柱状节理岩体宏观等效弹性模量尺寸效应研究

闫东旭, 徐卫亚, 王 伟, 石 崇, 石安池, 吴关叶

闫东旭, 徐卫亚, 王 伟, 石 崇, 石安池, 吴关叶. 柱状节理岩体宏观等效弹性模量尺寸效应研究[J]. 岩土工程学报, 2012, 34(2): 243-250.
引用本文: 闫东旭, 徐卫亚, 王 伟, 石 崇, 石安池, 吴关叶. 柱状节理岩体宏观等效弹性模量尺寸效应研究[J]. 岩土工程学报, 2012, 34(2): 243-250.
shu
YAN Dong-xu, XU Wei-ya, WANG Wei, SHI Chong, SHI An-chi, WU Guan-ye. Research of size effect on equivalent elastic modulus of columnar jointed rock mass[J]. Chinese Journal of Geotechnical Engineering, 2012, 34(2): 243-250.
Citation: YAN Dong-xu, XU Wei-ya, WANG Wei, SHI Chong, SHI An-chi, WU Guan-ye. Research of size effect on equivalent elastic modulus of columnar jointed rock mass[J]. Chinese Journal of Geotechnical Engineering, 2012, 34(2): 243-250.
shu

柱状节理岩体宏观等效弹性模量尺寸效应研究  English Version

  • 1. 河海大学岩土力学与堤坝工程教育部重点试验室，江苏 南京 210098; 2. 河海大学岩土工程科学研究所，江苏 南京 210098; 3. 中国水电顾问集团华东勘测设计研究院，浙江 杭州 310014

基金项目: 国家自然科学基金项目 （ 50911130366 ， 50979030 ）
详细信息
    作者简介:

    闫东旭 (1984 – ) ，男，江苏徐州人，博士研究生，主要从事岩石力学理论与工程实践研究。

  • 中图分类号: TU452

Research of size effect on equivalent elastic modulus of columnar jointed rock mass

  • 1. Key Laboratory of Ministry of Education for Geomechanics and Embankment Engineering, Hohai University, Nanjing 210098, China; 2. Research Institute of Geotechnical Engineering, Nanjing 210098, China; 3. East China Hydropower Investigation and Design Institute, Hangzhou 310014, China

