不同锚固方式下软弱破碎岩质边坡渐进破坏特性的模型试验研究

徐前卫; 丁文其; 朱合华; 马静

不同锚固方式下软弱破碎岩质边坡渐进破坏特性的模型试验研究 English Version

1.同济大学道路与交通工程教育部重点实验室，上海 200092; 2. 同济大学岩土及地下工程教育部重点实验室，上海 200092; 3. 上海理工大学土木工程系，上海 200093

基金项目: 国家自然科学基金项目(41130751)；西部交通科技建设项目(2011ZB04)；岩土及地下工程教育部重点实验室（同济大学）开放基金资助项目(KLE-TJGE-B1108)

详细信息

作者简介:
徐前卫 (1973 – ),男，工学博士，副教授,主要从事隧道及地下结构工程领域的教学与科研工作。

中图分类号: TU45
计量
- 文章访问数: 01255
- HTML全文浏览量: 0
- PDF下载量: 0530
出版历程
- 发布日期: 2012-06-19

Experimental study on progressive failure properties of weak and fractured rock slopes with different anchoring modes

1. Key Laboratory of Road and Traffic Engineering of Ministry of Education, Tongji University, Shanghai 200092 , China; 2. Key Laboratory of Geotechnical and Underground Engineering of Ministry of Education, Tongji University, Shanghai 200092, China ; 3. Department of Civil Engineering, University of Shanghai for Science and Technology, Shanghai 200093, China

摘要

摘要: 在软弱破碎岩体中进行人工边坡开挖，往往因局部坡体应力集中或变形过大而导致边坡失稳破坏，为此需要采用大量的锚杆加固岩体。为进一步了解该类边坡的变形破坏机制及其支护加固效果，以 Ⅳ 类围岩为参照对象，将其等效为单一均质地层，并根据相似理论建立其地质力学模型，随后开展了不同锚杆加固方式下岩质边坡破坏特性的试验研究。试验结果表明，当不采取加固措施时，软弱破碎岩质边坡的塌方主要是由于坡顶岩体的张拉和坡脚岩体的压剪共同作用的结果，且往往呈渐进性破坏机制；当采取锚杆加固时，一方面，锚杆加固可有效提高边坡岩体的承载能力和抵抗变形能力，锚杆的作用主要体现在抗剪止裂和抗拉伸两个方面，另一方面，不同的锚杆直径、锚杆长度和锚固间距对边坡岩体的加固效果和最终破坏模式有较大影响。
- 软弱破碎岩体 /
- 岩质边坡 /
- 渐进性破坏 /
- 锚杆 /
- 模型试验
Abstract: Cutting slopes in weak and fractured rock mass will inevitably induce excessive stress or deformation of the surrounding rock, which may result in slope collapse accidents. Therefore, a large number of anchor bolts are required to reinforce the rock mass. In order to further understand the failure mechanism and the anchoring effect of this kind of slope, the weak and fractured rock mass of grade Ⅳ, according to China's classification, is taken as the reference prototype. It is equivalent to be isotropic continual stratum for facilitating research firstly, and then its geologic model ground is manufactured according to the similarity theory. Subsequently, a series of model tests are carried out to study failure characteristics of the rock slope with or without bolt reinforcement. The test results show that, if no reinforcement measures are taken, the collapse of slope is the combined results of tension failure at the top and compression-shearing failure at the bottom of the slope, and it often presents the characteristics of progressive failure. If bolts are adopted for reinforcement, on the one hand, it can effectively improve the bearing capacity and deformation resistance of rock mass, and the anchoring effect of the bolts is mainly reflected by the aspects of shear resistance, crack resistance and anti-extension; on the other hand, different bolt diameters, lengths and spacings have a great impact on the reinforcement effect and the final failure mode of the rock slope.
- weak and fractured rock mass /
- rock slope /
- progressive failure /
- bolt /
- model test

HTML全文

参考文献(16)

