坑中坑开挖对悬臂式支护结构侧移的影响分析

丰土根; 熊中华; 余波

坑中坑开挖对悬臂式支护结构侧移的影响分析 English Version

丰土根^{1, 2},
熊中华^1,2,,
余波^{1, 2}

1. 河海大学岩土力学与堤坝工程教育部重点实验室,江苏南京 210098; 2. 河海大学岩土工程科学研究所,江苏南京 210098

基金项目: 国家自然科学基金项目（51009054）；教育部科学技术研究重点项目（109077）；江苏省自然科学基金项目（BK2010513）

详细信息

作者简介:
丰土根（1975- ），男，浙江金华人，博士后，教授，主要从事岩土工程教学科研工作。E-mail: tgfeng75@163.com。

通讯作者:
熊中华

中图分类号: TU470
计量
- 文章访问数: 0278
- HTML全文浏览量: 0
- PDF下载量: 0250
出版历程
- 收稿日期: 2013-04-21
- 发布日期: 2013-11-19

Influence of pit-in-pit excavation on lateral deformation of cantilever retaining structure

FENG Tu-gen^{1, 2},
XIONG Zhong-hua^1,2,,
YU Bo^{1, 2}

1. Key Laboratory of Ministry of Education of Geomechanics and Embankment Engineering, Hohai University, Nanjing 210098, China; 2. Research Institute of Geotechnical Engineering, Hohai University, Nanjing 210098, China

摘要

摘要: 悬臂式支护结构比内撑式支护结构对变形更为敏感,坑中坑开挖将对悬臂式支护结构侧移产生较大影响。利用有限元计算程序,建立坑中坑有限元模型并作全面数值模拟研究,得到了坑中坑不同开挖位置、深度及大小对围护结构变形的影响规律,并探讨了相应的变形控制措施。结果表明：外坑围护结构最大侧移随坑趾系数的增大而减小,并且坑趾系数存在临界值,最大侧移随着深度比和面积比的增大而增大；围护结构侧移受深度比影响最大,坑趾系数次之,面积比最小；增大内坑围护结构刚度和入土深度对抑制外坑围护结构变形增大的作用不明显,相反,内坑设置支撑能起到显著的作用。
- 悬臂式支护结构 /
- 坑中坑 /
- 坑趾系数 /
- 面积比 /
- 深度比 /
- 有限元
Abstract: The cantilever retaining structure is more sensitive to the deformation than the internal bracing retaining structure. The excavation of pit-in-pit will bring great impact on the cantilever retaining structure. By using the finite element program to establish pit-in-pit models and to perform comprehensive numerical simulation studies, the deformation characteristics of the outer pit are studied in the cases of different positions, depths and areas of the inner pit excavation. Moreover, the measures to control the deformation are also discussed. The results show that the maximum lateral deformation on cantilever retaining structure increases with the decrease of pit toe coefficient which has a critical value. However, they perform completely opposite in terms of depth ratio and area ratio. The depth ratio has the greatest impact on the lateral deformation of cantilever retaining structure, while the area ratio has the least impact on it. The increase of the stiffness and embedded depth of cantilever retaining structure has no significant effect in inhibiting the increase of the deformation of the retaining structure of the outer pit. However, it performs completely opposite if the inner pit has internal bracing.
- cantilever retaining structure /
- pit-in-pit /
- pit toe coefficient /
- area ratio /
- depth ratio /
- finite element

HTML全文

参考文献(10)

[1]	JGJ 120—99 建筑基坑支护技术规程[S]. 1999. (JGJ 120—99 Technical specification for retaining and protection of building foundation excavations[S]. 1999. (in Chinese))
[2]	CECS 96：97 基坑土钉支护技术规程[S]. 1997. (CECS 96: 97 Specification for soil nailing in foundation excavations[S]. 1997. (in Chinese))
[3]	DG.TJ 08—61—2010 基坑工程技术规范[S]. 上海, 2010. (DG.TJ 08—61—2010 Technical code for excavation engineering[S]. Shanghai, 2010. (in Chinese))
[4]	徐为民, 屠毓敏. 某工程坑中坑塌滑原因分析及加固设计 [J]. 岩土力学, 2010, 31(5): 1555-1559. (XU Wei-min, TU Yu-min. Landslide analysis and reinforcement design of the pit-in-pit[J]. Rock and Soil Mechanics, 2010, 31(5): 1555-1559. (in Chinese))
[5]	付文光, 杨志银, 刘俊岩, 等. 复合土钉墙的若干理论问题、兼论《复合土钉墙基坑支护技术规范》[J]. 岩石力学与工程学报, 2012, 31(11): 2291-2304. (FU Wen-guang, YANG Zhi-yin, LIU Jun-yan, et al. Some theoretical questions of composite soil nailing wall and discussion on technical code for composite soil nailing wall in retaining and protection of excavation[J]. Chinese Journal of Rock Mechanics and Engineering, 2012, 31(11): 2291-2304. (in Chinese))
[6]	龚晓南. 关于基坑工程的几点思考[J]. 土木工程学报, 2005, 38(9): 99-102. (GONG Xiao-nan. Considerations on foundation pit engineering[J]. China Civil Engineering Journal, 2005, 38(9): 99-102. (in Chinese))
[7]	吴铭炳, 林大丰, 戴一鸣, 等. 坑中坑基坑支护设计与监测[J]. 岩土工程学报, 2006, 28(增刊): 1570-1572. (WU Ming-bing, LIN Da-feng, DAI Yi-ming, et al. Design and monitoring of retaining of pits in foudation-pit[J]. Chinese Journal of Geotechnical Engineering, 2006, 28(S0): 1570-1572. (in Chinese))
[8]	陈畅, 邸国恩, 王卫东. 软土基坑工程坑中坑支护的设计方法[J]. 岩土工程学报, 2008, 30(增刊): 286-290. (CHEN Chang, DI Guo-en, WANG Wei-dong. Design of retaining system of local deep excavations in foundation pits in soft ground[J]. Chinese Journal of Geotechnical Engineering, 2008, 30(S0): 286-290. (in Chinese))
[9]	申明亮, 廖少明, 周小华, 等. 坑中坑基坑应力场的参数化分析[J]. 岩土工程学报, 2010, 32(增刊): 187-191. (SHEN Ming-liang, LIAO Shao-ming, ZHOU Xiao-hua, et al. Parametric analysis on stress field of pit in pit excavation[J]. Chinese Journal of Geotechnical Engineering, 2010, 32(S0): 187-191. (in Chinese))
[10]	徐意智, 廖少明, 周小华, 等. 上海软土坑中坑型基坑围护的等效深度计算法[J]. 岩土力学, 2012, 33(9): 2736-2742. (XU Yi-zhi, LIAO Shao-ming, ZHOU Xiao-hua. A computation method of equivalent depth for pit-in-pit excavation structural design in soft ground of Shanghai[J]. Rock and Soil Mechanics, 2012, 33(9): 2736-2742. (in Chinese))
