EPS 粒径对轻量土抗剪强度的影响规律

侯天顺, 徐光黎

侯天顺, 徐光黎. EPS 粒径对轻量土抗剪强度的影响规律[J]. 岩土工程学报, 2011, 33(10): 1634-1641.
引用本文: 侯天顺, 徐光黎. EPS 粒径对轻量土抗剪强度的影响规律[J]. 岩土工程学报, 2011, 33(10): 1634-1641.
shu
HOU Tian-shun, XU Guang-li. Influence law of EPS size on shear strength of light weight soil[J]. Chinese Journal of Geotechnical Engineering, 2011, 33(10): 1634-1641.
Citation: HOU Tian-shun, XU Guang-li. Influence law of EPS size on shear strength of light weight soil[J]. Chinese Journal of Geotechnical Engineering, 2011, 33(10): 1634-1641.
shu

EPS 粒径对轻量土抗剪强度的影响规律  English Version

  • 1. 西北农林科技大学水利与建筑工程学院，陕西 杨凌 712100 ； 2. 中国地质大学生物地质与环境地质教育部重点实验室，湖北 武汉 430074

基金项目: 教育部重点实验室开放基金项目 (BGEGF200814)
详细信息
    作者简介:

    侯天顺 (1981 – ) ，男，湖北省郧西县人，博士，讲师，主要从事土力学基本理论与土体工程性质方面的教学与科研工作。

  • 中图分类号: TU411.3

Influence law of EPS size on shear strength of light weight soil

  • 1. College of Water Resources and Architectural Engineering, Northwest A&F University, Yangling 712100, China; 2. Key Lab of Biogeology and Environmental Geology of Ministry of Education, China University of Geosciences, Wuhan 430074, China

