饱和黄土区CFG桩与振动沉管碎石桩复合地基承载特性试验研究

王 旭,张延杰; ,蒋代军; ,刘德仁; ,蒋鹏程

饱和黄土区CFG桩与振动沉管碎石桩复合地基承载特性试验研究 English Version

王旭,张延杰; ,蒋代军; ,刘德仁; ,蒋鹏程

王旭,张延杰; ,蒋代军; ,刘德仁; ,蒋鹏程

基金项目: 长江学者和创新团队发展计划资助（IRT1139）

详细信息

作者简介:
王旭,张延杰; ,蒋代军; ,刘德仁; ,蒋鹏程: 王旭(1965- )，男，河南郑州人，工学博士，教授，主要从事桩基础与土工设计理论方面的研究工作。E-mail: publicwang@163.com。

中图分类号: TU473.1
计量
- 文章访问数: 301
- HTML全文浏览量: 0
- PDF下载量: 333
出版历程
- 收稿日期: 2013-06-14
- 发布日期: 2013-11-24

Experimental research on bearing features of CFG pile composite ground and vibrating sinktube detritus pile composite ground on saturated loess

WANG Xu^{1, 2}, ZHANG Yan-jie¹, JIANG Dai-jun¹, LIU De-ren¹, JIANG Peng-cheng^{1, 3}

1. School of Civil Engineering, Lanzhou Jiaotong University, Lanzhou 730070, China; 2. Key Laboratory of Road & Bridge and Underground Engineeringof Gansu Province, Lanzhou 730070, China; 3. Guangzhou Railway Group Co., Ltd., Guangzhou 510088, China

摘要

摘要: 国家重点工程西部管道工程兰州原油末站超大型油罐群,是我国首次在饱和黄土地基修建的超大型储油设施。由于饱和黄土地基天然承载力仅为60 kPa, 油罐区地基采用CFG 桩复合地基进行处理,工艺装置区采用振动沉管碎石桩进行地基处理。现场开展了振动沉管碎石桩桩体重型动力触探试验、振动沉管碎石桩单桩复合地基静载荷试验、CFG 单桩及单桩复合地基静载荷试验,确定复合地基的承载力。通过试验得出,振动沉管碎石桩单桩复合地基承载力特征值为66 kPa。不满足设计要求的70 kPa；而CFG单桩复合地基承载力特征值为275 kPa,满足15万m³油罐复合地基承载力270 kPa 的设计要求。探讨了两种复合地基的承载特性,试验研究成果对饱和黄土地基处理提供了借鉴和经验。
- 饱和黄土 /
- CFG桩 /
- 碎石桩 /
- 承载力
Abstract: The large oil tank group in Lanzhou, which is a part of the China's state key project—the western oil pipe line project, is constructed on the saturated loess stratum for the first time in China. Due to the low natural bearing capacity, only 60 kPa, that the ground treatment should adopt the CFG pile composite method is applied in oil tank area. The vibrating sinktube detritus pile composite method is applied in process plant area. The dynamic penetration tests, single-pile static load tests and composite foundation static load tests are carried out to determine the bearing capacity of the composite foundation. Through the field experimental research, it is found that the bearing capacity of the vibrating sinktube detritus pile composite is only 66 kPa, which does not meet the design requirements of 70 kPa. The bearing capacity of CFG pile composite is 275 kPa, which can meet the design requirements of 270 kPa. The bearing features of the CFG pile composite ground and the vibrating sinktube detritus pile composite ground are discussed to provide references for similar projects.
- saturated loess /
- CFG pile /
- gravel pile /
- bearing capacity

HTML全文

参考文献(7)

[1]	中油四维工程勘察有限公司.西部原油成品油管道工程兰州原油末站(罐区)岩土工程勘察报告[R]. 2005. (Petroleum Engineering Investigation Siwei Co. Geotechnical investigation report of western oil pipeline project in Lanzhou last stop (tank) [R]. 2005. (in Chinese))
[2]	何广讷. 振冲碎石桩复合地基[M]. 北京: 人民交通出版社, 2001. (HE Guang-ne. Vibrating sinktube detritus pile composite ground[M]. Beijing: China Communications Press, 2001. (in Chinese))
[3]	高炳鑫, 贾宏程. 振冲碎石桩复合地基在仪征15万m³超大型油罐地基中的应用[J]. 石油化工建设, 2005, 27(2): 18-21. (GAO Bing-xin, JIA Hong-cheng. The application of vibrating sinktube detritus pile composite ground in Yizheng 150000 m³ large oil tank foundation[J]. Petroleum and Chemical Construction, 2005, 27(2): 18-21(in Chinese))
[4]	陈仲颐, 周景星, 王洪瑾. 土力学[M]. 北京: 清华大学出版社, 1994. (CHEN Zhong-yi, ZHOU Jing-xing, WANG Hong-jin. Soil mechanics[M]. Beinjing: Tsinghua University Press, 1994. (in Chinese))
[5]	中国石化北京设计院. SH/T 3068—2007石油化工企业钢储罐地基基础设计规范[S]. 北京: 中国石油化工总公司, 1995. (Beijing Design Institute of China Sinopec Corp. SH/T 3068—2007 Design code for petrochemical enterprises steel tank foundation[S]. Beijing: China Petroleum & Chemical Corporation, 1995. (in Chinese))
[6]	JGJ 79—2002建筑地基处理技术规范[S]. 北京: 中国建筑工业出版社, 2002. (JGJ 79—2002 Technical code for groung treatment of buildings[S]. Beijing: China Architecture & Building Press, 2002. (in Chinese))
[7]	王长丹, 王旭, 聂彪, 等. 高饱和度黄土地基超大型储油罐CFG 桩复合地基承载性能试验研究[J]. 水利与建筑工程学报, 2008, 6(3): 47-50. (WANG Chang-dan, WANG Xu, NIE Biao, et al. Experimental study on bearing performance of CFG pile composite foundation of large oil tank in saturated loess stratum[J]. Journal of Water Resources and Architectural Engineering, 2008, 6(3): 47-50. (in Chinese))
