土体旋转流变仪开发与土压平衡盾构改性土体塑性流动特性实验

孟庆琳; 屈福政; 李守巨

土体旋转流变仪开发与土压平衡盾构改性土体塑性流动特性实验 English Version

1. 大连理工大学机械工程学院，辽宁大连 116024 ； 2. 大连理工大学工业装备结构分析国家重点实验室，辽宁大连 116024

基金项目: 国家重点基础研究发展计划（973）项目（2007CB714006）

详细信息

作者简介:
孟庆琳 (1981 – ) ，男，天津市人，博士研究生，主要从事盾构密封仓压力平衡问题的数值仿真研究。

中图分类号: U455
计量
- 文章访问数: 01313
- HTML全文浏览量: 0
- PDF下载量: 0612
出版历程
- 发布日期: 2011-10-14

Development of soil rotational rheometer and experiment on plastic flow characteristics of conditioned soil in earth pressure balance shield

1. School of Mechanical Engineering, Dalian University of Technology, Dalian 116024, China; 2. State Key Laboratory of Structural Analysis of Industrial Equipment, Dalian University of Technology, Dalian 116024, China

摘要

摘要: 为了研究土压平衡式盾构机（ EPBS ）密封仓及螺旋输送机内改性土体塑性流动特性，开发了一种土体旋转流变仪。该装置属于可变围压式控制应变型旋转流变仪，通过测量标准十字叶片在给定围压及转速条件下的旋转扭矩，获得被测介质的表观动力黏度。对某地铁施工标段的砂土进行实验测量，实验砂土均采用泡沫改性且改性配比相同，而初始含水率不同（ 5% ， 10% 和 15% ）。测量条件包含 4 个不同围压等级（ 100 ， 200 ， 300 和 400 kPa ）和 7 个不同的叶片转速（ 1/3.4 ， 1/4.1 ， 1/5 ， 1/6.4 ， 1/9 ， 1/15 和 1/30 RPM ）。实验结果表明，泡沫改性砂土的剪切应力与剪切速率之间满足 Bingham 流体模型，属于一种黏塑性非牛顿流体。其黏度系数和屈服应力均随围压的增大而增大。该装置不但可作为一种比较改性土体塑性流动特性优劣的工具，而且可以为仿真获取密封仓及螺旋输送机内压力场分布和研究密封仓压力平衡控制提供实验支撑。
- 土压平衡式盾构 /
- 改性土体 /
- 塑性流动特性 /
- 非牛顿流体
Abstract: A soil rotational rheometer is developed for investigating plastic flow characteristics of conditioned soil in the bulk chamber and the screw conveyor of earth pressure balance shield (EPBS). The device belongs to variable pressure and controlled strain rate rotational rheometer. It is capable of obtaining apparent viscosity by measuring the torsional shear applied to a standard vane with controlled pressure and strain rate. The test sands come from a section of a metro and are prepared by the same conditioning treatments under different initial moisture contents (5%, 10% and 15%). The test conditions contain four confining pressure levels (100, 200, 300 and 400 kPa) and seven vane speeds (1/3.4, 1/4.1, 1/5, 1/6.4, 1/9, 1/15 and 1/30 RPM). The results show that the relationship between shear stress and stain rate of foam conditioned sand fits the Bingham fluid model. It belongs to the visco-plastic non-Newtonian fluid. The viscosity coefficient and the yield stress increase with the increase of the confining pressure. The device is a valuable tool for comparing plastic flow characteristics of conditioned soil in EPBS and the test support for investigating distribution of pressure for simulation of soil flow in the working chamber and along the screw conveyor and developing pressure balance control in EPBS.
- earth pressure balance shield /
- conditioned soil /
- plastic flow characteristic /
- non-Newtonian fluid

HTML全文

参考文献(19)

