渗流条件下三维盾构隧道开挖面极限支护压力

吕玺琳; 李冯缔; 黄茂松; 焦齐柱; 胡雯婷

渗流条件下三维盾构隧道开挖面极限支护压力 English Version

吕玺琳^{1, 2},
李冯缔^{1, 2},
黄茂松^{1, 2},
焦齐柱³,
胡雯婷^{1, 2}

1. 同济大学地下建筑与工程系，上海 200092；2. 同济大学岩土及地下工程教育部重点实验室，上海 200092；3. 中铁第四勘察设计院集团有限公司，湖北武汉430063

基金项目: 国家杰出青年科学基金项目（50825803）；国家自然科学基金青年科学基金项目（50908171）；交通部科技项目（2009-353-333-340）

详细信息

作者简介:
吕玺琳(1981- )，男，重庆人，博士，副教授，从事岩土力学与工程方面研究。E-mail: xilinlu@tongji.edu.cn。

中图分类号: TU91
计量
- 文章访问数: 0516
- HTML全文浏览量: 0
- PDF下载量: 0507
出版历程
- 收稿日期: 2013-03-02
- 发布日期: 2013-07-18

3D limit support pressure solution for shield tunnel face subjected to seepage

Lü Xi-lin^{1, 2},
LI Feng-di^{1, 2},
HUANG Mao-song^{1, 2},
JIAO Qi-zhu³,
HU Wen-ting^{1, 2}

1. Department of Geotechnical Engineering, Tongji University, Shanghai 200092, China; 2. Key Laboratory of Geotechnical and Underground Engineering of Ministry of Education, Tongji University, Shanghai 200092, China; 3.China Railway Siyuan Survey and Design Group Co., Ltd., Wuhan 430063, China

摘要

摘要: 通过有限元数值模拟，对水位变化条件下盾构隧道开挖面的孔压分布特性进行了研究，并进一步分析了水位高度、隧道直径和隧道埋深对开挖面渗流力的影响，结果表明开挖面平均渗流力与水位高度近似呈线性关系。基于梯形楔形体模型，结合渗流数值模拟结果获得楔形体滑块边界上的平均渗流力，建立了考虑渗流影响的隧道开挖面总极限支护压力计算公式。与不考虑渗流影响的支护压力对比表明，总支护压力大部分用于平衡渗流力，且总支护压力随水位高度近似呈线性增长。将建立的模型用于钱江隧道工程，通过选取5个典型截面计算支护压力，获得了钱江隧道极限支护压力的变化规律。
- 盾构隧道 /
- 开挖面稳定 /
- 支护压力 /
- 楔形体模型 /
- 渗流
Abstract: By adopting FE numerical simulation, the influence of water table line on the distribution of pore water pressure around the shield tunnel face is studied, and the influences of water table line, tunnel diameter, tunnel depth on the seepage force are obtained. The results show that the seepage force varies almost linearly with the water table line. By considering the average seepage force on the slide block, the face stability of shield tunnels is studied via trapezoidal wedge model, and a formula to calculate the limit support pressure under seepage condition is deduced. The seepage force shows great influence on the limit support pressure, and the total support pressure increases almost linearly with the water table line. The proposed model is used for the Qianjiang river shield tunnel project to calculate the limit support pressure of 5 selected typical sections, and the variation of support pressure is obtained.
- shield tunnel /
- face stability /
- support pressure /
- wedge model /
- seepage

HTML全文

参考文献(1)

吕玺琳,王浩然,黄茂松. 盾构隧道开挖面稳定性极限理论分析[J]. (岩土工程学报), 2011, 33(1): 57-62.(Lü Xi-lin,WANG Hao-ran,HUNAG Mao-song. Study on the face stability of shield tunnel in limit theory[J].Lü Xi-lin, WANG Hao-ran, HUNAG Mao-song. Study on the face stability of shield tunnel in limit theory[J]. Chinese Journal of Geotechnical Engineering, 2011, 33(1): 57-62. (in Chinese))
吕玺琳,李冯缔,黄茂松,等. 三维盾构隧道开挖面极限支护压力数值及理论解[J]. (同济大学学报(自然科学版)), 2012, 40(10): 1469-1473.(LU Xi-lin,LI Feng-di,HUANG Mao-song,et al. Three-dimensional numerical and analytical solutions of limit support pressure at shield tunnel face[J]. Journal of Tongji University(Natural Science), 2012, 40(10): 1469-1473. (in Chinese))
ANAGNOSTOU G,KOVáRI K. Face stability conditions with earth-pressure-balanced shields[J]. KOVáRI K. Face stability conditions with earth-pressure-balanced shields[J]. Tunnelling and Underground Space Technology, 1996, 11(2): 165-173.
DE Buhan P,CUVILLIER A,DORMIEUX L,et al. Face stability of shallow circular tunnels driven under the water table: a numerical analysis[J]. International Journal for Numerical and Analytical Methods in Geomechanics, 1999, 23(1): 79-95.
BROERE W,VAN TOl A. Influence of infiltration and groundwater flow on tunnel face stability[C]// Geotechnical Aspects of Underground Construction in Soft Ground. Tokyo, 2000: 339-344.
SCHWEIGER H F,POTTLER R K,Steiner H. Effect of seepage forces on the shotcrete lining of a large undersea cavern[C]// Int Conf Computer Methods and Advances in Geomechanics. Rotterdam: Balkema, 1991: 1503-1508.
LEE I M,NAM S W. The study of seepage forces acting on the tunnel lining and tunnel face in shallow tunnels[J]. Tunnelling and Underground Space Technology, 2001, 16(1): 31-40.
高健,张义同,乔金丽. 渗透力对隧道开挖面稳定性影响分析[J]. (岩土工程学报), 2009, 31(10): 1547-1553.(GAO Jian,ZHANG Yi-tong,QIAO Jin-li. Face stability analysis of tunnels with consideration of seepage force[J]. Chinese Journal of Geotechnical Engineering, 2009, 31(10): 1547-1553 (in Chinese))
陈祖煜. 关于“渗流作用下土坡圆弧滑动有限元计算”的讨论之一[J]. (岩土工程学报), 2002, 24(3): 394-396.(CHEN Zu-yu. Comments on “Finite element calculation on circular slip of earth slope under seepage action”[J]. Chinese Journal of Geotechnical Engineering, 2002, 24(3): 394-396 (in Chinese))
胡雯婷,吕玺琳,黄茂松. 盾构隧道开挖面极限支护压力三维极限平衡解[J]. (地下空间与工程学报), 2011, 7(5): 853-856.(HU Wen-ting,Lü Xi-lin,HUANG Mao-song. Three-dimensional limit equilibrium solution of the support pressure on the shield tunnel face[J]. Lü Xi-lin, HUANG Mao-song. Three-dimensional limit equilibrium solution of the support pressure on the shield tunnel face[J]. Chinese Journal of Underground Space and Engineering, 2011, 7(5): 853-856. (in Chinese))
胡雯婷. 考虑渗流的盾构隧道开挖面三维稳定分析[D]. 上海: 同济大学, 2012.(HU Weng-ting. Three dimentional stability analysis of shield tunnel excavation face with the consideration of seepage[D]. Shanghai: Tongji University, 2012. (in Chinese))
