自动化实时监测在地铁隧道中的应用及分析

杨帆; 赵剑; 刘子明; 邹兴欣

自动化实时监测在地铁隧道中的应用及分析 English Version

（1. 深圳市市政设计研究院有限公司，广东深圳 518029；2. 深圳地铁运营分公司，广东深圳 518040）

详细信息

作者简介:
杨帆(1980– )，男，四川成都人，硕士，工程师，主要从事地铁监测、桥梁及房屋建筑结构检测鉴定等工作。

中图分类号: TU456
计量
- 文章访问数: 1033
- HTML全文浏览量: 2
- PDF下载量: 1149
出版历程
- 收稿日期: 2012-11-12
- 发布日期: 2012-11-12

Application and analysis of automatic real-time monitoring in construction of subway tunnels

(1. Shenzhen Muncipial Design & Research Institute Co., Ltd., Shenzhen 518029, China; 2. Operation Department of Shenzhen Metro Company, Shenzhen 518040, China)

摘要

摘要: 介绍了深圳地铁二号线东延段燕大区间穿越运营地铁一号线大科区间时结构变形自动化实时监测的实施要点，根据盾构隧道结构特点，完善了整个自动化监测系统，并分析了结构变形规律。当地铁左右线全部完成穿越后，最大累计沉降变形量为-13.8 mm，变形值均在控制指标允许范围内。同时提出将监测点的沉降过程划分为3个阶段，对沉降量最大的第二阶段使用对数函数模型y=-4.096ln(x)-2.7194来进行拟合，得到了较好的拟合结果。最后对盾构法施工引起结构变形的主要原因进行了有益探讨，为今后类似项目提供了宝贵的监测经验。
- 地铁隧道 /
- 结构变形 /
- 实时监测 /
- 数据分析 /
- 模型分析
Abstract: The key points of automatic real-time monitoring of the structural deformation are introduced when the subway Line 1 is traversed by the extension section of the subway Line 2 in Shenzhen. The automatic monitoring system is improved according to the structural characteristics of the shield tunnel, and the structural deformation rules are analyzed. After all the traversing of the left and right tunnels of subway Line 2, the accumulated settlement is -13.8 mm, which is below the critical value. The settlement process is divided into three stages. For the second stage with the largest settlement, a logarithmic function y=-4.096ln(x)-2.7194 is employed, and the fitting results are satisfactory. The main reasons of the structural deformation induced by the shield method are discussed. It may provide reference and monitoring experience for similar projects in the future.
- subway tunnel /
- structural deformation /
- real-time monitoring /
- data analysis /
- model analysis

HTML全文

参考文献(11)

[1]	张成平, 张订立, 吴介普, 等. 暗挖地铁车站下穿既有地铁隧道施工控制[J]. 中国铁道科学, 2009, 30(1): 69–72. (ZHANG CP, ZHANG DL, WU J P, et al. Construction Control of a Newly-built subway station undercrossing the existing subway tunnel[J]. China Railway Science, 2009, 30(1): 69–72. (in Chinese))
[2]	王勇. 浅谈富水软弱地层地铁隧道施工沉降控制技术[J].科技资讯, 2010(5): 77–82. (WANG Y. On the settlement control of subway tunnel construction in water-rich soft ground[J]. Sciense &Technology Information, 2010(5): 77–82. (in Chinese))
[3]	上海市地铁沿线建筑施工保护地铁技术管理暂行规定[S]. 上海市市政工程管理局, 1994. (The interim provisions of metro technology management of the subway protection during construction along the subway in Shanghai[S]. Shanghai Municipal Engineering dministration Bureau, 1994. (in Chinese))
[4]	邹积亭. 地铁沉降监测数据处理与小波去噪分析[D]. 北京建筑工程学院, 2006. (ZOU J T. The processing of settlement observation data and the wavelet de-noising analysis[D]. Beijing University of Civil Engineering and Architecture, 2006. (in Chinese))
[5]	PERCIVAL B. Donald, WALDEN T. Andrew. 时间序列分析的小波方法[M]. 程正兴, 译. 北京: 机械工业出版社, 2005. (PERCIVAL B. Donald, WALDEN T. Andrew. Wavelet method for temporal sequence analysis[M]. CHENG Zheng-xing, translator. Beijing: China Machine Press, 2005. (in Chinese))
[6]	崔晓东. 建筑物沉降规律的综合时序分析[J]. 现代测绘, 2004, 27(1). (CUI XD. Comprehensive time series analyzing for building settlement rule[J]. Modern Surveying and Mapping, 2004, 27(1). (in Chinese))
[7]	韦凯. 软土地层中盾构施工对既有地铁沉降的影响分析[J]. 华东交通大学学报, 2007, 24(2): 58–61. (WEI K. Analysis of the underground pipeline deformation control factors with shield tunnel excavation beneath it in soft soil[J]. Journal of East China Jiaotong University, 2007, 24(2): 58–61. (in Chinese))
[8]	刘波, 陶龙光, 丁城刚, 等. 地铁双隧道施工诱发地表沉降预测研究与应用[J]. 中国矿业大学学报, 2006, 35(3): 356–361. (LIU B, TAO L G, DING C G, et al. Prediction for ground subsidence induced by subway double tube tunneling[J]. Journal of China University of Mining & Technology, 2006, 35(3): 356–361. (in Chinese))
[9]	陈学军, 邹宝平, 邝光霖, 等. 盾构隧道下穿深圳滨海大道沉降控制技术[J]. 铁道标准设计, 2010(3): 92–95. (CHEN X J, ZOU B P, KUANG G L, et al. Control technology for settlement of shielding tunnel undergoing through binhai road in Shenzhen[J]. Railway Standard Design, 2010(3): 92–95. (in Chinese))
[10]	梁禹. 广州地铁一号线越江隧道运营期结构变形监测[J]. 现代隧道技术, 2008, 45(3): 84–87. (LIANG Y. Structural Deformation Monitoring of the Submerged Tunnel on Guangzhou Metro Line 1 during Operation[J].Modern Tunnelling Technology, 2008, 45(3): 84–87. (in Chinese))
[11]	谢伟文, 方门福. 深圳地铁第三方变形监测的技术方法[J].城市勘测, 2007(3): 98–102. (XIE W W, FANG M F. Technical methods of deformation monitoring in Shengzhen metro[J]. Urban Geothechnical Investigation & Surveying, 2007(3): 98–102. (in Chinese))（本文责编李运辉）
