淤泥质黏土火灾高温下导热系数的试验研究

徐婕; 朱合华; 闫治国

淤泥质黏土火灾高温下导热系数的试验研究 English Version

徐婕^1,2,
朱合华^1,2,
闫治国^1,2

1. 同济大学岩土及地下工程教育部重点实验室，上海 200092; 2. 同济大学地下建筑与工程系，上海 200092

基金项目: 国家自然科学基金项目(50978197);教育部创新团队发展计划项目(IRT1029);上海市领军人才计划与曙光跟踪计划项目

详细信息

作者简介:
徐婕(1988– )，女，河南开封人，硕士研究生，主要从事隧道及地下工程防灾研究。E-mail: xujiexiaomo@yahoo.cn

中图分类号: TU411
计量
- 文章访问数: 01070
- HTML全文浏览量: 0
- PDF下载量: 0748
出版历程
- 收稿日期: 2011-11-13
- 发布日期: 2012-12-19

Experimental studies on coefficient of thermal conductivity of silty clay

XU Jie^1,2,
ZHU He-hua^1,2,
YAN Zhi-guo^1,2

1. Key Laboratory of Geotechnical and Underground Engineering of Ministry of Education, Tongji University, Shanghai 200092, China; 2. Department of Geotechnical Engineering, Tongji University, Shanghai 200092, China

摘要

摘要: 对火灾高温下隧道衬砌结构周围饱和软黏土的热传导特性进行了试验研究,旨在进一步探讨作用于隧道结构上的荷载变化,以便准确评价其安全状态.采用热探针程序法(美国材料与试验协会(ASTM)确定土体和软岩导热系数的标准方法),应用自行研制的高温土体导热系数测定仪测定了上海淤泥质黏土在高温下的导热系数.试验分别测定了不同温度及不同含水率条件下土样的导热系数,并以KD2导热系数测定仪作为校准仪器对试验结果进行了校正.试验结果表明导热系数随着温度的升高而增大,且其增大的速率随温度的增加而减小,特别是对含有机质的淤泥质黏土因有机质的高温分解而使得这种降低更加明显;此外,在不同高温下土体导热系数随含水率的增加而增大.
- 淤泥质黏土 /
- 高温 /
- 导热系数 /
- 热探针程序法
Abstract: The researches on heat conduction characteristics of soft soil under high temperature are performed for further determining the load change on tunnel lining structure surrounded by saturated soft soil and accurately evaluating its safety under high temperature of fire. The experiment adopts the method of thermal needle probe procedure, proposed by American Society for Testing and Materials (ASTM) as the standard method for determination of thermal conductivity of soil and soft rock, by using self-made apparatus for coefficient of thermal conductivity of soil to measure the coefficient of thermal conductivity of Shanghai mucky clay under high temperature. The thermal conductivity of soil samples with different water contents is measured respectively under different temperatures. At the same time, as calibrating instrument, the KD2 thermal conductivity measuring apparatus is used to calibrate the test results. The test results indicate that the thermal conductivity of soil with the same water content increases with the increase of temperatures. When the temperature is low, the increase rate of thermal conductivity of soil is higher, and when the temperature is high, the increase rate of thermal conductivity of soil is lower, which is more serious due to the decomposition of the organic soil under high temperatures. Further, the thermal conductivity of soil with the same temperature increases with the increase of water content.
- silty clay /
- high temperature /
- coefficient of thermal conductivity /
- thermal needle probe procedure

HTML全文

参考文献(20)