摘要

    摘要
  • 摘要: 为了确定 EPS 粒径对轻量土抗剪强度的影响，通过直剪试验研究了水泥掺入比 12% 、 20% ， EPS 颗粒体积比 40% 的 3 种 EPS 粒径 混合土的抗剪强度特性。结果表明： 轻量土的剪应力–剪切位移关系曲线有硬化、软化两种形态，取决于水泥掺入比、法向应力等因素。抗剪强度包线为折线型包线，与传统结构性土体包线形态一致。水泥掺入比与 EPS 颗粒体积比相同时，随着 EPS 粒径增大，轻量土密度不变，抗剪强度减小，单价降低，但强度衰减率远远低于单价降低率；剪切面上 EPS 发生剪缩与剪断，受水泥掺入比、 EPS 粒径的控制；黏聚力随 EPS 粒径增大而减小，内摩擦角没有显著变化规律。轻量土剪切破坏过程，可以划分为变形协调、逐渐破损、纯摩擦 3 个阶段。提出了固化土、 EPS 3 界面接触抗剪强度模型，从理论上证明了混合土强度随 EPS 粒径增大而衰减的规律。根据混合土的强度衰减率低于单价降低率，推荐实际生产过程中可以采用 3 ～ 5 mm 的 EPS 球粒，进行配方寻优，适当降低造价。
    Abstract: To determine influence of EPS (Expanded polystyrene) size on shear strength of light weight soil, the shear strength characteristics of mixed soil (cement mixed ratio of 12% and 20% and EPS volume ratio of 40%) with three kinds of EPS sizes are studied by means of direct shear tests. The results show that there are two types of shear stress-shear displacement relation curves: strain hardening and strain softening, and they are decided by cement mixed ratio, normal stress and so on. Its shear strength envelope is broken line, and it has the same shape as that of traditional structural soil. When the cement mixed ratio and EPS volume ratio are the same, with the increase of the EPS size, the wet density of light weight soil is constant, the shear strength decreases, the unit price reduces, but the strength reduction rate is far below the reduction rate of the unit price. Shear contraction or shear fracture may occur in EPS on shear planes, and it is decided by the cement mixed ratio and EPS size. Cohesion decreases with the increase of the EPS size, and internal friction angle has no obvious variation law. Shear failure processes of light weight soil can be divided into three stages: deformation coordination, progressive damage and pure friction. A shear strength model for 3 interfaces (stabilized soil-stabilized soil, stabilized soil-EPS, EPS-EPS) is brought forward. The strength reduction law of light weight soil with the increase of the EPS size is theoretically proved. According to the fact that the strength reduction rate is far below the reduction rate of unit price, EPS beads whose diameter is 3-5 mm should be used in construction, and prescription can be optimized, then the cost can be reduced appropriately.
    • HTML全文
    • 参考文献(21)
  • [1] 董金梅 . 聚苯乙烯轻质混合土工程特性的试验研究 [D]. 南京 : 河海大学 , 2005. (DONG Jin-mei. Study on the engineering characteristic of light heterogeneous soil mixed expanded polystyrene[D]. Nanjing: Hohai University, 2005. (in Chinese))
    [2] 姬凤玲 . 淤泥泡沫塑料颗粒轻量土力学特性研究 [D]. 南京 : 河海大学 , 2005. (JI Feng-ling. Study on mechanical properties of light weight bead-treated soil made from silt[D]. Nanjing: Hohai University, 2005. (in Chinese))
    [3] 山田純男 , 長坂勇二 , 西田登 , 等 . 発生土スチロール片と砂を混合した軽量土 [J]. 土と基礎 , 1989, 37 (2): 25 – 30. (YAMADA S, NAGASAKA Y, NISHIDA N, et al. Foamed particle light-weight soil with sand[J]. Soil and Foundations, 1989 , 37 ( 2 ) : 25 – 30. (in Japanese))
    [4] YAJIMA J, MYDIN S H. Mechanical properties of the unsaturated foam composite light-weight soil[C]// 4th International Conference on Unsaturated Soils. United States: American Society of Civil Engineers, 2006(147): 1639 – 1650.
    [5] YAJIMA J, MARUO S, OGAWA S. Deformation and strength properties of foam composite light-weight soil[J]. Doboku Gakkai Rombun Hokokushu, 1994(499): 197 – 205.
    [6] KIKUCHI Y, NAGATOME T, FUKUMOTO H, et al. Absorption property evaluation of light weight soil with air foam under wet sand condition[J]. Zairyo/Journal of the Society of Materials Science, 2008, 57 (1): 56 – 59.
