基于隧道空间全波场二维数值模拟与特征分析

刘江平; 程飞; 范承余; 曹进

基于隧道空间全波场二维数值模拟与特征分析 English Version

1. 中国地质大学(武汉地球物理与空间信息学院，湖北武汉 430074；2. 安徽省高速公路控股集团有限公司，安徽合肥 230051

详细信息

作者简介:
刘江平(1957– )，男，湖南双峰人，博士，教授，博士生导师，主要从事环境工程地球物理方面的教学和研究工作。

中图分类号: U45
计量
- 文章访问数: 1008
- HTML全文浏览量: 8
- PDF下载量: 395
出版历程
- 收稿日期: 2011-09-12
- 发布日期: 2012-10-09

Two-dimensional numerical simulation of tunnel-based seismic full-wave fields

1. Institute of Geophysics & Geomatics, China University of Geosciences (Wuhan, Wuhan 430074, China; 2. Anhui Expressway Holding Group Company Limited, Hefei 230051, China

摘要

摘要: 基于隧道地震波场二维数值模拟是研究隧道超前探测过程中地震波传播规律的基础，目前关于这方面的研究均建立在隧道侧壁观测系统的基础上，并且把隧道空间作为与周围地层具有同样弹性参数的均匀介质考虑，因此不能实现全波场模拟，与实际存在差异。基于实际隧道空间，建立了更加接近实际的隧道地质模型，实现了隧道空间的二维全波场模拟。通过二维全波场模拟及实例结果对比分析表明：① 采用空间四阶时间二阶交错网格有限差分法能有效实现基于隧道空气介质的二维全波场模拟；② 当地质界面倾角为90°时，掌子面附近激发的共激发点观测系统比侧壁的共接收点观测系统更有利于反射波的获取；③ 随着地质界面倾角的减小，界面同侧激发和接收的反射波能量增强；④对于局部地质体和大倾角地质界面，掌子面附近激发横波能量强于纵波，有利于横波成像。
- 全波场模拟 /
- 隧道 /
- 超前预报 /
- 交错网格
Abstract: The two-dimensional (2D) numerical simulation of seismic wave fields based on tunnels is a basis for the analysis of propagation laws of seismic waves in the tunnel prediction. All of the current researches, which are designed with observation systems on the sidewalls of tunnels and assume tunnels as homogeneous media with the same elastic parameters of surrounding media, are not in conformity with the actual situations because they cannot involve surface waves. A geological tunnel-based model is established, which is more suitable for the practical tunnels to achieve the 2D numerical simulation of seismic full-wave fields. The results show: (1) using a staggered grid finite-difference (FD) algorithm with a second-order accuracy in time and a fourth-order accuracy in space, we can achieve the 2D numerical simulation of seismic full-wave fields without ignoring the air medium in tunnels; (2) when considering a vertical geological interface, common-source system with shots near the tunnel face is better for obtaining reflection waves than the one with shots on the side walls; (3) with the decrease of the dips of geological interfaces, the energy of reflection waves increases when shots and receivers are on the same side; (4) for the local geological features and interfaces, shear wave shot on the tunnel face, which acquires more energy than pressure wave shot, can help in shear wave imaging.
- numerical simulation of full-wave fields /
- tunnel /
- advanced forecast /
- staggered-grid

HTML全文

参考文献(10)

[1]	宋先海, 顾汉明, 肖伯勋. 我国隧道地质超前预报技术述评[J]. 地球物理学进展, 2006, 21(2): 605–613. (SONG Xian-hai, GU Han-ming, XIAO Bo-xun. Overview of tunnel geological advanced prediction in China[J]. Progress in Geophysics, 2006, 21(2): 605–613. (in Chinese))
[2]	赵永贵. 国内外隧道超前预报技术评析与推介[J]. 地球物理学进展, 2007, 22(4): 1334–1352. (ZHAO Yong-gui. Analysis and recommendation of tunnel prediction techniques at home and abroad[J]. Progress in Geophysics, 2007, 22(4): 1334–1352. (in Chinese))
[3]	ZHAO Y G, JIANG H, ZHAO X P. Tunnel seismic tomography method for geological prediction and its application[J]. Applied Geophysics, 2006, 3(2): 69–74.
[4]	张平松,刘盛东,吴健生. 隧道及井巷工程超前探测模拟及其偏移技术研究[J]. 岩石力学与工程学报, 2007, 26(增刊1): 2847–2851. (ZHANG Ping-song, LIU Sheng-dong, WU Jian-sheng. Study on detecting simulation ahead of tunnel and laneway and its migration techniques[J]. Chinese Journal of Rock Mechanics and Engineering, 2007, 26(S1): 2847–2851. (in Chinese))
[5]	王齐仁. 隧道地质灾害超前探测方法研究[D]. 长沙: 中南大学, 2008. (WANG Qi-ren. The study of advanced detecting methods on tunnel geological hazards[D]. Changsha: Central South University, 2008. (in Chinese))
[6]	杜立志. 隧道施工地质地震波法超前探测技术研究[D]. 吉林: 吉林大学, 2008. (DU Li-zhi. The study of tunnel seismic geological prediction technology in the process of construction[D]. Jilin: Jilin University, 2008. (in Chinese))
[7]	鲁光银, 熊瑛, 朱自强. 隧道反射波超前探测有限差分正演模拟与偏移处理[J]. 中南大学学报(自然科学版), 2011, 42(1): 136–141. (LU Guang-yin, XIONG Ying, ZHU Zi-qiang. Detection simulation ahead of tunnel face and reverse-time migration with reflection wave method[J]. Journal of Central South University (Science and Technology), 2011, 42(1): 136–141. (in Chinese))
[8]	鲁光银. 隧道地质灾害反射波法探测数值模拟及围岩F-AHP分级研究[D]. 长沙: 中南大学, 2009. (LU Guang-yin. Numerical simulation for tunnel geological hazard detection by reflected wave method and rock dynamic classification by F-AHP method research[D]. Changsha: Central South University, 2009. (in Chinese))
[9]	GRAVES R W. Simulating seismic wave propagation in 3D elastic media using staggered-grid finite difference[J]. Bulletin of the Seismological Society of America, 1996, 86(4): 1091–1106.
[10]	CERJAN Charles, KOSLOFF Dan. A nonreflecting boundary condition for discrete acoustic and elastic wave equation[J]. Geophysics, 1985, 50(4): 705–708.
