小净距平行盾构隧道施工先行隧道管片附加应力监测研究

张明聚; 赵明; 王鹏程; 贾大鹏; 刘义; 杜永骁

小净距平行盾构隧道施工先行隧道管片附加应力监测研究 English Version

1. 北京工业大学城市与工程安全减灾省部共建教育部重点实验室，北京 100124; 2. 中铁十二局集团有限公司，山西太原 030032

基金项目: 国家自然科学基金项目(50678002)

详细信息

作者简介:
张明聚(1962– )，男，教授，博士生导师，主要从事城市地下工程方面的教学、科研和技术开发。E-mail: zhangmj@bjut.edu.cn

中图分类号: U451
计量
- 文章访问数: 1032
- HTML全文浏览量: 5
- PDF下载量: 452
出版历程
- 收稿日期: 2012-01-05
- 发布日期: 2012-12-19

Field tests and researches on secondary stresses of advanced tunnel segments during parallel shield tunnels driving in close proximity

1.The Key Laboratory of Urban Security and Disaster Engineering ( Beijing University of Technology), Ministry of Education, Beijing 100124, China; 2. China Railway 12th Bureau Group Co., Ltd., Taiyuan 030032, China;

摘要

摘要: 通过现场监测,研究揭示小净距平行盾构隧道施工中后行隧道掘进引起的先行隧道管片附加应力的变化规律.介绍了管片附加应力测点布置及监测方法,分析给出了管片附加应力动态变化规律,研究了附加应力与后行隧道掘进距离的关系,对管片附加应力的最大值和稳定值进行了统计分析.监测结果表明,当后行隧道掘进到监测断面附近时,附加应力有突变量,水平直径处环向受到压力作用,环向应力的量值比纵向应力大.以期能为评价小净距盾构隧道施工相互影响程度及该类盾构隧道设计,施工提供参考依据.
- 盾构隧道 /
- 小净距盾构掘进 /
- 附加应力 /
- 现场监测
Abstract: The change rules of the secondary stresses of advanced tunnel segment induced by parallel shield tunnels dirving in close proximity are studied by field tests. The layout of the measured points and the field test methods are introduced, and the change rules of the secondary stresses are analyzed. Furthermore, the relationship between the secondary stresses and the distance of the shield driving face to the measured section are studied. Statistical analyses of the maximum and the stabilized magnitudes of the secondary stresses are carried out. The results of the field tests show that there will be sharp change of the secondary stresses when the hind shield is driven to the measured section, the circumferential secondary stresses in the intersection of horizontal diameter with circumference of the tunnel will be laid, and the magnitudes of the circumferential secondary stresses will be greater than those of the longitudinal secondary stresses. The results may be applied to the quantitative assessment of the construction interaction of shield tunnels in close proximity and is regarded as references to the design and construction of this kind of shield tunnels.
- shield tunnel /
- parallel shield tunnels driving in close proximity /
- secondary stress /
- field test

HTML全文

参考文献(13)

