基坑被动区加固参数对支护结构位移影响分析

马郧; 屈若枫; 周兴涛; 徐光黎; 龙雄华; 李受祉

基坑被动区加固参数对支护结构位移影响分析 English Version

(1. 中国地质大学，湖北武汉 430074；2. 中南勘察设计院(湖北)有限责任公司，湖北武汉 430074)

详细信息

作者简介:
马郧(1970– )，男，湖北武汉人，博士研究生，教授级高级工程师，主要从事岩土工程勘察、基坑工程设计工作。

中图分类号: TU47
计量
- 文章访问数: 1319
- HTML全文浏览量: 2
- PDF下载量: 573
出版历程
- 收稿日期: 2012-11-12
- 发布日期: 2012-11-12

Effects of reinforcement parameters in passive zone of excavations on lateral deformation of supporting structures

(1. China University of Geosciences, Wuhan 430074, China; 2. Central Southern Geotechnical Design Institute Co., Ltd., Wuhan 430074，China)

摘要

摘要: 为研究软土地基区域基坑被动区加固参数对支护结构位移影响，以武汉地区某典型基坑工程为背景，采用FLAC二维数值模拟的方法，建立了有限差分基坑被动区的加固模型，并将CX6现场实测值与计算值与进行对比，验证计算模型的合理性；实测桩身应力变化规律同支护体系水平位移分布规律一致，反映了实测数据的正确性；基于模型讨论了加固区域的深度、宽度、形状参数对支护结构位移的影响；并将计算值与支护结构的实测位移进行了对比分析，验证数值模拟的精确性、合理性。结合实测值和数值模拟分析的结果表明，数值模拟可以较好地分析支护体系的实际变形规律；在武汉软弱土层地区，被动区阶梯式加固相比其他加固形式有明显的优势，具有较强的适用性；被动区加固对支护结构变形的位移影响是非常显著的；加固区域各阶深度、宽度都存在一个有效域，当超出该域后，加固效果不会出现显著提升；当各阶加固宽度与深度相当时，加固效果最好。
- 软土地基 /
- 基坑 /
- 阶梯式 /
- 被动区加固 /
- 位移影响 /
- 数值模拟
Abstract: In order to study the influence of the parameters of strengthened soils in passive zone of excavations on the lateral displacement of supporting structures in soft soil ground, based on a typical excavation in Wuhan, a finite difference model is established by the FLAC two-dimensional numerical simulation method. Then, the calculated results of CX6 are compared with the field data to verify the rationality and accuracy of the numerical model. The distribution laws of stress on piles and lateral displacement of supporting structure at different measuring points are in consistency, which reflects the correctness of the measured data. The effects of the depth, width and shape in passive zone on the lateral deformation of the supporting structures are studied. The calculated results are compared with the field data to verify the rationality and accuracy of the numerical model. The better agreement of filed data and the numerical simulation analysis shows that the numerical simulation can be used to analyze the actual deformation laws of the supporting structure. The multi-stair improvement has obvious advantages in passive zone compared with other forms, and it shows great application value in Wuhan soft soil layer areas. The effects of strengthened soils in passive zone on the lateral deformation of the supporting structures are obvious. The effects of the depth and width in passive zone exist a valid range. When those parameters exceed a certain value, the increasing rate of the reinforcement effects will be very little. When the width and depth of the improvement are approximately equal, the optimum reinforcement effect can be obtained.
- soft soil ground /
- excavation /
- multi-stair /
- passive zone reinforcement /
- lateral deformation /
- numerical simulation

HTML全文

参考文献(10)

[1]	SHIRLAW J Nick. Jet grouting soft clays for tunneling and deep excavations-design and construction issues[C]// Grouting and Ground Treatment Proceedings of the Third International Conference, GSP No.120. New Orleans, Louisiana: ASCE, 2003: 257–268.
[2]	STUART Littlejohn. The development of practice in permeation and compensation grouting a historical review (1802-2002)[C]//Grouting and Ground Treatment Proceedings of the Third International Conference, GSPNo.120. New Orleans, Louisiana: ASCE, 2003: 100–116 .
[3]	KARLSRUD K. Some aspects of design and construction of deep supported excavations[C]//Proceedings of the Fourteenth International Conference on Soil Mechanics and Foundation Engineering, 1997.
[4]	罗战友, 刘薇, 夏建中. 基坑内土体加固对围护结构变形的影响分析[J]. 岩土工程学报, 2006, 28(增刊): 1538–1540. (LUO Zhan-you, LIU Wei, XIA Jian-zhong. Effect of improvement soils on lateral deformation of foundation pits[J]. Chinese Journal of Geotechnical Engineering, 2006, 28(S0): 1538–1840. (in Chinese))
[5]	魏祥, 杜金龙, 杨敏. 被动区加固对基坑外桩基础的变形影响分析[J]. 岩土工程学报, 2008, 30(增刊): 37–40. (WEI Xiang, DU Jin-long, YANG Min. Influence of passive zone reinforcement on pile foundations adjacent to excavation[J]. Chinese Journal of Geotechnical Engineering, 2008, 30(S0): 37–40. (in Chinese))
[6]	秦爱芳, 胡中雄, 彭世娟. 上海软土地区受卸荷影响的基坑工程被动区土体加固深度研究[J]. 岩土工程学报, 2008, 30(6): 935–940. (QIN Ai-fang, HU Zhong-xiong PENG Shi-juan. Depth of soil stabilization in passive area of foundation pits for Shanghai soft day[J]. Chinese Journal of Geotechnical Engineering, 2008, 30(6): 935–940. (in Chinese))
[7]	贾坚. 土体加固技术在基坑开挖工程中的应用[J]. 地下空间与工程学报, 2007, 3(1): 132–137. (JIA jian. The application of ground treatment in foundation excavations[J]. Chinese Journal of Underground Space and Engineering, 2007, 3(1): 132–137. (in Chinese))
[8]	DB42/159—2004 基坑工程技术规程[S]. 2004. (DB42/159—2004 Technical specification for engineering of foundation excavation[S]. 2004. (in Chinese))
[9]	张辉, 熊巨华, 曾英俊. 长条形基坑地下连续墙侧向位移数值模拟及其影响因素分析[J]. 结构工程师, 2010, 26(1): 80–86. (ZHANG hui, XIONG Ju-hua, ZENG Ying-jun. Numerical simulation and influence factor analysis on lateral displacement of diaphragm wall in long-narrow pit[J]. Structural Engineers, 2010, 26(1): 80–86. (in Chinese))
[10]	郑俊杰, 章荣军, 丁烈云, 等. 基坑被动区加固的位移控制效果及参数分析[J]. 岩石力学与工程学报, 2010, 29(5): 1042–1051. (ZHENG Jun-jie, ZHANG Rong-jun, DING Lie-yun, et al. Displacement control effects and parameter analysis of passive zone improvement of foundation pits[J]. Chinese Journal of Rock Mechanics and Engineering, 2010, 29(5): 1042–1051. (in Chinese))（本文责编李运辉）
