考虑固结群桩竖向应力相互作用的积分方程分析方法

梁发云; 宋著; 郭蔚东

doi:10.11779/CJGE201405006

考虑固结群桩竖向应力相互作用的积分方程分析方法 English Version

梁发云^{1, 2},
宋著^{1, 2},
郭蔚东³

1. 同济大学岩土及地下工程教育部重点实验室,上海 200092; 2. 同济大学地下建筑与工程系,上海 200092; 3. 卧龙岗大学土木、采矿与环境工程学院,澳大利亚卧龙岗 NSW 2522

基金项目: 国家自然科学基金项目（41172246）; 国家重点基础研究发展计划（973计划）项目（2013CB036304）

详细信息

作者简介:
梁发云(1976- ),男,安徽肥东人,博士,教授,博士生导师,主要从事桩基础、深基坑工程及桥梁冲刷等方面的教学和科研工作。E-mail: fyliang@tongji.edu.cn。

中图分类号: TU473
计量
- 文章访问数: 366
- HTML全文浏览量: 2
- PDF下载量: 266
出版历程
- 收稿日期: 2013-09-02
- 发布日期: 2014-05-20

Integral equation method for interaction effect of stress of vertically loaded pile groups considering consolidation

LIANG Fa-yun^{1, 2},
SONG Zhu^{1, 2},
GUO Wei-dong³

1. Key Laboratory of Geotechnical and Underground Engineering of Ministry of Education, Tongji University, Shanghai 200092, China; 2. Department of Geotechnical Engineering, Tongji University, Shanghai 200092, China; 3. School of Civil, Mining and Environmental Engineering, University of Wollongong, Wollongong, NSW 2522, Australia

摘要

摘要: 采用Biot 固结方程,分别以等长和不等长两桩为分析对象,将受竖向荷载作用的桩土体系分解成半空间饱和扩展土和虚拟桩,基于竖向应变协调关系建立桩土相互作用的第二类Fredholm 积分方程,求解出不同固结状态时的桩身轴力分布。在等长两桩中,由于邻近桩的存在,桩身附加轴力主要分布于桩身20%～80%深度处,其影响程度随着桩间距的增加而减弱。进一步将等长两桩分析扩展至群桩研究中,分析表明：群桩效应引起了桩顶荷载的不均匀分布；土体固结对桩身内力分布也有一定的影响,固结后角桩承担的荷载有所下降。桩长不等时,长短桩之间的相互作用效应并不一致,表现为两桩桩顶承受相同荷载时长桩沿桩身附加轴力增加较短桩明显。最后,将不等长桩相互作用系数应用于群桩的优化分析中,在保证总桩长和桩基沉降基本相当的情况下,通过调整不同位置的桩长使得各桩受力趋于合理。
- 积分方程 /
- 不等长桩 /
- 群桩效应 /
- Biot固结 /
- 桩身附加轴力
Abstract: The interaction effect of stress is obtained for two vertically loaded piles which are of equal or different pile lengths embedded in the homogeneous poroelastic saturated soils governed by the Biot’s theory. The pile-soil system is decomposed into an extended soil and two fictitious piles, and the compatibility condition between the axial strain of the fictitious piles and the extended soil is established. This approach yields the governing Fredholm integral equations of the second kind, and the basic unknowns of the axial force and settlement along the pile shaft are calculated. For the piles with the same length, the additional force along the pile shaft can be observed at 20%~80% depth of pile length due to the adjacent pile and decreases with the pile spacing. Extending two-pile model into pile group analysis, pile group effect will lead to the differences in load at the pile heads. The consolidation effect can alter the distribution of axial stress along the pile shafts. The loadings acting on the corner piles decrease. For the piles with different dimensions, the interactions among long and short piles are different, and the additional axial force along the long pile is greater than that along the short one. The combination of long and short piles is applied to the optimization of pile groups. The results show that adjusting the pile length within a pile group can reduce the differential pile-head loadings without increasing the total pile length and pile-head settlement.
- integral equation method /
- dissimilar pile /
- pile group effect /
- Biot consolidation /
- additional axial force

HTML全文

参考文献(28)