[1]	MERRITT A, MAIR R J. Mechanics of tunnelling machine screw conveyor: model tests[J]. Géotechnique, 2006, 56 (9): 605 – 615.
[2]	QUEBAUD S, SIBAI M, HENRY J P. Use of chemical foam for improvements in drilling by earth pressure balanced shields in granular soils[J]. Tunnelling and Underground Space Technology, 1998, 13 (2): 173 – 180.
[3]	WILLIAMSON G E, TRAYLOR M T, HIGUCHI M. Soil conditioning for EPB shield tunneling on the South Bay Ocean Outfall[C]// Proceedings of RETC, 1999: 897 – 925.
[4]	JANCSECZ S, KRAUSE R, LANGMAACK L. Advantages of soil conditioning in shield tunnelling: experiences of LRTS Izmir[C]// ALTEN T, et al, eds. Proceedings of International Congress on Challenges for the 21st Century, Balkema, Rotterdam: 865 – 875.
[5]	BOONE S J, ARTIGIANI E, SHIRLAW J N, et al. Use of ground conditioning agents for Earth Pressure Balance machine tunnelling[C]// AFTES, ed. Proceedings of Congress International de Chambery: 313 – 319.
[6]	VINAI R, OGGERI C, PEILA D. Soil conditioning of sand for EPB applications: a laboratory research[J]. Tunnelling and Underground Space Technology, 2008, 23 (3): 308 – 317.
[7]	魏康林 . 土压平衡式盾构施工中“理想状态土体”的探讨 [J] . 城市轨道交通研究 , 2007(1): 67 – 70. (WEI Kang-lin. On the ideal soil in the earth pressure balanced shield tunnelling[J]. Urban Mass Transit, 2007(1): 67 – 70. (in Chinese))
[8]	YOSHIKAWA T. Soil pressure drop of the screw conveyor for shielded machines[C]// Transactions of the Japan Society for Mechanical Engineers, 1996, Part C 62(595): 1197 – 1203.
[9]	BEZUIJEN A, SCHAMINEE P E L. Model experiments using foam simulation the drilling with an EPB shield[R]. GeoDelft Report No. BF 51010. Delft, GeoDelft, 2000.
[10]	BEZUIJEN A, SCHAMINEE P E L. Simulation of the EPB-shield TBM in model tests with foam as additive[C]// Proceedings of Congress on Modern Tunnelling Science and Technology. Balkema, Kyoto, Rotterdam, 2001: 935 – 940.
[11]	沈寿长 . 泥石流流变特性的试验研究 [J]. 水利学报 , 1998, 9 (9): 7 – 13. (SHEN Shou-chang. Experiment of rheology of debris flow[J]. Journal of Hydraulic Engineering, 1998, 9 (9): 7 – 13. (in Chinese))
[12]	刘宝林 , 孔珑 . 水煤浆流动特性及其流变模型确定方法综述 [J]. 煤化工 , 1995(4): 49 – 53. (LIU Bao-lin, KONG Long. A summary of flowing properties of coal-water slurry and determination of rheologic model thereof[J]. Coal Chemical Industry, 1995(4): 49 – 53. (in Chinese))
[13]	陈育民 , 刘汉龙 , 邵国建 , 等 . 砂土液化及液化后流动特性试验研究 [J]. 岩土工程学报 , 2009, 31 (9): 1408 – 1413. (CHEN Yu-min, LIU Han-long, SHAO Jian-guo, et al. Laboratory tests on flow characteristics of liquefied and post-liquefied sand[J]. Chinese Journal of Geotechnical Engineering, 2009, 31 (9) : 1408 – 1413. (in Chinese))
[14]	KARMAKAR S, KUSHWAHA R L. Development and laboratory evaluation of a rheometer for soil visco-plastic parameters[J]. Journal of Terramechanics, 2007, 44 (2): 197 – 204.
[15]	SKELLAND A H P. Non-Newtonian flow and heat transfer [D]. New York: John Wiley and Sons Inc, 1967.
[16]	ZISIS T, MITSOULIS E. Visco-plastic flow around a cylinder kept between parallel plates[J]. J Non-Newtonian Fluid Mech, 2002, 105 : 1 – 20.
[17]	BERIS A N, TSAMOPOULOS J A, Armstrong R C, et al. Creeping motion of a sphere through a Bingham plastic[J]. J Fluid Mech, 1985, 158 : 219 – 244.
[18]	CHHABRA R P, RICHARDSON J F. Non-Newtonian flow in the process industries, fundamentals and engineering applications[D]. Oxford: Butterworth Heinemann Publishing Ltd., 1999.
[19]	ASTM D2573 — 72. Standard test method for field vane shear test in cohesive soil[S]. 1972.