[1]	EBERHARDTA E, STEADB D, COGGANC J S. Numerical analysis of initiation and progressive failure in natural rock slopes-the 1991 Randa rockslide[J]. International Journal of Rock Mechanics & Mining Sciences, 2004(41): 69 – 87.
[2]	LI X. Finite element analysis of slope stability using a nonlinear failure criterion[J]. Computers and Geotechnics, 2007, 34 : 127 – 136.
[3]	程谦恭 , 胡厚田 , 彭建兵等 . 高边坡岩体渐进性破坏黏弹塑性有限元数值模拟 [J]. 工程地质学报 , 2000, 8 (1): 25 – 30. (CHENG Qian-gong, HU Hou-tian, PENG Jian-bing, et al. Visco-elastoplastic finite element simulation of progressive failure of high-steep rock slope[J]. Journal of Engineering Geology, 2000, 8 (1): 25 – 30. (in Chinese))
[4]	王庚荪 . 边坡的渐进破坏及稳定性分析 [J]. 岩石力学与工程学报 , 2000, 19 (1): 29 – 33. (WANG Geng-sun. The progressive failure of slope and the stability analyses[J]. Chinese Journal of Rock Mechanics and Engineering, 2000, 19 (1): 29 – 33. (in Chinese))
[5]	袁大祥 , 朱子龙 , 朱乔生 . 高边坡节理岩体地质力学模型试验研究 [J]. 三峡大学学报 ( 自然科学版 ), 2001, 23 (3): 193 – 197. (YUAN Da-xiang, ZHU Zi-long, ZHU Qiqo-sheng. Experimental research on geomechanics model of jointed rock mass of high slope[J]. Journal of China Three Gorges University, 2001, 23 (3): 193 – 197. (in Chinese))
[6]	郑颖人 , 赵尚毅 , 邓卫东 . 岩质边坡破坏机制有限元数值模拟分析 [J]. 岩石力学与工程学报 , 2003, 22 (12): 1943 – 195. (ZHENG Ying-ren, ZHAO Shang-yi, DENG Wei-dong. Numerical simulation on failure mechanism of rock slope by strength reduction FEM[J]. Chinese Journal of Rock Mechanics and Engineering, 2003, 22 (12): 1943 – 195. (in Chinese))
[7]	陈亚军 , 王家臣 , 常来山 , 等 . 节理岩体边坡渐进破坏的试验研究 [J]. 金属矿山 , 2005, 23 (8): 11 – 13. (CHEN Ya-jun, WANG Jia-chen, CHANG Lai-shan, et al. Experimental research on progressive failure of jointed rock slope[J]. Underground Space, 2003, 23 (8): 158 – 161. (in Chinese))
[8]	刘宪权 , 朱建明 , 冯锦艳 , 等 . 水平厚煤层露井联合开采下边坡破坏机理 [J]. 煤炭学报 , 2008, 33 (12): 1346 – 1350. (LIU Xian-quan, ZHU Jian-ming, FENG Jin-yan, et al. Mechanism of the slope failure of horizontal thick coal seam under the condition of combined mining [J]. Journal of China Coal Society, 2008, 33 (12): 1346 – 1350. (in Chinese))
[9]	STILL H, HOLMEBERY M, NORD G. Support of weak rock with ground bolts and shotcrete[J]. Rock Mech. & Rock Engineering, 1989, 22 (3): 73 – 78.
[10]	CAI Yue, ESAKIA Tetsuro, JIANG Yu-jing. Arock bolt and rock mass interaction model[J]. International Journal of Rock Mechanics & Mining Sciences, 2004, 41 : 1055 – 1067.
[11]	尤春安 . 全长黏结式锚杆的受力分析 [J]. 岩石力学与工程学报 , 2000, 19 (3): 339 – 341. (YOU Chun-an. Mechanical analysis of whole grouted anchor[J]. Chinese Journal of Rock Mechanics and Engineering, 2000, 19 (3) : 339 – 341. (in Chinese))
[12]	荣冠 , 朱焕春 , 杨松林 , 等 . 三峡工程永久船闸高强锚杆现场试验研究 [J]. 岩土力学 , 2001, 22 (2): 171 – 175. (RONG Guan, ZHU Huan-chun, YANG Song-lin, et al. In-situ study on bolting at permanent shiplock of Three Gorges Project[J]. Rock and Soil Mechanics, 2001, 22 (2): 171 – 175. (in Chinese))
[13]	吴德海 , 曾祥勇 , 邓安福 , 等 . 单锚锚杆加固碎裂结构岩体模型试验研究 [J]. 地下空间 , 2003, 23 (2): 158 – 161. (WU De-hai, ZENG Xiang-yong, DUN An-fu, et al. Experimental study on rock model of cracked structure reinforced by single bolt[J]. Underground Space, 2003, 23 (2): 158 – 161. (in Chinese))
[14]	王四巍 , 姜彤 , 刘汉东 , 等 . 中空注浆锚杆在加固碎裂边坡中应用试验研究 [J]. 岩石力学与工程学报 , 2008, 27 ( 增刊 2): 3965 – 3967. (WANG Si-wei, JIANG Tong, LIU Han-dong, et al. Study on testing in reinforced slope with hollow grouted bolt[J]. Chinese Journal of Rock Mechanics and Engineering, 2008, 27 (S2): 3965 – 3967. (in Chinese))
[15]	张永兴 , 卢黎 , 饶枭宇 , 等 . 压力型锚杆力学性能模型试验研究 [J]. 岩土力学 , 2010, 31 (7): 2045 – 2050. (ZHANG Yong-xin, LU Li, RAO Xiao-yu, et al. Model test research on mechanical behavior of compression type rock bolt[J]. Rock and Soil Mechanics, 2010, 31 (7): 2045 – 2050. (in Chinese))
[16]	PHILLIPS S H E. Factors affecting the design of anchorages in rock[R]. London: Cementation Research Ltd, 1970.
