高水压条件下泥水盾构隧道开挖面支护压力特性分析

陈孟乔; 刘建坤; 肖军华; 田泽野

高水压条件下泥水盾构隧道开挖面支护压力特性分析 English Version

1. 北京交通大学土木建筑工程学院,北京 100044; 2. 南京工业大学土木工程学院,江苏南京 210009

基金项目: 国家自然科学基金项目（41171064）

详细信息

作者简介:
陈孟乔(1985- )，男，河北秦皇岛人，博士研究生，主要从事城市轨道工程方面的研究。E-mail: mengqiaochen@126.com。

中图分类号: U451
计量
- 文章访问数: 0273
- HTML全文浏览量: 0
- PDF下载量: 03368
出版历程
- 收稿日期: 2013-06-06
- 发布日期: 2013-11-24

Face supporting pressure of slurry shield tunnel under high hydraulic pressure

1. School of Civil Engineering, Beijing Jiaotong University, Beijing 100044, China; 2. School of Civil Engineering, Nanjing University of Technology, Nanjing 210009, China

摘要

摘要: 高水压条件下,泥水盾构隧道施工过程中开挖面支护压力对开挖面稳定性和地层变形的影响很大。结合南京地铁3号线浦珠路站—滨江路站区间过江隧道工程,建立了模拟盾构隧道开挖面失稳过程的数值模型,研究了开挖面支护压力与土体变形之间的关系以及相关参数对其影响。研究表明,相比于无水压的情况,高水压条件下开挖面前方土体发生较小位移时开挖面支护压力就达到极限值,且极限值增大约一个量级,开挖面更易失稳。随着内摩擦角、水位和隧道直径的增大,开挖面极限支护压力比增大,开挖面稳定性降低,但变化趋势逐渐变缓,开挖面极限支护压力比与内摩擦角、水位呈抛物线形式,与隧道直径呈幂函数形式。随着黏聚力、埋深的增大,开挖面极限支护压力比减小,开挖面稳定性升高,但变化趋势逐渐变缓,呈抛物线形式。弹性模量对开挖面稳定性几乎没有影响。研究结果可为高水压条件下盾构隧道施工中合理确定支护压力提供参考。
- 盾构隧道 /
- 开挖面稳定 /
- 支护压力 /
- 高水压
Abstract: Face supporting pressure has great influence on face stability and ground deformation under high hydraulic pressure during slurry shield tunneling. Based on the under-river tunneling project of Nanjing Metro Puzhulu-Binjianglu interval, a numerical model is established to simulate the process of instability, the relation between face supporting pressure and soil deformation and the impact of relevant parameters are studied. The results show that, compared the case without no hydraulic pressure, the limit supporting pressure is reached when smaller soil displacement has occurred and the value the much greater under high hydraulic pressure. The ratio of the limit supporting pressure increases and the face stability decreases with the increase of the internal friction angle, water levle and tunnel diameter. The relation curve of the limit supporting pressure and the internal friction angle (water level) is parabola, and that of the limit supporting pressure and tunnel the diameter is power function. The ratio of the limit supporting pressure decreases and the face stability increases with the increase of the cohesion and tunnel depth. The relation curve of the limit supporting pressure and cohesion (tunnel depth) is parabola (power function). The elastic modulus has almost no effect on the face stability. The research may provide a reference for the determination of face supporting pressure during slurry shield tunneling under high hydraulic pressure.
- shield tunnel /
- face stability /
- supporting pressure /
- high hydraulic pressure

HTML全文

参考文献(8)

[1]	ANAGNOSTOU G, KOVARI K. The face stability of slurry shield driving tunnels[J]. Tunnelling and Underground Space Technology, 1994, 9(2): 165-174.
[2]	ANAGNOSTOU G, KOVARI K. Face stability conditions with earth-pressure-balanced shields[J]. Tunnelling and Underground Space Technology, 1996, 11(2): 166-173.
[3]	CHAMBON P, CONE J F. Shallow tunnels in cohesionless soil: Stability of tunnel face[J]. Journal of Geotechnical Engineering, 1994, 120(7): 1148-1165.
[4]	朱伟, 秦建设, 卢廷浩. 砂土中盾构开挖面变形与破坏数值模拟研究[J]. 岩土工程学报, 2005, 27(8): 897-902. (ZHU Wei, QIN Jian-she, LU Ting-hao. Numerical study on face movement and collapse around shield tunnels in sand[J]. Chinese Journal of Geotechnical Engineering, 2005, 27(8): 897-902. (in Chinese))
[5]	黄正荣, 朱伟, 梁精华, 等. 浅埋砂土中盾构法隧道开挖面极限支护压力及稳定研究[J]. 岩土工程学报, 2006, 28(11): 2005-2009. (HUANG Zheng-rong, ZHU Wei, LIANG Jing-hua, et al. Study on limit supporting pressure and stabilization of excavation face for shallow shield tunnels in sand[J]. Chinese Journal of Geotechnical Engineering, 2006, 28(11): 2005-2009. (in Chinese))
[6]	黄正荣, 朱伟, 梁精华, 等. 盾构法隧道开挖面极限支护压力研究[J]. 土木工程学报, 2006, 39(10): 112-116. (HUANG Zheng-rong, ZHU Wei, LIANG Jing-hua, et al. A study on the limit support pressure at excavation face of shield tunneling[J]. China Civil Engineering Journal, 2006, 39(10): 112-116. (in Chinese))
[7]	方勇, 何川. 土压平衡式盾构掘削面支护压力特性分析[J]. 岩土力学, 2009, 30(11): 3528-3532. (FANG Yong, HE Chuan. Analysis of cutting face support pressure for earth pressure balance shield tunneling[J]. Rock and Soil Mechanics, 2009, 30(11): 3528-3532. (in Chinese))
[8]	魏纲. 顶管工程土与结构的形状及理论研究[D]. 杭州: 浙江大学, 2005. (WEI Gang. Theoretical study on properties of soil and structure during pipe jacking construction[D]. Hangzhou: Zhejiang University, 2005. (in Chinese))
