基于流形方法和图论算法的岩/土质边坡稳定性分析

郑文博; 庄晓莹; 李耀基; 蔡永昌

基于流形方法和图论算法的岩/土质边坡稳定性分析 English Version

1. 同济大学地下建筑与工程系,上海 200092; 2. 云南磷化集团有限公司,云南昆明 650600

基金项目: 国家自然科学基金项目（51109162）

详细信息

作者简介:
郑文博(1988- )，男，广东揭阳人，硕士研究生，主要从事岩石力学和边坡稳定性的研究。E-mail: 2006wbzheng@tongji.edu.cn。

通讯作者:
庄晓莹

中图分类号: TU47
计量
- 文章访问数: 377
- HTML全文浏览量: 2
- PDF下载量: 743
出版历程
- 收稿日期: 2013-03-21
- 发布日期: 2013-11-19

Graph theory for stability analysis of rock/soil slopes based on numerical manifold method

1. Key Laboratory of Geotechnical and Underground Engineering of Ministry of Education, Department of Geotechnical Engineering, Tongji University, Shanghai 20092, China; 2. Yunnan Phosphate Chemical Group Co., Ltd., Kunming 650600, China

摘要

摘要: 目前边坡稳定性分析常用的极限平衡法存在着不能考虑实际岩土体的应力应变关系,假设过多等缺点,强度折减法也存在着需要重复计算工作量大,计算容易不收敛,难以考虑边坡应力路径影响及较难直接得到滑裂面等不足。从边坡的应力状态出发,借助基于物理覆盖系统、能较好统一连续和不连续分析的数值流形方法,得到土质边坡或存在着较多不连续面的岩质边坡的应力场分布,并将边坡稳定性分析转化为图论问题,利用Bellman-Ford搜索算法快速稳定地寻找出边坡的安全系数和最危险滑裂面。该方法无需做过多假设及迭代计算,可以反映边坡的应力路径影响,较好地统一岩质/土质边坡稳定性分析。
- 岩/土质边坡 /
- 稳定性分析 /
- 数值流形方法 /
- 图论
Abstract: The widely-used analysis methods for slope stability based on the limit equilibrium conditions have limitations. In the limit equilibrium method, the constitutive model for soils or rocks cannot be considered, and assumptions are needed between slices of soils/rocks. The strength reduction method, another dominant method for slope stability analysis, requires iterative calculations and cannot represent the effect of stress paths. Besides, it does not give the slip surface directly. Based on the current stress state of slopes, the numerical manifold method, which can unify the continuum analysis and discontinuum analysis with its dual covers, is adopted to calculate the stress distributions of soil slopes or rock slopes with joints. Then the slope stability analysis is converted to a graph problem, and the Bellman-Ford algorithm is used to obtain the slip surface and the safety factor which is defined as the ratio of the resistant force and the slip force along the slip surface. The proposed method removes the difficulties in iterative calculations and unifies the stability analysis of rock/soil slopes, and is capable of including the effects of stress paths.
- rock/soil slope /
- stability analysis /
- numerical manifold method /
- graph theory

HTML全文

参考文献(13)

[1]	郑宏, 田斌, 刘德富, 等. 关于有限元边坡稳定性分析中安全系数的定义问题[J]. 岩石力学与工程学报, 2005, 24(13): 2225-2230. (ZHENG Hong, TIAN Bin, LIU De-fu, et al. On definitions of safety factor of slope stability analysis with finite element method[J]. Chinese Journal of Rock Mechanics and Engineering, 2005, 24(13): 2225-2230. (in Chinese))
[2]	陈祖煜. 土质边坡稳定分析——原理方法程序[M]. 北京: 中国水利水电出版社, 2003. (CHEN Zhu-yu. Stability analysis of soil slopes——theory, methods and programs[M]. Beijing: China Water Power Press, 2003. (in Chinese))
[3]	陈祖煜, 汪小刚, 杨健, 等. 岩质边坡稳定分析——原理方法程序[M]. 北京: 中国水利水电出版社, 2005. (CHEN Zu-yu, WANG Xiao-gang, YANG Jian, et al. Rock slope stability analysis——theory, methods and programs[M]. Beijing: China Water Power Press, 2005. (in Chinese))
[4]	付强. 有限元塑性极限分析法在黄土高边坡稳定性方面的应用[D]. 兰州: 兰州理工大学, 2007. (FU Qiang. High loess slope stability analysis by plastic limit analysis method using finite element method[D]. Lanzhou: Lanzhou University of Technology, 2007. (in Chinese))
[5]	郑颖人, 赵尚毅. 有限元强度折减法在土坡与岩坡中的应用[J]. 岩石力学与工程学报, 2004, 23(19): 3381-3388. (ZHENG Ying-ren, ZHAO Shang-yi. Application of strength reduction fem in soil and rock slope[J]. Chinese Journal of Rock Mechanics and Engineering, 2004, 23(19): 3381-3388. (in Chinese))
[6]	郑颖人, 赵尚毅. 岩土工程极限分析有限元法及其应用[J]. 土木工程学报, 2005, 38(1): 91-104. (ZHENG Ying-ren, ZHAO Shang-yi. Limit state finite element method for geotechnical engineering analysis and its applications[J]. China Civil Engineering Journal, 2005, 38(1): 91-104. (In Chinese))
[7]	李育超. 基于实际应力状态的土质边坡稳定分析研究[D]. 杭州: 浙江大学, 2006. (LI Yu-chao. Stability analysis of soil slopes under actual stress state[D]. Hangzhou: Zhejiang University, 2006. (in Chinese))
[8]	SHI G H. Manifold method of material analysis[C]// Transaction of the Ninth Army Conference on Applied Mathematics and Computing. Minneapolis. Minnesota, 1991.
[9]	庄晓莹, 朱合华, 蔡永昌, 等. 基于无网格-图论方法的岩体边坡稳定性分析研究[J]. 力学季刊, 2008, 29(4): 537-543. (ZHUANG Xiao-ying, CAI Yong-chang, ZHU He-hua, et al. Rock slope stability analysis based on meshless method and shortest path algorithms[J]. Chinese Quarterly of Mechanics, 2008, 29(4): 537-543. (in Chinese))
[10]	DONALD I B, GIAM P. The ACADS slope stability programs review[C]// 6th International Symposium on Landslides, 1992: 1665-1670.
[11]	郑宏, 李春光, 李焯芬, 等. 求解安全系数的有限元法[J]. 岩土工程学报, 2002, 24(5): 626-628. (ZHENG Hong, LI Chun-guang, LEE Chao-feng, et al. Finite element method for solving the factor of safety[J]. Chinese Journal of Geotechnical Engineering, 2002, 24(5): 626-628. (in Chinese))
[12]	李连崇, 唐春安, 刑军, 等.节理岩体边坡变形破坏的FRPA分析[J]. 东北大学学报(自然科学版),2006, 21(5): 559-561. (LI Lian-chong, TANG Chun-an, XING Jun, et al. Numerical simulation and analysis of deformation and failure of jointed rock slopes by RFPA-slope[J]. Journal of Northeastern University (Natural Science), 2006, 21(5): 559-561. (in Chinese))
[13]	朱伯芳. 有限单元法原理与应用[M]. 北京: 中国水利水电出版社, 1998. (ZHU Bo-fang. The finite element method theory and applications[M]. Beijing: China Water Power Press, 1998. (in Chinese))
