非均质黏土地基隧道环向开挖面稳定上限分析

黄茂松; 宋春霞; 吕玺琳

非均质黏土地基隧道环向开挖面稳定上限分析 English Version

黄茂松^1,2,
宋春霞^{1, 2},
吕玺琳^{1, 2}

1. 同济大学地下建筑与工程系，上海 200092; 2. 同济大学岩土及地下工程教育部重点实验室，上海 200092

基金项目: 国家自然科学基金国家杰出青年科学基金项目（50825803）

详细信息

作者简介:
黄茂松(1965- )，男，浙江玉环人，博士，教授，博士生导师，主要从事岩土工程方面的教学与科研工作。E-mail: mshuang@.tongji.edu.cn。

中图分类号: TU470
计量
- 文章访问数: 0358
- HTML全文浏览量: 0
- PDF下载量: 0460
出版历程
- 收稿日期: 2012-11-20
- 发布日期: 2013-08-19

Upper bound analysis for stability of a circular tunnel in heterogeneous clay

HUANG Mao-song^1,2,
SONG Chun-xia^{1, 2},
LüXi-lin^{1, 2}

1. Department of Geotechnical Engineering, Tongji University, Shanghai 200092, China; 2. Key Laboratory of Geotechnical and Underground Engineering of Ministry of Education, Tongji University, Shanghai 200092, China

摘要

摘要: 基于多块体极限分析上限法，推导了不排水条件下饱和黏性土地基中隧道环向开挖面稳定支护压力的计算公式。编制相应的计算程序，优化得到了隧道环向开挖稳定的最优上限解答。通过与已有极限分析上限解答的对比，验证了多块体极限分析上限法在隧道开挖稳定性分析的适用性。对照隧道开挖稳定的最优上限解的变化规律及相应破坏面的形状，详细分析了隧道埋深比、土体重度及强度非均质性对开挖面极限支护压力和因隧道开挖产生的滑动面范围和位置的影响。在此基础上，进一步基于隧道失稳的简化破坏模式推导了黏性土地基隧道开挖稳定的极限支护压力的简化上限解。通过与已有离心模型试验的对比验证，指出本文上限解可直接用于工程中初步确定开挖面支护压力，为隧道工程设计提供可靠的理论依据。
- 多块体极限分析上限法 /
- 隧道开挖稳定 /
- 滑动面 /
- 重度参数 /
- 非均质参数 /
- 简化上限解
Abstract: The stability of a shallow circular tunnel in undrained clay layer is examined in the framework of the limit analysis by means of the limit analysis upper bound method. Rigorous upper bounds of the face collapse pressure and failure envelopes are obtained using the rigid multi-block translational collapse mechanism. The multi-block failure mechanism has significant advantages with respect to the existing limit analysis: it takes into account the effect of cover-to-diameter ratio, gravity parameter and heterogeneous parameter. And the present results of the collapse pressure significantly improve the best available solution given by the solutions of other limit analysis. It is concluded that the collapse pressure increases linearly with the increase of gravity parameter, but decreases linearly with the increase of the heterogeneous parameter. Also the configuration of failure envelopes will vary as the cover-to-diameter ratio, gravity parameter and heterogeneous parameter differ. On the basis of those results, a simplified mechanism is obtained and a simplified solution is derived from the upper bound theory of plasticity. Finally the upper bound multi-block solution for the stability of TBM excavation in clays and its simplified solution are demonstrated by comparing with the centrifuge results.
- multi-block upper bound limit analysis /
- tunnel stability /
- sliding surface /
- gravity parameter /
- heterogeneous parameter /
- simplified solution

HTML全文

参考文献(1)

[1]

CAIRNCROSS A M. Deformation around tunnel heading in clay[D]. London: University of Cambridge, 1973.
SENEVIRATNE H N. Deformation and pore pressure around model tunnels in soft clay[D]. London: University of Cambridge, 1979.
MAIR R J. Centrifugal modeling of tunnel construction in soft clay [D]. London: University of Cambridge, 1979.
DAVIS E H, GUNN M J, MAIR R J,et al. The stability of shallow tunnels and underground openings in cohesive materials[J]. Géotechnique, 1980, 30(4): 397-416.
OSMAN A S, MAIR R J, BOLTON M D. On the kinematics of 2D tunnel collapse in undrained clay[J]. Géotechnique, 2006, 56(9): 585-595.
SLOAN S W, ASSADI A. Stability of shallow tunnels in soft ground[C]// Predictive Soil Mechanics, Proceedings of the Wroth Memorial Symposium. London: Thomas Telford, 1993: 644-663.
郑颖人, 邱陈瑜, 张红, 等. 关于土体隧道稳定性分析方法的探索[J]. (岩石力学与工程学报), 2008, 27(10): 1968-1980.(ZHENG Ying-ren, QIU Chen-yu, ZHANG Hong,et al. Exploration of stability analysis methods for surrounding rocks of soil tunnel[J]. Chinese Journal of Rock Mechanics and Engineering, 2008, 27(10): 1968-1980. (in Chinese))
黄正荣, 朱伟, 梁精华, 等. 盾构隧道开挖面极限支护压力研究[J]. (土木工程学报), 2006, 39(10): 112-116.(HUANG Zheng-rong, ZHU Wei, LIANG Jing-hua,et al. A study on the limit support pressure at excavation face of shield tunneling[J]. China Civil Engineering Journal, 2006, 39(10): 112-116. (in Chinese))
乔金丽, 张义同, 高健, 等强度折减法在盾构隧道开挖面稳定分析中的应用[J]. 等强度折减法在盾构隧道开挖面稳定分析中的应用[J]. (天津大学学报), 2010, 43(1): 14-20.(QIAO Jin-li, ZHANG Yi-tong, GAO Jian,et al. Application of strength reduction method to stability analysis of shield tunnel face[J]. Journal of Tianjin University Science and Technology, 2010, 43(1): 14-20. (in Chinese))
秦会来, 黄茂松, 马少坤. 黏土基坑抗隆起稳定分析的多块体上限解[J]. (岩石力学与工程学报), 2010, 29(1): 73-81.(QIN Hui-lai, HUANG Mao-song, MA Shao-kun. Multi-block upper bound method for basal heave stability analysis of braced excavations in clay[J]. Chinese Journal of Rock Mechanics and Engineering, 2010, 29(1): 73-81. (in Chinese))
周维祥. 非均质黏土地基隧道开挖面稳定性分析[D]. 上海: 同济大学, 2012.(ZHOU Wei-xiang. Stability analysis of tunnel face in non-homogeneous clays[D]. Shanghai: Tongji University, 2012. (in Chinese))
CHEN W F. Limit analysis and soil plasticity [M].New York:Elsevier Scientific Publishing Company, 1975.
WU B R, LEE C J. Ground movements and collapse mechanisms induced by tunneling in clayey soil[J]. International Journal Physical Modelling in Geotechnics, 2003, 3(4): 13-27.
