地震作用下面板堆石坝面板错台模型试验研究

孔宪京; 刘福海; 刘 君

地震作用下面板堆石坝面板错台模型试验研究 English Version

孔宪京^1,2,
刘福海¹,
刘君^1,2,

1. 大连理工大学海岸与近海工程国家重点实验室，辽宁大连116024; 2. 大连理工大学水利工程学院，辽宁大连 116024

基金项目: 国家自然科学基金项目（ 90815024 ， 50978045 ）

详细信息

作者简介:
孔宪京 (1952 – ) ，男，江苏南京人，博士，教授，博士生导师，主要从事岩土地震工程和高土石坝抗震的研究。

中图分类号: TV641
计量
- 文章访问数: 1185
- HTML全文浏览量: 2
- PDF下载量: 751
出版历程
- 收稿日期: 2011-01-20
- 发布日期: 2012-02-19

Shaking table model tests on face-slab dislocation of concrete faced rock-fill dams under earthquakes

1. State Key Laboratory of Coastal & Offshore Engineering, Dalian University of Technology, Dalian 116024, China; 2. School of Hydraulic Engineering, Dalian University of Technology, Dalian 116024, China

摘要

摘要: 采用弹性–重力相似关系设计了一组混凝土面板堆石坝（面板坝）振动台模型试验，研制开发了仿真面板材料，设计了一套图像采集、存储与分析系统。根据图像识别技术分析结果以及模型的数值计算分析结果，详细分析了面板坝面板错台机理，并与汶川地震中紫坪铺面板坝面板错台震害进行了对比分析。研究结果表明，地震造成的堆石体永久变形对面板产生的向下摩擦力和向外推力是造成面板错台的主要原因。模型试验结果与数值计算结果和实际震害基本吻合，表明振动台模型试验可以再现原型的主要破坏特征。
- 面板堆石坝 /
- 振动台模型试验 /
- 图像识别 /
- PIV /
- 紫坪铺 /
- 面板错台
Abstract: Shaking table model tests on concrete faced rock-fill dams are designed according to the elasticity-gravity similarity rules. Face-slab model materials are developed, and a system for the image collect ion, storage and pattern recognition is presented. On the basis of the results of the PIV analysis and the numerical simulation, t he dislocation mechanism of the face-slab under earthquakes is analyzed, and the results are compared with the real dislocation damage of Zipingpu Dam during Wenchuan Earthquake. The results of the model tests agree with those of numerical simulation . Both of them reveal the slab dislocation phenomenon of Zipingpu Dam. The results show that the main reasons of the face-slab dislocation are the thrust force towards the upstream and the friction force towards the downstream along the slab due to the permanent deformation of the rock-fill . Shaking table model tests can reflect the main damage characteristics of the prototype dams.
- concrete faced rock-fill dam /
- shaking table model test /
- pattern recognition /
- PIV /
- Zipingpu Dam /
- face-slab dislocation
