现浇 X 形混凝土桩与圆形桩承载性状对比试验研究

张敏霞; 刘汉龙; 丁选明; 王智强

现浇 X 形混凝土桩与圆形桩承载性状对比试验研究 English Version

张敏霞^1,2,
刘汉龙^1,3,
丁选明^1,3,
王智强^1,3

1. 河海大学岩土力学与堤坝工程教育部重点实验室，江苏南京 210098 ； 2. 河南理工大学土木工程学院，河南焦作 454000 ； 3. 河海大学岩土工程科学研究所，江苏南京 210098

基金项目: 江苏省自然科学基金创新学者攀登项目（BK2008040）；江苏省青蓝工程创新团队项目；教育部博士点基金项目（2010516211）；河海大学中央高校基本科研业务费与专项资金项目（2010B29914）

详细信息

作者简介:
张敏霞 (1979 – ) ，女，博士研究生，讲师，主要从事地基处理与土动力学方面的教学与科研工作。

中图分类号: TU47
计量
- 文章访问数: 1239
- HTML全文浏览量: 0
- PDF下载量: 563
出版历程
- 发布日期: 2011-09-14

Comparative tests on bearing capacity of cast-in-situ X-shaped concrete piles and circular pile

(1. Key Laboratory of Ministry of Education for Geomechanics and Embankment Engineering, Hohai University, Nanjing 210098, China; 2. College of Civil Engineering of Henan Polytechnic University, Jiaozuo 454000, China; 3. Geotechnical Research Institute, Hohai University, Nanjing 210098, China)

摘要

摘要: 通过现浇 X 形混凝土桩与等截面圆形桩、等周长圆形桩足尺模型静载试验，对比分析了试验各桩桩身轴力分布、桩侧摩阻力以及桩端阻力的发展情况，并对 X 形桩的荷载传递机理进行了深入研究。试验结果表明：对于本次研究对象的 X 形桩，与等截面圆形桩相比：其极限承载力及桩身单位体积混凝土极限承载力均为等截面圆形桩的 1.32 倍，与等周长圆形桩相比：其极限承载力及桩身单位体积混凝土极限承载力分别为等周长圆形桩的 0.84 倍与 1.47 倍。从提高桩基承载力，节约桩身混凝土用量角度来看， X 形桩是一种具有较高的竖向承载力且造价低的新型桩，因此该桩在软土地基中有广泛的推广和应用价值。
- 现浇 X 形混凝土桩 /
- 静载荷试验 /
- 荷载传递机理 /
- 极限承载力
Abstract: Through the full scale static load model tests on the cast-in-situ X-shaped concrete piles and circular piles with the same cross-section area and circular p iles with the same perimeter, the distribution of pile axial force and the development of pile shaft resistance and pile toe resistance are comparatively analyzed, and the load transfer mechanism of the X-shaped piles is studied. The tes t results show that: for the X-shaped piles, the ultimate bearing capacity and the bearing capacity per unit volume of pile concrete are both 1.32 times those of the circular pile in the same area, and 0.84 times and 1.47 times respectively those of the circular piles with the same perimeter. From the view of improving the bearin g capacity of the pile and saving the amount of pile concrete, the X-shaped pile is a new pile with is high vertical bearing capacity and low cost, therefore it has the extremely high promotion and application value in soft soil foundation.
- cast-in-situ X-shaped concrete pile /
- static load test /
- load transfer mechanism /
- ultimate bearing capacity

HTML全文

参考文献(20)

