Centrifugal model tests on stability of large-diameter cylinders under wave loads simulated by water-level difference method

REN Guofeng; GUAN Yunfei; ZHOU Chuner; GU Xingwen; XU Guangming

doi:10.11779/CJGE2024S10046

Volume 46 Issue S1

Turn off MathJax

Article Contents

Abstract

References

Chinese Journal of Geotechnical Engineering > 2024 > 46(S1): 27-31. > DOI: 10.11779/CJGE2024S10046

REN Guofeng, GUAN Yunfei, ZHOU Chuner, GU Xingwen, XU Guangming. Centrifugal model tests on stability of large-diameter cylinders under wave loads simulated by water-level difference method[J]. Chinese Journal of Geotechnical Engineering, 2024, 46(S1): 27-31. DOI: 10.11779/CJGE2024S10046

Citation:

PDF (1377 KB)

Centrifugal model tests on stability of large-diameter cylinders under wave loads simulated by water-level difference method

REN Guofeng^{1, 2,},
GUAN Yunfei^{1, 2},
ZHOU Chuner³,
GU Xingwen^{1, 2, ,},
XU Guangming^{1, 2}

1.
Nanjing Hydraulic Research Institute, Nanjing 210029, China
2.
State Key Laboratory of Hydrology-Water Resources and Hydraulic Engineering, Nanjing 210029, China, China
3.
Guangdong Province Planning and Design Institute for Water Transpotation Co., Ltd., Guangzhou 510050, China

More Information

Received Date: April 28, 2024

Graphical Abstract

Abstract

Abstract

A type of cylinder structure with large diameter and height is employed in an artificial island project subjected to harsh wave conditions. The centrifugal model tests on the stability of large cylinder under wave loads is carried out by using the water-level difference method to simulate the wave loads. The results show that the cylinder translates approximately under 25-year wave suction loads with the lateral displacement of 353 mm and the settlement of the cylinder top of 187 mm, respectively. The mean circumferential tensile stress of the cylinder wall during construction is about 90 MPa, which is within the allowable stress range of steel cylinder materials. The soil pressure at the sea side of the cylinder wall tends to be stable with the increase of the water-level difference to the peak value, indicating that there is no new relative displacement trend between the cylinder and the surrounding soils, and the large-diameter steel cylinder revetment structure is stable and safe under wave loads.
- large-diameter cylinder structure,
- water-level difference method,
- centrifugal model test,
- mechanism,
- stability

FullText(HTML)

References (6)

References

[1]	周锡礽, 刘佳岭. 大圆筒结构在港口工程中的应用以及结构设计计算中的几个问题[J]. 港口工程, 1994(72): 1-10. https://www.cnki.com.cn/Article/CJFDTOTAL-GKGC405.000.htm ZHOU Xireng, LIU Jialing. Several problems about the application of large cylinder structure in port engineering and the calculation of the structural design[J]. Port Engineering, 1994(72): 1-10. (in Chinese) https://www.cnki.com.cn/Article/CJFDTOTAL-GKGC405.000.htm
[2]	竺存宏, 邓冰, 田双珠. 沉入式大圆筒在深水码头结构中的应用研究有关问题探讨[J]. 水道港口, 1997(12): 1-17. https://www.cnki.com.cn/Article/CJFDTOTAL-SDGK199704000.htm ZHU Cunhong, DENG Bing. Discussion on the application research of submerged large cylinder in deep water wharf structure[J]. Journal of Waterway and Harbor, 1997(12): 1-17. (in Chinese) https://www.cnki.com.cn/Article/CJFDTOTAL-SDGK199704000.htm
[3]	刘建起, 陈宅珠. 浅沉式大直径圆筒结构稳定性计算[J]. 天津大学学报, 1994, 27(4): 460-467. https://www.cnki.com.cn/Article/CJFDTOTAL-TJDX404.011.htm LIU Jianqi, CHEN Zhaizhu. Stability calculation of large diameter cylindrical structure with shallow subsidence [J]. Journal of Tianjin University, 1994, 27(4): 460-467. (in Chinese) https://www.cnki.com.cn/Article/CJFDTOTAL-TJDX404.011.htm
[4]	竺存宏, 张凤展, 张丽丽. 沉入式大圆筒有关理论问题的探讨[J]. 港工技术, 2002, 39(1): 19-22. https://www.cnki.com.cn/Article/CJFDTOTAL-GAOG200201007.htm ZHU Cunhong, ZHANG Fengzhan, ZHANG Lili. Investigation on theoretical issues of buried large-diameter cylinder[J]. Port Engineering Technology, 2002, 39(1): 19-22. (in Chinese) https://www.cnki.com.cn/Article/CJFDTOTAL-GAOG200201007.htm
[5]	徐光明, 章为民, 赖忠中. 沉入式大圆筒结构码头工作机理离心模型试验研究[J]. 海洋工程, 2001, 19(1): 38-44. https://www.cnki.com.cn/Article/CJFDTOTAL-HYGC200101006.htm XU Guangming, ZHANG Weimin, LAI Zhongzhong. Centrifuge modeling of quay walls composed of large-diameter cylinders embedded below mud line[J]. The Ocean Engineering, 2001, 19(1): 38-44. (in Chinese) https://www.cnki.com.cn/Article/CJFDTOTAL-HYGC200101006.htm
[6]	陈福全, 杨敏. 大直径圆筒结构码头性状分析[J]. 同济大学学报(自然科学版), 2002, 30(7): 797-801. https://www.cnki.com.cn/Article/CJFDTOTAL-TJDZ200207003.htm CHEN Fuquan, YANG Min. Numerical analysis of behavior of large diameter cylindrical wharf structure[J]. Journal of Tongji University (Natural Science), 2002, 30(7): 797-801. (in Chinese) https://www.cnki.com.cn/Article/CJFDTOTAL-TJDZ200207003.htm
