压裂中水力裂缝穿过天然裂缝判断准则

张然; 李根生; 赵志红; 盛茂; 范鑫; 迟焕鹏

doi:10.11779/CJGE201403024

压裂中水力裂缝穿过天然裂缝判断准则 English Version

1. 油气资源与探测国家重点实验室（中国石油大学）,北京 102249; 2. 油气藏地质及开发工程国家重点实验室（西南石油大学）,四川成都 610500

基金项目: 国家自然科学基金国际合作项目（51210006）; 国家自然科学基金重点项目（51234006）

详细信息

作者简介:
张然(1987- )，男，博士研究生，就读于中国石油大学（北京）石油工程学院，主要从事页岩气井水力压裂造缝机理及水力参数研究。E-mail: zhang_lili8877@sina.com。

通讯作者:
李根生

中图分类号: TU41
计量
- 文章访问数: 0417
- HTML全文浏览量: 0
- PDF下载量: 0485
出版历程
- 收稿日期: 2013-04-09
- 发布日期: 2014-03-19

New criteria for hydraulic fracture crossing natural fractures

1. State Key Laboratory of Petroleum Resource and Prospecting, China University of Petroleum, Beijing 102249, China; 2. State Key Laboratory of Oil and Gas Reservoir Geology and Exploitation, Southwest Petroleum University, Chengdu 610500, China

摘要

摘要: 为准确预测水力压裂过程中水力裂缝是否会穿过天然裂缝及其穿出方向,基于弹性力学理论,建立了水力裂缝穿过天然裂缝的判断准则,并给出了水力裂缝穿出天然裂缝时穿出角度的计算方法。计算结果表明：在给定逼近角下对应有确定的水力裂缝穿过天然裂缝所需的水平主应力比值范围,超过或低于这个范围水力裂缝将不能穿过天然裂缝；高逼近角及高水平主应力比值下水力裂缝易直接穿过天然裂缝；在相同逼近角下,水平主应力比值越大,穿出方向总是倾向于靠近增大的水平主应力方向。
- 裂缝性储层 /
- 天然裂缝 /
- 穿过 /
- 主应力差异 /
- 逼近角 /
- 穿出角度
Abstract: The complexity of a hydraulic fracture network depends on the behaviors of induced hydraulic fractures as they intersect natural fractures, so it is important to understand the mechanism of fracture intersection under particular field conditions of in-situ stresses, rock and natural fracture properties. An accurate criterion for the fracture propagation across natural fractures is established, and the direction of the reinitiated fracture is also studied. The results show that for a given approaching angle there exits a certain range of stress ration when crossing occurs, beyond this range crossing will not occur. Under high horizontal differential principle stress and approaching angle, hydraulic fracture is more likely to cross the natural fracture. As the stress ration increases, the direciton of reinitiated fracture draws closer to the direction of the incremental principle stress. This new criterion can be applied in the general analysis of fracture network and simulation of numerical fracture network.
- fractured reservoir /
- natural fracture /
- crossing /
- stress ration /
- approaching angle /
- reinitiated angle

HTML全文

参考文献(12)

[1]	吴奇, 胥云, 王腾飞, 等. 增产改造理念的重大变革：体积改造技术概论[J]. 天然气工业, 2011, 31(4): 7-12. (WU Qi, XU Yun, WANG Teng-fei, et al. The revolution of reservoir stimulation: An introduction of volume fracturing[J]. Natural Gas Industry, 2011, 31(4): 7-12. (in Chinese))
[2]	CIPOLLA C L, WARPINSKI N R, MAYERHOFER M J, et al. The relationship between fracture complexity, reservoir properties, and fracture-treatment design[R]. SPE 115769, 2008.
[3]	雷群, 胥云, 蒋廷学, 等. 用于提高低—特低渗透油气藏改造效果的缝网压裂技术[J]. 石油学报, 2009, 30(2): 237-241. (LEI Qun, XU Yun, JIANG Ting-xue, et al. “Fracture network” fracturing technique for improving post-fracturing performance of low and ultra-low permeability reservoirs[J]. Acta Petrolei Sinica, 2009, 30(2): 237-241. (in Chinese))
[4]	DANESHY A A. Off-Balance Growth: A new concept in hydraulic fracturing[J]. Journal of Petroleum Technology, 2003, 55(4): 78-85.
[5]	DANESHY A A. Analysis of off-balance fracture extension and fall-off pressures[C]// SPE International Symposium and Exhibition on Formation Damage Control. Lafayette, Louisiana, 2004.
[6]	WARPINSKI N R, TEUFEL L W. Influence of geologic discontinuities on hydraulic fracture propagation[J]. Journal of Petroleum Technology, 1987, 44(2): 209-220.
[7]	HOSSAIN M M, RAHMAN M K, RAHMAN S S. Volumetric growth and hydraulic conductivity of naturally fractured reservoirs during hydraulic fracturing: A case study using Australian conditions[C]// SPE Annual Technical Conference and Exhibition. Dallas, Texas, 2000.
[8]	BLANTON T L. An experimental study of interaction between hydraulically induced and pre-existing fractures[C]// SPE Unconventional Gas Recovery Symposium. Pittsburgh, Pennsylvania, 1982.
[9]	BLANTON T L. Propagation of hydraulically and dynamically induced fractures in naturally fractured reservoirs[C]// SPE Unconventional Gas Technology Symposium. Louisville, Kentucky, 1986.
[10]	周健, 陈勉, 金衍, 等. 多裂缝储层水力裂缝扩展机理试验[J]. 中国石油大学学报(自然科学版), 2008, 32(4): 51-54. (ZHOU Jian, CHEN Mian, JIN Yan, et al. Experiment of propagation mechanism of hydraulic fracture in multi-fracture reservoir[J]. Journal of China University of Petroleum(Edition of Natural Science), 2008, 32(4): 51-54. (in Chinese))
[11]	周健, 陈勉, 金衍, 等. 裂缝性储层水力裂缝扩展机理试验研究[J]. 石油学报, 2007, 28(5): 109-113. (ZHOU Jian, CHEN Mian, JIN Yan, et al. Experimental study on propagation mechanism of hydraulic fracture in naturally fractured reservoir[J]. Acta Petrolei Sinica, 2007, 28(5): 109-113. (in Chinese))
[12]	RENSHAW C E, POLLARD. An experimentally verified criterion for propagation across unbonded frictional interfaces in brittle,linear elastic materials[J]. International Journal of Rock Mechanics Mining Science and Geomechanics, 1995, 32(3): 237-249.
