New testing technology for large-diameter cast-in-situ pile integrity based on temperature measurement of hydration heat of concrete
-
摘要: 现有的大直径灌注桩的完整性检测技术存在一定的不足与缺陷。提出了基于混凝土水化热的大直径灌注桩桩身完整性检测新技术。无论何种桩身缺陷,同正常混凝土的相比,在水化、凝结、硬化过程中,释放热量普遍偏少。桩身夹泥等缺陷体甚至不释放热量。同时,缺陷体对热量的传导能力普遍较差。可以通过精确测量大直径灌注桩混凝土水化热而产生的温度梯度,进而判定桩身完整性。通过现场试验验证了该技术的可行性,值得深入研究与进一步推广应用。Abstract: There is certain lack in the current integrity tests on large-diameter cast-in-situ piles. A new technology is proposed based on the hydration heat of concrete. Compared with the normal concrete, no matter what kind of pile defects, the release of the heat is generally on the low side in the hydration, setting and hardening process. Mud and other pile defects do not even release heat. Meanwhile, the thermal conductivity of pile defects is generally poor. Concrete hydration heat and the resulting temperature gradient of the large-diameter cast-in-situ piles can be measured accurately, and thus the pile integrity is determined. The technical feasibility is demonstrated by field trials, which is worth of application and extension based on next thoroughgoing research.
-
[1] JGJ 106 — 2003 建筑基桩检测技术规范 [S]. 北京 : 中国建筑工业出版社 , 2003. (JGJ106–2003 Technical code for testing of building foundation piles[S]. Beijing: China Architecture and Building Press, 2003. (in Chinese)) [2] 唐丽云 , 杨更社 . 桩基施工对冻土地区桩基热影响分析 [J]. 岩土工程学报, 2010, 32 (9): 1350 – 1353. (TANG Li-yun, YANG Gen-she. Thermal effects of pile construction on pile foundation in permafrost regions[J]. Chinese Journal of Geotechnical Engineering, 2010, 32 (9): 1350 – 1353. (in Chinese)) [3] 李敏健 , 邵 泉 . 广州新电视塔 3.8 m 大直径人工挖孔桩混凝土水化热分析 [J]. 广州建筑 , 2010, 38 (4): 37 – 40. (LI Jian-min, SHAO Quan. Analyzing heat of hydration in 3.8 meter-wild artificial digged-hole pile of Guangzhou New TV Tower[J]. Guangzhou Architecture, 2010, 38 (4): 37 – 40. (in Chinese)) [4] 陈建荣 , 高 飞 . 现代桩基工程试验与检测—新技术•新方法•新设备 [M]. 上海 : 上海科学技术出版社 , 2011. (CHEN Jian-rong, GAO Fei. Modern pile foundation engineering testing & detecting-new technology ﹒ new method ﹒ new equipment[M]. Shanghai: Shanghai Science and Technology Press, 2011. (in Chinese)) [5] 盛 谦 . 混凝土导热系数试验研究 [J]. 大众科技 , 2009(8): 78 – 80. (SHENG Qian. Research on thermal conductivity of concrete[J]. Popular Science, 2009(8): 78 – 80. (in Chinese)) [6] 肖衡林 , 蔡德所 , 何 俊 . 基于分布式光纤传感技术的岩土体导热系数测定方法 [J]. 岩石力学与工程学报 , 2009, 28 (4): 819 – 826. (XIAO Heng-lin, CAI De-su, HE Jun. Measuring method of geomaterial thermal conductivity based on distributed optical fiber sensing technology[J]. Chinese Journal of Rock Mechanics and Engineering, 2009, 28 (4): 819 – 826. (in Chinese))