[1]	POULOS H G. Pile behaviour — theory and application[J]. Géotechnique, 1989, 39(3): 365-415.
[2]	GUO W D. Theory and practice of pile foundations[M]. Boca Raton: CRC Press, 2012.
[3]	POULOS H G. Analysis of the settlement of pile group[J]. Géotechnique, 1968, 18(4): 449-471.
[4]	MYLONAKIS G, GAZETAS G. Settlement and additional internal force of group piles in layered soil[J]. Géotechnique, 1998, 48(1): 55-72.
[5]	CHOW Y K. Analysis of vertically loaded pile groups[J]. International Journal for Numerical and Analytical Methods in Geomechanics, 1986, 10(1): 59-72.
[6]	SOUTHCOTT PH, SMALL JC. Finite layer analysis of vertically loaded piles and pile groups[J]. Computers and Geotechnics, 1996, 18(1): 47-63.
[7]	LIANG F Y, CHEN L Z, HAN J. Integral equation method for analysis of piled rafts with dissimilar piles under vertical loading[J]. Computers and Geotechnics, 2009, 36(3): 419-426.
[8]	CHEN SL, SONG CY, and CHEN LZ. Two-pile interaction factor revisited [J]. Canadian Geotechnical Journal, 2011, 48(5): 754-766.
[9]	POULOS H G, DAVID E H. Pile foundation analysis and design[M]. New York: John Wiley and Sons, 1980.
[10]	WONG S C, POULOS H G. Approximate pile-to-pile interaction factors between two dissimilar piles[J]. Computers and Geotechnics, 2005, 32(8): 613-618.
[11]	ZHANG Q Q, ZHANG Z M. Study on interaction between dissimilar piles in layered soils[J]. International Journal for Numerical and Analytical Methods in Geomechanics, 2011, 35: 67-81.
[12]	王建华, 陆建飞, 沈为平. Biot 固结理论在单桩负摩擦研究中的应用[J]. 岩土工程学报, 2000, 22(5): 590-593. (WANG Jian-hua, LU Jian-fei, SHEN Wei-ping. The application of Biot consolidation theory to the negative friction problem of single pile[J]. Chinese Journal of Geotechnical Engineering, 2000, 22(5): 590-593. (in Chinese))
[13]	陆建飞, 王建华, 沈为平. 考虑固结和流变的群桩的积分方程解法[J]. 岩土工程学报, 2000, 22(6): 650-653. (LU Jian-fei, WANG Jian-hua, SHEN Wei-ping. The integral equation method to solve pile group problem considering consolidation and rheology of soil[J]. Chinese Journal of Geotechnical Engineering, 2000, 22(6): 650-653. (in Chinese))
[14]	程泽海, 凌道盛, 陈云敏. 桩筏基础在竖向荷载作用下的时间效应[J]. 土木工程学报, 2004, 37(2): 73-77. (CHENG Ze-hai, LING Dao-sheng, CHEN Yun-min. Time effects on piled raft foundation under vertical loading[J]. China Civil Engineering Journal, 2004, 37(2): 73-77. (in Chinese))
[15]	崔春义, 栾茂田, 杨庆. 结构-桩筏-地基体系时间效应的三维数值分析[J]. 岩土工程学报, 2007, 29(8): 1244-1250. (CUI Chun-yi, LUAN Mao-tian, YANG Qing. 3D numerical analysis of time effect of superstructure-piled raft-foundation[J]. Chinese Journal of Geotechnical Engineering, 2007, 29(8): 1244-1250. (in Chinese))
[16]	梅国雄, 宰金珉. 固结有限层理论与应用[M]. 北京: 科学出版社, 2006. (MEI Guo-xiong, ZAI Jin-min. Theory and application of consolidation finite layer[M]. Beijing: Science Press, 2006. (in Chinese))
[17]	梁发云, 陈龙珠, 李镜培. 层状地基中混合桩型复合地基的分析方法[J]. 岩土工程学报, 2007, 29(3): 380-384. (LIANG Fa-yun, CHEN Long-zhu, LI Jing-pei. Study on the behavior of composite foundation with hybrid piles in layered soils[J]. Chinese Journal of Geotechnical Engineering, 2007, 29(3): 380-384. (in Chinese))
[18]	梁发云, 陈龙珠, 李镜培. 混合桩型复合地基工程性状的近似解析方法[J]. 岩土工程学报, 2005, 27(4): 459-463. (LIANG Fa-yun, CHEN Long-zhu, LI Jing-pei. An approximate approach for the analysis of composite foundation with hybrid piles[J]. Chinese Journal of Geotechnical Engineering, 2005, 27(4): 459-463. (in Chinese))
[19]	LIANG F Y, SONG Z, GUO W D. Group interaction on vertically loaded piles in saturated poroelastic soil[J]. Computers and Geotechnics, 2014, 56: 1-10. (http://dx.doi.org/10.1016/j.compgeo.2013.10.003)
[20]	MUKI R, STERNBERG E. Elastostatic load-transfer to a half-space from a partially embedded axially loaded road[J]. International Journal of Solids and Structures, 1970, 6(1): 69-90.
[21]	MCNAMEE J, GIBSON R E. Displacement functions and linear transforms applied to diffusion through porous elastic media[J]. Quarterly Journal of Mechanics & Applied Mathematics, 1960, 13(1): 98-111.
[22]	NIUMPRADIT B, KARASUDHI P. Load transfer from an elastic pile to saturated porous elastic soil[J]. International Journal for Numerical and Analytical Methods in Geomechanics, 1981, 5(2): 115-138.
[23]	韩煊, 李宁. 复合地基中群桩相互作用机理的数值试验研究[J]. 土木工程学报, 1999, 32(4): 75-80. (HAN Xuan, LI Ning. Numerical simulation test on interaction mechanism of group pile composite foundation[J]. China Civil Engineering Journal, 1999, 32(4): 75-80. (in Chinese))
[24]	陈龙珠, 梁发云. 桩筏基础的积分方程解法及其参数分析[J]. 岩土工程学报, 2004, 26(6): 733-738. (CHEN Long-zhu, LIANG Fa-yun. An integral equation approach and parametric analysis for piled raft foundation[J]. Chinese Journal of Geotechnical Engineering, 2004, 26(6): 733-738. (in Chinese))
[25]	KUWABARA F. An elastic analysis for piled raft foundations in a homogeneous soil[J]. Soils and Foundations, 1989, 29(1): 82-92.
[26]	WONG S C, POULOS H G. Approximate pile-to-pile interaction factors between two dissimilar piles[J]. Computers and Geotechnics, 2005, 32(8): 613-618.
[27]	CLANCY P, RANDOLPH M F. An approximate analysis procedure for piled raft foundations[J]. International Journal for Numerical and Analytical Methods in Geomechanics, 1993, 17(12): 849-869.
[28]	LEUNG Y F, KLAR A, SOGA K. Theoretical study on pile length optimization of pile groups and piled rafts[J]. Journal of Geotechnical and Geoenvironment Engineering, 2010, 136(2): 319-330.
