰^1,,
刘志²,
阳军生¹

1. 中南大学土木工程学院,湖南长沙 410075; 2. 山西省交通科学研究院,山西太原 030006

基金项目: 国家科技支撑计划课题（2012BAK24B02）; 国家自然科学基金项目（51008309）

详细信息

作者简介:
张箭(1989- ),男,博士研究生,主要从事隧道与地下工程方面的研究工作。E-mail: zhangj0507@163.com。

通讯作者:
杨峰

计量
- 文章访问数: 391
- HTML全文浏览量: 5
- PDF下载量: 293
出版历程
- 收稿日期: 2013-08-24
- 发布日期: 2014-07-24

Three-dimensional limit analysis of blow-out failure modes of shallow shield tunnels

1. School of Civil Engineering, Central South University, Changsha 410075, China; 2. Shanxi Transportation Research Institute, Taiyuan 030006, China

摘要

摘要: 浅覆隧道盾构施工过程中可能引起开挖面挤出破坏。为研究开挖面破坏规律,借助已有刚性锥体破坏模式,推导隧道开挖面三维临界挤出压力表达式,建立极限分析上限法非线性规划模型并编程求解。利用该程序,研究了隧道埋深、地层参数等因素与开挖面临界挤出压力曲线关系及破坏模式的演化特征。结果表明,隧道埋深和土体内摩擦角对开挖面临界挤出压力及挤出破坏模式影响较大。发生挤出破坏时,开挖面附近和上方地表范围为主要破坏区域。最后,利用上限法和有限差分法对长沙地铁2号线长沙大道—体育公园站区间隧道某浅埋段进行开挖面稳定性分析,上限法与有限差分法所得结果相互印证,但上限法计算更为简便。
- 浅覆隧道 /
- 极限分析 /
- 上限法 /
- 开挖面 /
- 三维破坏模式 /
- 挤出破坏
Abstract: Blow-out failure of shallow tunnels may occur during shield construction process. To study failure rules, based on the upper bound limit analysis of rigid blocks, three-dimensional expressions for the critical blow-out face pressures are derived using the existing failure modes, and the results are optimized by means of the nonlinear programming model. The relations between the critical blow-out face pressures and influence factors such as formation parameters and buried depth are studied. Meanwhile, the failure modes under different conditions are also explored by use of the program. The results show that both the buried depth and the internal friction angle have great effects on the critical pressures and failure modes. The failure regions mainly range from the surroundings to the surface above the face within blow-out failure. Finally, face stability of a shallow tunnel of Changsha Metro Line 2 (from Changsha Road to Sports Park) is discussed by using the upper bound method and the finite difference method. The results obtained by the two methods are in agreement, but the upper bound method is actually more convenient.
- shallow tunnel /
- limit analysis /
- upper bound method /
- tunnel face /
- three-dimensional failure mode /
- blow-out failure

HTML全文

参考文献(18)