[1]	ONO K. Fire design requirements for various types of tunnel [M]. Seoul: Keynote Lecture of ITA WTC 2006, 2006.
[2]	SAVOV K, LACKNER R, MANG H A. Stability assessment of shallow tunnels subjected to fire load[J]. Fire Safety Journal, 2005, 40(8): 745-763
[3]	闫治国. 隧道衬砌结构火灾高温力学行为及耐火方法研究[D]. 上海: 同济大学, 2007. YAN Zhi-guo. A study on mechanical behaviors and fireproof methods of tunnel lining structure during and after fire scenarios[D]. Shanghai: Tongji University, 2007.
[4]	YAN Z G, ZHU H H. Experimental study on mechanical behaviors of tunnel lining under and after fire scenarios[C]// Proceedings of the 33rd ITA-AITES World Tunnel Congress, Prague, 2007: 1805-1809.
[5]	CUI Yu-jun, YE Wei-min. On modeling of thermo-mechanical volume change behavior of saturated clays[J]. Chinese Journal of Rock Mechanics and Engineering, 2005, 24(21): 3903-3910
[6]	HUECKEL T, BALDI G. Thermoplasticity of saturated clays: experimental constitutive study[J]. Journal of Geotechnical Engineering, 1990, 116(12): 1778-1796
[7]	TANAKA N, THOMAS J, CRILLLY G. Stress-strain behavior of reconstituted illicit clay at different temperatures[J]. Engineering Geology, 1997, 47: 339-350
[8]	蒋建平, 李晓昭, 高广运, 等. 南京地铁(融)土热物理参数试验研究[J]. 中国铁道科学, 2009, 30(1): 13-16 JIANG Jian-ping, LI Xiao-zhao, GAO Guang-yun,,et al. Experimental study on the thermophysical parameters of (thawed) soil in the foundation of Nanjing metro engineering[J]. China Railway Science, 2009, 30(1): 13-16.(in Chinese))
[9]	原喜忠, 李宁, 赵秀云, 等. 非饱和(冻)土导热系数预估模型研究[J]. 岩土力学, 2010, 31(9): 2689-2694 YUAN Xi-zhong, LI Ning, ZHAO Xiu-yun,,et al. Study of thermal conductivity model for unsaturated unfrozen and frozen soils[J]. Rock and Soil Mechanics, 2010, 31(9): 2689-2694. (in Chinese))
[10]	何发祥, 黄英. 用BP网络求解土体的导热系数[J]. 岩土力学, 2000, 21(1): 84-87 HE Fa-xiang, HUANG Ying. Solution of thermal conduction coefficient from BP network[J]. Rock and Soil Mechanics, 2000, 21(1): 84-87. (in Chinese))
[11]	刘晓燕, 郑春嫒, 黄彩凤. 多孔材料导热系数影响因素分析[J]. 低温建筑技术, 2009, 31(9): 121-122 LIU Xiao-yan, ZHEN Chun-yuan, HUANG Cai-feng. Analysis effect factor of thermal conductivity for porous materials[J]. Low Temperature Architecture Technology, 2009, 31(9): 121-122. (in Chinese))
[12]	邓友生, 何平, 周成林. 含盐土导热系数的试验研究[J].冰川冻土, 2004, 26(3): 319-323 DENG You-sheng, HE Ping, ZHOU Cheng-lin. An experimental research on the thermal conductivity coefficient of saline soil[J]. Journal of Glaciology and Geocryology, 2004, 26(3): 319-323. (in Chinese))
[13]	付厚利, 刘勇. 深土冻结温度场导热系数识别及应用[C]// 矿山建设工程新进展2007全国矿山建设学术会议文集. 2007. FU Hou-li, LIU Yong. Heat conductivity identification and application of deep earth freezing temperature field[C]// The Academic Meeting of Mining Construction, 2007. (in Chinese))
[14]	周亚素, 雷鸣. 现场测定土壤导热系数的影响因素分析[J]. 东华大学学报自然科学版, 2009, 35(4): 472-477 ZHOU Yan-su, LEI Ming. Influence factors analysis on in-situ test of ground thermal conductivity[J]. Journal of Doonghua University(Natural Science), 2009, 35(4): 472-477. (in Chinese))
[15]	邓朝晖. 建筑材料导热系数的影响因素及测定方法[J]. 工程质量, 2008(7): 15-18 DENG Zhao-hui. Affecting factors and test methods on thermal conductivity of building materials[J]. Quality of Civil Engineering and Construction, 2008(7): 15-18. (in Chinese))
[16]	高青, 余传辉, 马纯强, 等. 地下土壤导热系数确定中影响因素分析[J]. 太阳能学报, 2008, 29(5): 581-585 GAO Qing, YU Chuan-hui, MA Chun-qiang. Analysis of influence factors on determining the ground thermal conductivity[J]. Acta Energiae Solaris Sinica, 2008, 29(5): 581-585. (in Chinese))
[17]	宋春节. 地源热泵系统关键技术的研究[D]. 北京: 北京工业大学, 2008: SONG Chun-jie. Study of several key technical problems of ground-source heat pump system[D]. Beijing: Beijing University of Technology, 2008:
[18]	乔亚玲. 薄质隔热涂层导热系数的测定方法及其量测精度的研究[D]. 北京: 北京工业大学, 2007: QIAO Ya-ling. A new method of thermal conductivity coefficient test for heat-insulated filmsy coating and its measuring accuracy[D]. Beijing: Beijing University of Technology, 2007:
[19]	D533408 American Society for Testing and Materials. Standard test method for determination of thermal conductivity of soil and soft rock by thermal needle probe procedure1[S]. 2008.
[20]	刘伟, 范爱武, 黄晓明. 多孔介质传热传质理论与应用[M]. 北京: 科学出版社, 2006. LIU Wei, FAN Ai-wu, HUANG Xiao-ming. Heat and mass transfer?theory and application of porous media[M]. Beijing: Science Press, 2006.