摘要

    摘要
  • 摘要: 以金沙江白鹤滩水电站工程为背景，结合相关的岩石力学试验方法，建立了柱状节理岩体三维离散元模型，对柱状节理岩体进行了三轴压缩试验数值模拟。数值试验研究了六棱柱形柱状节理岩体柱体直径变化、四棱柱形柱状节理岩体柱体边长、节理错距变化对其等效弹性模量的影响。为研究随机柱状节理岩体柱体尺寸对岩体等效弹性模量的影响，提出柱体大对角线长尺寸控制方案，并研究了柱体大对角线长变化对岩体等效弹性模量的影响。通过与现场试验的对比研究，结果表明：随机柱体尺寸控制方案可靠；柱体尺寸的变化对与柱体垂直方向的等效弹性模量影响较大，是主要影响因素；四棱柱形柱状节理岩体错距变化主要对与错距平行的岩体等效弹性模量产生影响，对其它两个方向的等效弹性模量的影响较弱，是次要影响因素。研究结果为工程实践中等效力学参数的确定提供了相关参考。
    Abstract: Based on Baihetan Hydropower Project on Jinsha River, 3D discrete element models for columnar jointed rock mass are established considering the relevant methods of rock mechanics. Numerical simulations of triaxial compression tests on the columnar jointed rock mass are carried out. The impacts of diameter change on the equivalent elastic modulus of hexagonal columnar jointed rock mass as well as those of side length and joint stagger change on the equivalent elastic modulus of quadrangular columnar jointed rock mass are studied. In order to investigate the impacts of size change on the equivalent elastic modulus of random columnar jointed rock mass, a program for controlling columnar size is proposed using the average large diagonal size. Then the impacts of change of the average large diagonal size on the equivalent elastic modulus are studied. It is shown from the researches on size effect and comparison with the in-situ tests that changes in cylinder size have larger impacts on the equivalent elastic modulus perpendicular to cylinder than on that parallel to cylinder. Changes in stagger of quadrangular columnar jointed rock mass mainly have impacts on the equivalent elastic modulus parallel to stagger and have weak impacts on the equivalent elastic moduli in two other directions. The results can provide reference for the determination of mechanical parameters in engineering practice.
    • HTML全文
    • 参考文献(26)
  • [1] 张 明 , 卢裕杰 , 杨 强 . 准脆性材料的破坏概率与强度尺寸效应 [J]. 岩石力学与工程学报 , 2010, 29 (9): 1782 – 1789. (ZHANG Ming, LU Yu-jie ， YANG Qiang. Failure probability and strength size effect of quasi-brittle materials[J]. Chinese Journal of Rock Mechanics and Engineering, 2010, 29 (9): 1782 – 1789. (in Chinese))
    [2] 周火明 , 盛 谦 , 邬爱清 . 三峡工程永久船闸边坡岩体宏观力学参数的尺寸效应研究 [J]. 岩石力学与工程学报 , 2001, 20 (5): 661 – 664. (ZHOU Huo-ming, SHENG Qian, WU Ai-qing. Size effect analysis of macro-mechanics parameters for the rock masses of the TGP ship lock slope[J]. Chinese Journal of Rock Mechanics and Engineering, 2001, 20 (5): 661 – 664. (in Chinese))
    [3] 陈 瑜 , 黄永恒 , 曹 平 , 等 . 不同髙径比时软岩强度与变形尺寸效应研究 [J]. 中南大学学报 , 2010, 41 (3): 1073 – 1078. (CHEN Yu, HUANG Yong-heng, CAO Ping, et al. Size effect experimental study of strength and deformation in different height-to-diameter ratio soft rocks[J]. Journal of Central South University, 2010, 41 (3): 1073 – 1078. (in Chinese))
    [4] 洪 亮 , 李夕兵 , 马春德 , 等 . 岩石动态强度及其应变率灵敏性的尺寸效应研究 [J]. 岩石力学与工程学报 , 2008, 27 (3): 526 – 533. (HONG Liang, LI Xi-bing, MA Chun-de, et al. Study on size effect of rock dynamic strength and strain rate sensitivity[J]. Chinese Journal of Rock Mechanics and Engineering, 2008, 27 (3): 526 – 533. (in Chinese))
    [5] 杨圣奇 , 苏承东 , 徐卫亚 . 岩石材料尺寸效应的试验和理论研究 [J]. 工程力学 , 2005, 22 (4): 112 – 118. (YANG Sheng-qi, SU Cheng-dong, XU Wei-ya. Experimental and theoretical study of size effect of rock material[J]. Engineering Mechanics, 2005, 22 (4): 112 – 118. (in Chinese))
    [6] 徐 磊 , 任青文 . 分形节理抗剪强度尺寸效应的数值试验 [J]. 采矿安全与工程学报 , 2007, 24 (4): 405 – 408. (XU Lei, REN Qing-wen. Numerical test for size effect of shear strength of fractal joints[J]. Journal of Mining and Safety Engineering, 2007, 24 (4): 405 – 408. (in Chinese))
    [7] 梁正召 , 唐春安 , 唐世斌 , 等 . 岩石紧凑拉伸断裂过程及其尺寸效应的三维数值模拟 [J]. 计算力学学报 , 2007, 24 (3): 334 – 340. (LIANG Zheng-zhao, TANG Chun-an, TANG Shi-bin, et al. Numerical study on three dimensional compact tension fracture of single notched rocks and associated scale effects by parallel computing[J]. Chinese Journal of Computational Mechanics, 2007, 24 (3): 334 – 340. (in Chinese))
    [8] 中国水电顾问集团华东勘测设计研究院 . 金沙江白鹤滩水电站柱状节理玄武岩工程地质研究报告 [R]. 杭州 : 中国水电顾问集团华东勘测设计研究院 , 2006. (East China Investigation and Design Institute of CHECC. Engineering geology's research report of columnar jointed basalt at Baihetan Hydropower Station on Jinsha River[R]. Hangzhou: East China Investigation and Design Institute of CHECC, 2006.(in Chinese))
    [9] 徐卫亚 , 郑文棠 , 宁 宇 , 等 . 柱状节理坝基岩体三维各向异性数值分析 [J]. 岩土力学 , 2010, 31 (3): 949 – 955. (XU Wei-ya, ZHENG Wen-tang, NING Yu, et al. 3D anisotropic numerical analysis of rock mass with columnar joints for dam foundation[J]. Rock and Soil Mechanics, 2010, 31 (3): 949 – 955. (in Chinese))