[1]	TB100032—#2004 铁路隧道设计规范[S]. 北京: 中国铁道出版社, 2004. TB1000322004 Code for design of railway tunnel[S]. Beijing: China Railway Publishing House, 2004. (in Chinese))
[2]	YAMAGUCHI I, YAMAZAKI I, KIRITANI Y. Study of ground-tunnel interactions of four shield tunnels driven in close proximity, in relation to design and construction of parallel shield tunnels[J]. Tunnelling and Underground Space Technology, 1998, 13(3): 289-304
[3]	KOYAMA Yukinori. Present status and technology of shield tunneling method in Japan[J]. Tunnelling and Underground Space Technology, 2003, 18(2/3): 145-159
[4]	曾小清, 曹志远. 半解析数值法在地铁工程双线隧道分析中的应用[J]. 工程力学, 1998, 15(1): 46-52. (ZENG Xiao-qing, CAO Zhi-yuan. Application of semi-analytical numerical method to double-tube tunnel structures[J]. Engineering Mechanics, 1998, 15(1)
[5]	姜忻良, 贾勇, 王涛. 近距离平行隧道盾构施工对老隧道影响的数值模拟[J]. 天津大学学报, 2007, 40(7): 786-790 JIANG Xin-liang, JIA Yong, WANG Tao. Numerical simulation of influence of shield tunneling on short-distance parallel existing tunnel[J]. Journal of Tianjin University, 2007, 40(7): 786-790. (in Chinese))
[6]	方勇, 何川. 平行盾构隧道施工对既有隧道影响的数值分析[J]. 岩土力学, 2007, 28(7): 1402-1406 FANG Yong, HE Chuan. Numerical analysis of effects of parallel shield tunneling on existent tunnel[J]. Rock and Soil Mechanics, 2007, 28(7): 1402-1406. (in Chinese))
[7]	林志, 朱合华, 夏才初. 双线盾构隧道施工过程相互影响的数值研究[J]. 地下空间与工程学报, 2009, 5(1): 85-89 LIN Zhi, ZHU He-hua, XIA Cai-chu. Numerical modeling study on interaction between twin shields tunneling[J]. Chinese Journal of Underground Space and Engineering, 2009, 5(1): 85-89. (in Chinese))
[8]	陶连金, 孙斌, 李晓霖. 超近距离双孔并行盾构施工的相互影响分析[J]. 岩石力学与工程学报, 2009, 28(9): 1856-1862 TAO Lian-jin, SUN Bin, LI Xiao-lin. Interaction analysis of double holes extremely close approaching parallel shield tunnels construction[J]. Chinese Journal of Rock Mechanics and Engineering, 2009, 28(9): 1856-1862. (in Chinese))
[9]	章慧健, 仇文革, 冯冀蒙. 小净距隧道夹岩力学特征分析[J]. 岩土工程学报, 2010, 32(3): 434-439 ZHANG Hui-jian, QIU Wen-ge, FENG Ji-meng. Mechanical performance of shared rock of neighborhood tunnels[J]. Chinese Journal of Geotechnical Engineering, 2010, 32(3): 434-439. (in Chinese))
[10]	凌昊, 仇文革, 孙兵, 等. 双孔盾构隧道近接施工离心模型试验研究[J]. 岩土力学, 2010, 31(9): 2849-2853 LING Hao, QIU Wen-ge, SUN Bing,,et al. Study of adjacent construction of two tube shield tunnels by centrifugal model test[J]. Rock and Soil Mechanics, 2010, 31(9): 2849-2853. (in Chinese))
[11]	何川, 苏宗贤, 曾东洋. 盾构隧道施工对已建平行隧道变形和附加内力的影响研究[J]. 岩石力学与工程学报, 2007, 26(10): 2063-2069 HE Chuan, SU Zong-xian, ZENG Dong-yang. Research on influence of shield tunnel construction on deformation and secondary inner force of constructed parallel tunnel[J]. Chinese Journal of Rock Mechanics and Engineering, 2007, 26(10): 2063-2069. (in Chinese))
[12]	邵华, 张子新. 盾构近距离穿越施工对已运营隧道的扰动影响分析[J]. 岩土力学, 2004, 25(增刊2): 545-549 SHAO Hua, ZHANG Zi-xin. Analysis of disturbing effect on running subway caused by adjacent shield-driven[J]. Rock and Soil Mechanics, 2004, 25(S2): 545-549. (in Chinese))
[13]	陈越峰, 张庆贺, 张颖, 等. 近距离三线并行盾构隧道施工实测分析[J]. 地下空间与工程学报, 2008, 4(2): 335-340 CHEN Yue-feng, ZHANG Qing-he, ZHANG Ying,,et al. In-situ monitoring and analyzing on construction of three closely spaced parallel pipe shield tunnels[J]. Chinese Journal of Underground Space and Engineering, 2008, 4(2): 335-340. (in Chinese))
