桩承式路堤中土拱效应产生机理研究

庄妍, 崔晓艳, 刘汉龙

庄妍, 崔晓艳, 刘汉龙. 桩承式路堤中土拱效应产生机理研究[J]. 岩土工程学报, 2013, 35(zk1): 118-123.
引用本文: 庄妍, 崔晓艳, 刘汉龙. 桩承式路堤中土拱效应产生机理研究[J]. 岩土工程学报, 2013, 35(zk1): 118-123.
shu
ZHUANG Yan, CUI Xiao-yan, LIU Han-long. 3D FE analysis of arching in a piled embankment[J]. Chinese Journal of Geotechnical Engineering, 2013, 35(zk1): 118-123.
Citation: ZHUANG Yan, CUI Xiao-yan, LIU Han-long. 3D FE analysis of arching in a piled embankment[J]. Chinese Journal of Geotechnical Engineering, 2013, 35(zk1): 118-123.
shu

桩承式路堤中土拱效应产生机理研究  English Version

  • 1. 岩土力学与堤坝工程教育部重点实验室，江苏 南京 210098；2. 河海大学岩土工程科学研究所，江苏 南京 210098

基金项目: 国家自然科学基金高铁联合基金项目（U1134207）；国家自然科学基金青年项目（51108155）；江苏省“333”计划资助项目（BRA2011146）；中国博士后科学基金面上资助项目（2012M511670）
详细信息
    作者简介:

    庄 妍(1982- )，女，博士，副教授，主要从事软基处理方面的教学与科研工作。E-mail: Joanna_zhuang@163.com。

  • 中图分类号: TU470

3D FE analysis of arching in a piled embankment

  • 1. Key Laboratory of Ministry of Education for Geomechanics and Embankment Engineering, Nanjing 210000, China; 2. Geotechnical Research Institute, Hohai University; Nanjing 210000, China

摘要

    摘要
  • 摘要: 土拱效应的形成条件和荷载传递机理是刚性桩复合地基桩-土协调共同作用的关键性技术问题。基于ABAQUS三维有限元数值软件，研究路堤填土性质、路堤高度、桩间距等因素对土拱效应的形成和荷载传递特性的影响规律，分析路堤以及软土中应力和应变发展规律。研究结果表明：路堤高度h与桩间距s比值对土拱效应产生具有重要影响，当h / s ≤ 0.5时，没有土拱效应产生；当0.5 ≤ h / s ≤ 1.5时，土拱效应没有完全产生；当1.5 ≤ h / s时，产生完整的土拱效应；桩承式路堤中最大拱效应发挥作用时，桩间土所受竖向极限应力与路堤填土自重比值σs,ult /γh约在0.2～0.4之间；土拱效应作用下，路堤填料中土体发生破坏的部位与桩间距和土体性质有关。
    Abstract: There is no a generally accepted approach for the design of piled embankments. A series of three-dimensional finite element analyses are presented to examine the performance of piled embankments. The analyses show that when h/ s≤ 0.5, there is virtually no effect of arching, when 0.5 ≤ h/ s≤ 1.5, there is an increasing evidence of arching, and when 1.5 ≤ h/ s, full arching is observed. The ultimate stress on the subsoil (σs,ult) at the point of maximum arching normalized by γh. ranges 20% to 40 %.
    • HTML全文
    • 参考文献(1)
  • TERZAGHI K. Theoretical soil mechanics[M]. New York: JohnWiley and Son, 1943: 66-75.
    GUIDO V A,KNEUPPEL J D,SWEENEY M A. Plate loading tests on geogrid-reinforced earth slabs[C]// Proceeding. Geosynthetics’87 Conference. New Orleans, 1987: 216-225.
    HEWLETT W J,RANDOLPH M F. Analysis of piled embankments[J]. Ground Engineering, 1988, 21(3): 12-18.
    British Standard BS 8006. Code of practice for strengthened reinforced soils and other fills[S]. London: British Standard Institution 8006. Code of practice for strengthened reinforced soils and other fills[S]. London: British Standard Institution, 1995.
    MARSTON A,ANDERSON A O. The theory of loads on pipes in ditches and tests of cement and clay drain tile and sewer pipe[R]. Ames Iowa: Iowa Engineering Experiment Station Bulletin, Iowa State College, 1913.
    刘吉福. 路堤下复合地基桩、土应力比分析[J]. (岩石力学与工程学报), 2003, 22(4): 674-677.(LIU Ji-fu. Analysis on pile-soil stress ratio for composite ground under embankment[J]. Chinese Journal of Rock Mechanics and Engineering, 2003, 22(4): 674-677. (in Chinese))
    陈仁朋,贾 宁,陈云敏. 桩承式加筋路堤受力机制及沉降分析[J]. (岩石力学与工程学报), 2005, 24(23): 358-4367.(CHEN Ren-peng,JIA Ning,CHEN Yun-min. Mechanism and settlement analysis of pile-supported and geogrid-reinforced embankments[J]. Chinese Journal of Rock Mechanics and Engineering, 2005, 24(23): 358-4367. (in Chinese))
    ELLIS E A. ASLAM R. Arching in piled embankments: Comparison of centrifuge tests and predictive methods - Part 1 of 2[J]. Ground Engineering, 2009(6): 34-38.
    ELLIS E A,ASLAM R. Arching in piled embankments: comparison of centrifuge tests and predictive methods - Part 2 of 2[J]. Ground Engineering, 2009(7): 28-31.
    余 闯,刘松玉,杜广印,等. 桩承式路堤土拱效应的三维数值模拟[J]. (东南大学学报(自然科学版)), 2009, 39(1): 58-62.(YU Chuang,LIU Song-yu,DU Guang-yin,et al. Three dimensional simulations on soil arching of piled embankment[J]. Journal of Southeast University (Natural Science Edition) 2009, 39(1): 58-62. (in Chinese))
    费 康,王军军,陈 毅. 桩承式路堤土拱效应的试验和数值研究[J]. (岩土力学), 2011, 32(7): 1975-1983.(FEI Kang,WANG Jun-jun,CHAEN Yi. Experimental and numerical studies of soil arching in piled embankment[J]. Rock and Soil Mechanics, 2011, 32(7): 1975-1983. (in Chinese))
    IGLESIA G R,EINSTEIN H H,WHITMAN R V. Determination of vertical loading on underground structures based on an arching evolution concept[M]// FERNANDEZ C, BAUER R A, ed. Geo-Engineering for Underground Facilities. Reston: Geo-Insitute of the American Society of Civil Engineers (ASCE), 1999: 495-506 .
    POTTS V J,ZDRAVKOVIC L. Finite element analysis of arching behaviour in soils[C]// The 12th International Conference of International Association for Computer Methods and Advances in Geomechanics (IACMAG). Goa, India, 2008: 3642-3649.
