边坡锚杆锚固系统固有频率及其参数影响分析

段建; 言志信

doi:10.11779/CJGE201406009

边坡锚杆锚固系统固有频率及其参数影响分析 English Version

段建^{1, 2},
言志信^1,2,

1. 兰州大学土木工程与力学学院,甘肃兰州 730000; 2. 西部灾害与环境力学教育部重点实验室(兰州大学),甘肃兰州 730000

基金项目: 国家自然科学基金项目（51308273,41372307）; 云南省交通运输厅科技教育专项资金资助项目（云交科2010(A)06-b）

详细信息

作者简介:
段建(1979- ),男,湖南沅江人,博士研究生,讲师,主要从事岩土锚固及支挡工程教学与研究工作。E-mail: duanj07@lzu.edu.cn。

通讯作者:
言志信

中图分类号: TU476
计量
- 文章访问数: 351
- HTML全文浏览量: 4
- PDF下载量: 300
出版历程
- 收稿日期: 2013-09-11
- 发布日期: 2014-06-19

Natural frequency and parameter influence of slope anchorage system

DUAN Jian^{1, 2},
YAN Zhi-xin^1,2,

1. School of Civil Engineering and Mechanics, Lanzhou University, Lanzhou 730000, China; 2. Key Laboratory of Mechanics on Disaster and Environment in Western China (Lanzhou University), Ministry of Education, Lanzhou 730000, China

摘要

摘要: 基于一定假定,建立了边坡锚杆锚固系统自由振动力学模型,获得了锚固系统固有频率及对应振型计算公式,通过算例,对比验证了理论计算公式的可行性；同时,还分别从锚杆长度、坡面附加质量以及刚度系数三方面开展了边坡锚固系统固有频率参数影响分析,探讨了之间内在规律：锚杆长度和值均对低阶固有频率的影响较小,而对高阶固有频率大小影响则较大；附加质量对锚固系统固有频率影响较小；边坡锚固系统在一定条件下具有线性振型固有频率。
- 边坡锚固系统 /
- 固有频率 /
- 振型 /
- 参数影响
Abstract: According to some assumptions, the dynamic mechanical model for slope anchorage system is established for free vibration. Some formulas for the natural frequency and the corresponding vibration modes of anchorage system are deduced. Compared to that of the other methods, the feasibility of the theoretical formulas is verified through a specific example. Meanwhile, the natural frequency of slope anchorage system is analyzed under the influence of different parameters, anchor length, equivalent lumped mass and stiffness coefficient . The inherent laws between them are discussed. It is found that the anchor length and the value of stiffness coefficient have less effect on the low-order natural frequency, and their impact on the size of high-order natural frequency is larger. The equivalent lumped mass has less effect on the natural frequency of slope anchorage system. The slope anchorage system has the natural frequency of linear vibration mode under certain conditions.
- slope anchorage system /
- natural frequency /
- vibration mode /
- parameter influence

HTML全文

参考文献(15)

