基于能量理论的土钉支护结构地震主动土压力计算方法研究

王永胜; 朱彦鹏; 周勇

基于能量理论的土钉支护结构地震主动土压力计算方法研究 English Version

(兰州理工大学土木工程学院，甘肃兰州 730050)

详细信息

作者简介:
王永胜(1985– )，男，甘肃甘谷人，博士生，主要从事支挡结构和工程事故分析与处理方面的科研工作。

中图分类号: TU432
计量
- 文章访问数: 01120
- HTML全文浏览量: 0
- PDF下载量: 0373
出版历程
- 收稿日期: 2012-11-12
- 发布日期: 2012-11-12

Method for calculating seismic active earth pressure of soil-nailing retaining structures based on energy theory

(College of Civil Engineering, Lanzhou University of Technology, Lanzhou 730050, China)

摘要

摘要: 地震作用下柔性支挡结构土压力的计算是个比较复杂的问题，其方法还不成熟且比较保守，为了能够比较准确合理地计算地震作用下土钉支护结构的主动土压力，以能量法和极限平衡法为基础，考虑土钉支护结构对地震土压力的影响，建立了滑动面为平面的地震主动土压力模型，推导了地震主动土压力的计算公式。结合工程实例，把公式与现有规范和方法的计算结果作比较，并进行参数分析，得到一些具有参考价值的结果。分析表明，公式计算的土压力值均比其它方法小，土钉的存在能够有效地减小地震作用下土体对支护结构的侧向压力，并使滑移面慢慢向墙后移动。通过算例验证，说明这种考虑土钉支护作用的计算方法更加合理，比较符合工程实际，为以后土钉支护结构的施工、优化和抗震设计提供参考。
- 边坡工程 /
- 能量理论 /
- 极限平衡法 /
- 土钉支护结构 /
- 地震主动土压力
Abstract: The calculation of earth pressure of flexible retaining wall under earthquake ground motion is a complex problem, and the relevant method for calculating the earth pressure is still not mature and conservative. In order to calculate the active earth pressure of soil-nailing retaining structure under earthquake ground motion accurately and reasonably based on the energy method and the limit equilibrium method, a model for the seismic active earth pressure is established, in which the sliding surface is considered as a plane, and the formula is obtained considering the influence of the role of soil-nailing retaining structure on the earth pressure. Based on an engineering example, the results obtained from the above formula are compared with those obtained from the existing norms and methods, and parametric analysis is carried out, and then some practical results are obtained. The results show that the calculated earth pressures are smaller than those from other methods. The existence of soil nails can effectively reduce the lateral pressure of supporting structures under earthquake ground motions and make the sliding surface slowly move to the wall back. The proposed method considering the role of soil nailing is more reasonable and agrees with the actual engineering. It may provide some valuable references for the construction, optimization and anti-seismic design of soil-nailing retaining structures.
- slope engineering /
- energy theory /
- limit equilibrium method /
- soil-nailing retaining structure /
- seismic active earth pressure

HTML全文

参考文献(14)

[1]	王建, 姚令侃, 陈强. 汶川地震路堤成灾模式及土工格栅加筋变形控制研究[J]. 岩石力学与工程学报, 2010, 29(1): 3387–3394. (WANG Jian, YAO Ling-kan, CHEN Qiang. Research on failure mode of road embankment in Wenchuan great earthquake and deformation control of geogrid reinforcement[J]. Chinese Journal of Rock Mechanics and Engineering, 2010, 29(1): 3387–3394. (in Chinese))
[2]	邱燕玲, 姚令侃, 秦伟. 汶川地震路基挡墙震害特征分析[J]. 重庆交通大学学报(自然科学版), 2010, 29(4): 576–581. (QIU Yan-ling, YAO Ling-kan, QIN Wei . Characteristic analysis of the damaged retaining wall in Wenchuan earthquake[J]. Journal of Chongqing Jiaotong University (Natural Science), 2010, 29(4): 576–581. (in Chinese))
[3]	许强, 李为乐. 汶川地震诱发大型滑坡分布规律研究[J]. 工程地质学报, 2010, 18(6): 818–826. (XU Qiang, LI Wei-le. Distribution of large-scale landslides induced by the Wenchuan earthquake [J]. Journal of Engineering Geology, 2010, 18(6): 818–826. (in Chinese))
[4]	王元战, 李新国, 陈楠楠. 挡土墙主动土压力分布与侧压力系数[J]. 岩土力学, 2005, 26(7): 1019–1022. (WANG Yuan-zhan, LI Xin-guo, CHEN Nan-nan.Active earth pressure on a retaining wall and lateral coefficient of earth pressure [J].Rock and Soil Mechanics, 2005, 26(7): 1019–1022. (in Chinese))
[5]	王立峰. 土钉墙面层土压力的计算分析[J]. 岩土力学, 2010, 31(5): 1615–1626. (WANG Li-feng. Analysis of facing earth pressure in soil nailing walls[J]. Rock and Soil Mechanics, 2010, 31(5): 1615–1626. (in Chinese))
[6]	曹振民. 挡土墙填土曲线破裂面主动土压力分析[J]. 中国公路学报, 1995, 8(2): 7–14. (CAO Zhen-min. Analysis of active earth pressure of back fill on retaining wall with curved rupture surface[J].China Journal of Highway and Transport, 1995, 8(2): 7–14. (in Chinese))
[7]	梅国雄, 宰金珉. 考虑位移影响的土压力近似计算方法[J].岩土力学, 2001, 22(1): 83–85. (MEI Guo-xiong, ZAI Jin-min. Earth pressure calculating method considering displacement[J]. Rock and Soil Mechanics, 2001, 22(1): 83–85. (in Chinese))
[8]	BROWZIN B S. Anchored bulkheads horizontal and sloping anchors[J]. J Geotech Engng Div Am Soc Civ Engrs, 1981, 107(GT5): 629–645.
[9]	HASHASH M A, WHITTLE A J. Mechanisms of load transfer and arching for braced excavations in clay[J]. 2002, 128(3): 187–197.
[10]	DESAI C S. A fundamental study of braced excavation construction[J]. Comput Geotech, 1977, 8: 39–64.
[11]	徐日庆. 考虑位移和时间的土压力计算方法 [J]. 浙江大学学报, 2000, 34(4): 370–375. (XU Ri-qing. Methods of earth pressure calculation for excavation[J]. Journal of Zhejiang University (Engineering Science), 2000, 34(4): 370–375. (in Chinese))
[12]	陈页开. 挡土墙上土压力的试验研究与数值分析[D]. 杭州: 浙江大学, 2001. (CHEN Ye-kai. Model test and numerical analysis of earth pressures on retaining wall[D]. Hangzhou: Zhejiang University, 2001. (in Chinese))
[13]	朱彦鹏, 罗晓辉, 周勇. 支挡结构设计[M]. 北京: 高等教育出版社, 2008. (ZHU Yan-peng, LUO Xiao-hui, ZHU Yong. Retaining structure design[M]. Beijing: Higher Education Press, 2008. (in Chinese))
[14]	顾慰慈. 挡土墙土压力计算[M]. 北京: 中国建材工业出版社, 2000. (GU Wei-ci. Calculating instructions of retaining wall[M]. Beijing: China Building Material Industry Publishing House, 2000. (in Chinese))