    [10] 郑文棠 , 徐卫亚 , 邬爱清 , 等 . 柱状节理开挖模拟洞数值原位试验 [J]. 岩土力学 , 2008, 29 ( 增刊 1): 253 – 257. (ZHENG Wen-tang, XU Wei-ya, WU Ai-qing, et al. Numerical in situ testing of excavation experimental cavity on columnar joints[J]. Rock and Soil Mechanics, 2008, 29 (S1): 253 – 257. (in Chinese))
    [11] 宁 宇 , 徐卫亚 , 郑文棠 , 等 . 白鹤滩水电站拱坝及坝肩加固效果分析及整体安全度评价 [J]. 岩石力学与工程学报 , 2008, 27 (9): 1890 – 1898. (NING Yu, XU Wei-ya, ZHENG Wen-tang, et al. Reinforcement effect analysis and global safety evaluation of arch dam and abutment of Baihetan Hydropower Station[J]. Chinese Journal of Rock Mechanics and Engineering, 2008, 27 (9): 1890 – 1898. (in Chinese))
    [12] 孟国涛 . 柱状节理岩体各向异性力学分析及其工程应用 [D]. 南京 : 河海大学 , 2007. (MENG Guo-tao. Geomechanical analysis of anisotropic columnar jointed rock mass and its application in hydropower engineering[D]. Nanjing: Hohai University, 2007. (in Chinese))
    [13] 郑文棠 . 不规则柱状节理岩石力学及在高边坡坝基岩石工程中的应用 [D]. 南京 : 河海大学 , 2008. (ZHENG Wen-tang. Rock mechanics of irregular columnar jointed basaltic mass and its application in high slope and dam foundation[D]. Nanjing: Hohai University, 2008. (in Chinese))
    [14] 宁 宇 , 徐卫亚 , 郑文棠 , 等 . 柱状节理岩体随机模拟及其表征单元体尺度研究 [J]. 岩石力学与工程学报 , 2008, 27 (6): 1202 – 1208. (NING Yu, XU Wei-ya, ZHENG Wen-tang, et al. Study of random simulation of columnar jointed rock mass and its representative elementary volume scale[J]. Chinese Journal of Rock Mechanics and Engineering, 2008, 27 (6): 1202 – 1208. (in Chinese))
    [15] 刘顺桂 , 池永翔 , 王思敬 , 等 . 柱状节理玄武岩体抗剪强度参数尺寸效应研究 [J]. 工程地质学报 , 2009, 17 (3): 367 – 370. (LIU Shun-gui, CHI Yong-xiang, WANG Si-jing, et al. Size effect on shear strength of basalt rock mass with columnar joints[J]. <> Journal of Engineering Geology, 2009, 17 (3): 367 – 370. (in Chinese))
    [16] 赵海斌 . 层状岩体力学参数试验及数值仿真研究 [D]. 南京 : 河海大学 , 2009. (ZHAO Hai-bin. Test and numerical simulation study on mechanical parameters of layered rock mass[D]. Nanjing: Hohai University, 2009. (in Chinese))
    [17] 周培德 . 计算几何—算法设计与分析 [M]. 第二版 . 北京 : 清华大学出版社 , 2005. (ZHOU Pei-de. Calculating geometry — design and analysis of arithmetic[M]. 2nd ed. Beijing: Tsinghua University Press, 2005. (in Chinese))
    [18] 谢顺平 , 王结臣 , 冯学智 , 等 . 基于节点逼近提取的平面点集 Voronoi 图构建方法 [J]. 测绘学报 , 2007, 36 (4): 436 – 442. (XIE Shun-ping, WANG Jie-chen, FENG Xue-zhi, et al. Algorithm for constructing voronoi diagram of planar points based on approximating and extracting vertices[J]. Acta Geodaetica et Cartographica Sinica, 2007, 36 (4): 436 – 442. (in Chinese))
    [19] HELD M. VRONI: an engineering approach to the reliable and efficient computation of voronoi diagrams of points and line segments[J]. Computational Geometry, 2001, 18 (1): 95 – 123.
    [20] 傅廷亮 , 尹雪涛 , 张 扬 . Voronoi 算法模型及其程序实现 [J]. 计算机仿真 , 2006, 23 (10): 89 – 92. (FU Ting-liang, YIN Xue-tao, ZHANG Yang. Voronoi algorithm model and the realization of its program[J]. Computer Simulation, 2006, 23 (10): 89 – 92. (in Chinese))
    [21] ALBERS G, et al. Voronoi diagrams of moving points[J]. International Journal of Computational Geometry and Applications, 1998, 8 (3): 365 – 380.
    [22] 白永健 , 黄润秋 , 巨能攀 , 等 . 高陡岩质边坡稳定性三维离散元分析 [J]. 工程地质学报 , 2008, 16 (5): 592 – 597. (BAI Yong-jian, HUANG Run-qiu, JU Neng-pan, et al. 3DEC stability analysis of high and steep rock slope[J]. Journal of Engineering Geology, 2008, 16 (5): 592 – 597. (in Chinese))
    [23] 程东幸 , 潘 炜 , 刘大安 , 等 . 锚固节理岩体等效力学参数三维离散元模拟 [J]. 岩土力学 , 2006, 27 (12): 2127 – 2132. (CHENG Dong-xing, PAN Wei, LIU Da-an, et al. 3DEC modeling of equivalent mechanical parameters in anchored jointed rock mass[J]. Rock and Soil Mechanics, 2006, 27 (12): 2127 – 2132. (in Chinese))
    [24] 中国水电顾问集团华东勘测设计研究院 . 金沙江白鹤滩各向异性岩体力学分析及坝基岩体稳定研究报告 [R]. 杭州 : 中国水电顾问集团华东勘测设计研究院 , 2006. (East China Investigation and Design Institute of CHECC. Research report of anisotropic mechanical analysis and dam base's stability at Baihetan Hydropower Station on Jinsha River[R]. Hangzhou: East China Investigation and Design Institute of CHECC, 2006. (in Chinese))
    [25] 宁 宇 . 柱状节理岩体等效强度与屈服准则研究 [D]. 南京 : 河海大学 , 2009. (NING Yu. Study on equivalent anisotropic strength and yield criterion of columnar jointed rock mass[D]. Nanjing: Hohai University, 2009. (in Chinese))
    [26] SINGH B. Continuum characterization of jointed rock masses[J]. International Journal of Rock Mechanics and Mining Sciences, 1973, 10 (4): 311.