[1]	秦建设. 盾构施工开挖面变形与破坏机理研究[D]. 南京:河海大学, 2005. (QIN Jian-she. Study on face deformation and collapse of earth pressure shield tunnel[D]. Nanjing: Hohai University, 2005. (in Chinese))
[2]	KIM S H, TONON F. Face stability and required support pressure for TBM driven tunnels with ideal face membrane - Drained case[J]. Tunnelling and Underground Space Technology, 2010, 25: 526-542.
[3]	周小文, 蹼家骝. 砂土中隧洞开挖引起的地面沉降试验研究[J]. 岩土力学, 2002, 23(5): 559-563. (ZHOU Xiao-wen, PU Jia-liu. Centrifuge model test on ground settlement induced by tunneling in sandy soil[J]. Rock and Soil Mechanics, 2002, 23(5): 559-563. (in Chinese))
[4]	李昀, 张子新, 张冠军. 泥水平衡盾构开挖面稳定模型试验研究[J]. 岩土工程学报, 2007, 29(7): 1074-1079. (LI Yun, ZHANG Zi-xin, ZHANG Guan-jun. Laboratory study on face stability mechanism of slurry shields[J]. Chinese Journal of Geotechnical Engineering, 2007, 29(7): 1074-1079. (in Chinese))
[5]	胡雯婷, 吕玺琳, 黄茂松. 盾构隧道开挖面极限支护力三维极限平衡解[J]. 地下空间与工程学报, 2011, 7(5): 853-856. (HU Wen-ting, LÜ Xi-lin, HUANG Mao-song. Three-Dimensional limit equilibrium solution of the support pressure on the shield tunnel face[J]. Chinese Journal of Underground Space and Engineering, 2011, 7(5): 853-856. (in Chinese))
[6]	ATKINSON J H, POTTS D M. Stability of shallow tunnel in cohesionless soil[J]. Géotechnique, 1977, 27(2): 203-215.
[7]	SLOAN S W, ASSADI A. Undrained stability of a square tunnel in a soil whose strength increases linearly with depth[J]. Computer and Geotechnics, 1991, 12: 321-346.
[8]	杨峰. 浅埋隧道围岩稳定性的极限分析上限法研究[D].长沙: 中南大学, 2009. (YANG Feng. Investigation of shallow tunnel stability using upper bound solution of limit analysis[D]. Changsha: Central South University, 2009. (in Chinese))
[9]	吕玺琳, 王浩然, 黄茂松. 盾构隧道开挖面稳定极限理论研究[J]. 岩土工程学报, 2011, 33(1): 57-62. (LÜ Xi-lin, WANG Hao-ran, HUANG Mao-song. Limit theoretical study on face stability of shield tunnels[J]. Chinese Journal of Geotechnical Engineering, 2011, 33(1): 57-62. (in Chinese))
[10]	YAMAMOTO K, LYAMIN A V, WILSON D W, et al. Stability of dual circular tunnel in cohesive-frictional soil subjected to surcharge loading[J]. Computer and Geotechnics, 2013, 50: 41-54.
[11]	黄茂松, 宋春夏, 吕玺琳. 非均质黏土地基隧道环向开挖面稳定上限分析[J]. 岩土工程学报, 2013, 35(8): 1504-1512. (HUANG Mao-song, SONG Chun-xia, LÜ Xi-lin. Upper bound analysis for stability of a circular tunnel in heterogeneous clay[J]. Chinese Journal of Geotechnical Engineering, 2013, 35(8): 1504-1512. (in Chinese))
[12]	LECA E, DORMIEUX L. Upper and lower bound solutions for the face stability of shallow circular tunnels in frictional material[J]. Géotechnique, 1990, 40(4): 581-606.
[13]	SOUBRA A H. Three-dimensional face stability analysis of shallow circular tunnels[C]// International Conference on Geotechnical and Geological Engineering. Melbourne, 2000: 1-6.
[14]	SUBRIN D, WONG H. Tunnel face stability in frictional material: a new 3D failure mechanism[J]. C R Mecanique, 2002, 330: 513-519.
[15]	MOLLON G, DIAS D, SOUBRA A H. Face stability analysis of circular tunnels driven by a pressurized shield[J]. Journal of Geotechnical and Geoenvironmental Engineering, 2010, 136(1): 215-229.
[16]	MOLLON G, DIAS D, SOUBRA A H. Probalilistic analsis and design of circular tunnels against face stability[J]. International Journal of Geomechanics, 2009, 9(6): 237-249.
[17]	刘志. 浅覆地铁盾构隧道地表隆起破坏模式与开挖面极限支护力研究[D]. 长沙: 中南大学, 2012. (LIU Zhi. Study of blow-out failure mechanism and limit supporting force on tunnel face in shallow metro tunnel[D]. Changsha: Central South University, 2012. (in Chinese))
[18]	CHEN W F. Limit analysis and soil mechanics[M]. New York: Elsevier Scientific Publishing Company, 1975.