    [7] OTANI J, MUKUNOKI T, KIKUCHI Y. Visualization for engineering property of in-situ light weight soils with air foams[J]. Soils and Foundations, 2002, 42 (3): 93 – 105.
    [8] OH S W, LEE J, KWON Y C, et al. Bearing capacity of light weight soil using recycled styrofoam beads[C]// Proceedings of the International Offshore and Polar Engineering Conference. Kitakyushu: International Society of Offshore and Polar Engineers, 2002, 12 : 670 – 674.
    [9] 多孔聚 苯乙烯材料施工法 (EPS 施工法 ) [J]. 白敏华 , 译 . 铁道建筑 , 1989(5): 40 – 41. (Construction method of porous expanded polystyrene(EPS method)[J]. BAI Min-hua, trans. Railway Engineering, 1989(5): 40 – 41. (in Chinese))
    [10] 村田修 . 轻质土工材料 EPS[J]. 潘君牧 , 译 . 路基工程 , 1991(2): 75 – 78. (MURATA S. Light-weight geomaterial-EPS[J]. PAN Jun-mu, trans. Subgrade Engineering, 1991(2): 75 – 78. (in Chinese))
    [11] 横田圣哉 , 三嶋信雄 . 泡沫混合轻量土 [J]. 于晓波 , 译 . 路基工程 , 1997(4): 81 – 86. (YOKOTA, MISHIMA N. Foam light-weight soil[J]. YU Xiao-bo, trans. Subgrade Engineering, 1997(4): 81 – 86. (in Chinese))
    [12] 三木博史 . 发泡空心颗粒混合轻量土在海堤加高工程中的应用 [J]. 于晓波 , 译 . 路基工程 , 1998(2): 85 – 89. (MIKI H. Foamed particle light-weight soil and its application in seawall engineering[J]. YU Xiao-bo, trans. Subgrade Engineering, 1998(2): 85 – 89. (in Chinese))
    [13] 马时冬 . 聚苯乙烯泡沫塑料轻质填土 (SLS) 的特性 [J]. 岩土力学 , 2001, 22 (3): 245 – 248. (MA Shi-dong. The properties of stabilized light soil(SLS) with expanded polystyrene[J]. Rock and Soil Mechanics, 2001, 22 (3): 245 – 248. (in Chinese))
    [14] 刘汉龙 , 朱 伟 , 高玉峰 , 等 . 一种轻质混合土及生产方法 : 中国 , CN1373261[P].2002-10-09. (LIU Han-long, ZHU Wei, GAO Yu-feng, et al. A sort of light-weight soil and its production method: China, CN1373261[P]. 2002-10-09. (in Chinese))
    [15] 陈忠平 , 邓 江 , 王树林 , 等 . 一种轻质填土体结构及其施工方法 : 中国 , CN1422826[P]. 2003-06-04. (CHEN Zhong-ping, DENG Jiang, WANG Shu-lin, et al. A sort of light-weight filling structure and its construction method: China, CN1422826[P]. 2003-06-04. (in Chinese))
    [16] 顾欢达 , 顾 熙 , 申 燕 , 等 . 发泡颗粒轻质土材料的基本性质 [J]. 苏州科技学院学报 , 2003, 16 (4): 44 – 48. (GU Huan-da, GU Xi, SHEN Yan, et al. The fundamental properties of light soil mixed with foamed beads[J]. Journal of University of Science and Technology of Suzhou, 2003, 16 (4): 44 – 48. (in Chinese))
    [17] 朱 伟 , 秦建设 , 钟小春 , 等 . 一种土工实用的气泡发泡装置 : 中国 , CN2614776[P]. 2004-05-12. (ZHU Wei, QIN Jian-she, ZHONG Xiao-chun, et al. A sort of foam production device: China, CN2614776[P]. 2004-05-12. (in Chinese))
    [18] 徐光黎 , 杨银湖 . 轻量土及其在工程中的应用 [J]. 地质科技情报 , 2005, 24 (4): 94 – 98. (XU Guang-li, YANG Yin-hu. Light-weight soils and their applications[J]. Geological Science and Technology Information , 2005, 24 (4): 94 – 98. (in Chinese))
    [19] 黎 冰 . 动荷载下黏土与 EPS 颗粒混合轻质土的变形和强度特性试验研究 [D]. 南京 : 河海大学 , 2007. (LI Bing. Experimental study on the deformation and strength properties of lightweight clay-EPS beads soil under cyclic loading[D]. Nanjing: Hohai University, 2007. (in Chinese))
    [20] 侯天顺 , 徐光黎 . 发泡颗粒混合轻量土三轴应力–应变–孔压特性试验 [J]. 中国公路学报 , 2009, 22 (6): 10 – 17. (HOU Tian-shun, XU Guang-li. Experiment on triaxial pore water pressure-stress-strain characteristics of foamed particle light weight soil[J]. China Journal of Highway and Transport, 2009, 22 (6): 10 – 17. (in Chinese))
    [21] 中华人民共和国水利部 . GB/T50123 — 1999 土工试验方法标准 [S]. 北京 : 中国计划出版社 , 1999. (Ministry of Water Resources, People's Republic of China. GB/T50123 — 1999 Standard for soil test method[S]. Beijing: Chinese Plans Press, 1999. (in Chinese))