[1]	周德培, 张建经, 汤涌. 汶川地震中道路边坡工程震害分析[J]. 岩石力学及工程学报, 2010, 29(3): 565-576. (ZHOU De-pei, ZHANG Jian-jing, TANG Yong. Seismic damage analysis of road slopes in Wenchuan Earthquake[J]. Chinese Journal of Rock Mechanics and Engineering, 2010, 29(3): 565-576. (in Chinese))
[2]	IVANOVIĆ A, NEILSON R D, RODGER A A. Lumped parameter modelling of single-tendon ground anchorage systems[J]. Geotechnical Engineering, 2001, 149(2): 103-113.
[3]	IVANOVIĆ A, STARKEY A, NEILSON R D, et al. The influence of load on the frequency response of rock bolt anchorage[J]. Advances in Engineering Software, 2003, 34(11): 697-705.
[4]	董建华, 朱彦鹏. 土钉土体系统动力模型的建立及地震响应分析[J]. 力学学报, 2009, 41(2): 236-242. (DONG Jian-hua, ZHU Yan-peng. Dynamic calculation model and seismic response for the system of soil nailing and surrounding soil[J]. Chinese Journal of Theoretical and Applied Mechanics, 2009, 41(2): 236-242. (in Chinese))
[5]	董建华, 朱彦鹏, 马巍. 框架预应力锚杆边坡支护结构动力计算方法研究[J]. 工程力学, 2013, 30(5): 250-258. (DONG Jian-hua, ZHU Yan-peng, MA Wei. Study on dynamic calculation method for frame supporting structure with pre-stress anchors[J]. Engineering Mechanics, 2013, 30(5): 250-258. (in Chinese))
[6]	叶海林, 郑颖人, 黄润秋, 等. 锚杆支护岩质边坡地震动力响应分析[J]. 后勤工程学院学报, 2010, 26(4): 1-7. (YE Hai-lin, ZHENG Ying-ren, HUANG Run-qiu, et al. Analysis on dynamic response of rockbolt in rock slope under earthquake[J]. Journal of Logistical Engineering University, 2010, 26(4): 1-7. (in Chinese))
[7]	叶海林, 黄润秋, 郑颖人, 等. 岩质边坡锚杆支护参数地震敏感性分析[J]. 岩土工程学报, 2010, 32(9): 1374-1379. (YE Hai-lin, HUANG Run-qiu, ZHENG Ying-ren, et al. Sensitivity analysis of parameters for bolts in rock slopes under earthquakes[J]. Chinese Journal of Geotechnical Engineering, 2010, 32(9): 1374-1379. (in Chinese))
[8]	HONG Yung-shan, CHEN Rong-her, WU Cho-sen, et al. Shaking table tests and stability analysis of steep nailed slopes[J]. Canadian Geotechnical Journal, 2005, 42(5): 1264-1279.
[9]	张明聚, 吕琦, 李立云, 等. 土钉支护边坡动力性能参数分析[J]. 岩土工程学报, 2010, 32(11): 1758-1763. (ZHANG Ming-ju, LÜ Qi, LI Li-yun, et al. Parametric analysis for a seismic behavior of soil nailing system[J]. Chinese Journal of Geotechnical Engineering, 2010, 32(11): 1758-1763. (in Chinese))
[10]	文畅平, 杨果林. 格构式框架护坡地震动位移模式的振动台试验研究[J]. 岩石力学与工程学报, 2011, 30(10): 2076-2083. (WEN Chang-ping, YANG Guo-lin. Shaking table model test study of seismic displacement mode of slope with anchor lattice frame structure[J]. Chinese Journal of Rock Mechanics and Engineering, 2011, 30(10): 2076-2083. (in Chinese))
[11]	叶海林, 郑颖人, 陆新, 等. 边坡锚杆地震动特性的振动台试验研究[J]. 土木工程学报, 2011, 44(增刊): 152-157. (YE Hai-lin, ZHENG Ying-ren, LU Xin, et al. Shaking table test on anchor bars of slope under earthquake[J]. China Civil Engineering Journal, 2011, 44(S0): 152-157. (in Chinese))
[12]	LYSMER J, RICHART F E. Dynamic response of footing to vertical loading[J]. Journal of Soil Mechanics and Foundation Division, ASCE, 1966, 92(1): 65-91.
[13]	NOVAK M, NOGAMI T, ABOUL-ELLA F. Dynamic soil reaction for plain strain case[J]. Journal of the Engineering Mechanics Division, 1978, 104(4): 953-959.
[14]	王腾, 王奎华, 谢康和. 成层土中桩的纵向振动理论研究及应用[J]. 土木工程学报, 2002, 35(1): 83-87. (WANG Teng, WANG Kui-hua, XIE Kang-he. Study on vibration properties of piles in layered soils[J]. China Civil Engineering Journal, 2002, 35(1): 83-87. (in Chinese))
[15]	倪振华. 振动力学[M]. 西安: 西安交通大学出版社, 1990. (NI Zhen-hua. Vibration mechanics[M]. Xi'an: Xi'an Jiaotong University Press, 1990. (in Chinese))