[1]	CHARLES W W N, TERENCE L Y Y, JONATHAN H M L, et al. Side resistance of large diameter bored piles socketed into decomposed rock[J]. Journal of Geotechnical and Geoenvironmental Engineering , ASCE, 2001, 127 (8): 642 – 657.
[2]	高广运 , 蒋建平 , 顾宝和 . 砂卵石层上大直径扩底桩墩竖向承载力性状 [J]. 岩土力学 , 2004, 25 (3): 359 – 362. (GAO Guang-yun, JIANG Jian-ping, GU Bao-he. Vertical bearing behavior large diameter short-belled pier in sand-cobble layer[J]. Rock and Soil Mechanics, 2004, 25 (3): 359 – 362. (in Chinese))
[3]	张忠苗 , 吴世明 , 包风 . 钻孔灌注桩桩底后注浆机理与应用研究 [J]. 岩土工程学报 , 1999, 21 (6): 681 – 686. (ZHANG Zhong-miao, WU Shi-ming, BAO Feng. Study of mechanism and application on bored pile end grouting[J]. Chinese Journal of Geotechnical Engineering , 1999, 21 (6): 681 – 686. (in Chinese))
[4]	DAN Brown . Effect of construction on axial capacity of drilled foundations in piedmont soils[J] . Journal of Geotechnical and Geoenvironment Engineering, 2002, 128 (12): 967 – 973.
[5]	沈扬 , 陈育民 , 胡志刚 , 等 . 哑铃桩模型试验与承载力计算方法研究 [J]. 防灾减灾工程学报 , 2009, 29 (4): 428 – 432. (SHEN Yang, CHEN Yu-min, HU Zhi-gang, et al. Model tests and calculation method study on dumbbell pile’s bearing capacity[J]. Journal of Disaster Prevention and Mitigation Engineering , 2009, 29 (4): 428 – 432. (in Chinese))
[6]	WEI Jin qi , HESHAM M. Experimental study of axial behaviour of tapered piles[J]. Canadian Geotechnical Journal , 1998 , 35 : 641 – 654.
[7]	MAHMOUD Ghazavi. Analysis of kinematic seismic response of tapered piles[J]. Geotech Geol Eng, 2007(25): 37 – 44.
[8]	葛中华 , 殷宗泽 , 马智杰 . 提高超高层建筑大直径灌注桩承载力的试验和研究 [J]. 岩土工程学报 , 1999, 21 (1): 31 – 33. (GE Zhong-hua, YIN Zong-ze, MA Zhi-jie. The study and test to enhance bearing capacity of the large diameter pile under the high rise building[J]. Chinese Journal of Geotechnical Engineering , 1999, 21 (1): 31 – 33. (in Chinese))
[9]	周国庆 , 梁恒昌 , 赵光思 . 桩侧土注浆提高单桩承载力试验研究 [J]. 中国矿业大学学报 , 2005, 34 (3): 265 – 269 . (ZHOU Guo-qing, LIANG Heng-chang, ZHAO Guang-si. Test of grouting surrounding pile for improving bearing capacity[J]. Journal of China University of Mining & Technology , 2005, 34 (3): 265 – 269 . (in Chinese))
[10]	沈保汉 , 贺德新 , 刘振亮 , 等 . DX 多节挤扩桩的产生及特点 [J] . 工业建筑 , 2004, 34 (3): 1 – 8. ( SHEN Bao-han, HE De-xin, LIU Zheng-liang, et al. DX pile with multi-unde-extruding branches [J] . Industrial Construction, 2004, 34 (3) : 1 – 8. (in Chinese))
[11]	吴兴龙 , 李光茂 , 魏章和 . DX 桩单桩承载力设计分析 [J] . 岩土工程学报 , 2000, 22 (5): 581 – 585. (WU Xing-long, LI Guang-mao, WEI Zhang-he. Design and analysis for the end-capacity of the single DX pile [J]. Chinese Journal of Geotechnical Engineering, 2000, 22 (5): 581 – 585. (in Chinese))
[12]	陆见华 , 陆小曼 . Y 形 - 异形沉管灌注桩的试验研究 [J] . 浙江水利水电专科学校学报 , 2002, 14 (4): 40 – 42. (LU Jian-hua, LU Xiao-man . Field test and study of Y- shaped pile-an unusual type of driven cast-in-situ concrete pile[J] . J Zhejiang Wat Cons & Hydr, 2002, 14 (4): 40 – 42. (in Chinese))
[13]	王新泉 , 陈永辉 , 刘汉龙 . Y 型沉管灌注桩荷载传递机制的现场试验研究 [J] . 岩石力学与工程学报 , 2008, 27 (3): 615 – 623. (WANG Xin-quan, CHEN Yong-hui, LIU Han-long . In-situ study on load transfer mechanism of Y-shaped vibro-pile[J]. Chinese Journal of Rock Mechanics and Engineering, 2008, 27 (3): 615 – 623. (in Chinese))
[14]	刘汉龙 . 现浇 X 形钢筋混凝土桩技术 [P]. 专利号 200710020306 ， 2007. ( LIU Han-long. Cast-in-situ X-shaped reinforced concrete piles[P]. Patent No. 2007100203063, 2007. (in Chinese))
[15]	王智强 . 现浇 X 形桩竖向承载特性研究 [D]. 南京 : 河海大学 , 2009. ( WANG Zhi-qiang. Study on the vertical bearing characteristics of cast-in-place X-section concrete pile[D]. Nanjing: Hohai University, 2009. (in Chinese))
[16]	袁佶 . X 形桩水平承载性能足尺模型试验研究 [D]. 南京 : 河海大学 , 2009. (YUAN Ji. Research on full-scale model test for the behavior of X-section pile under lateral load [D]. Nanjing: Hohai University, 2009. (in Chinese))
[17]	刘汉龙 , 谭慧明 , 彭劼 , 等 . 大型桩基模型试验系统的开发 [J]. 岩土工程学报 , 2009, 31 (3): 452 – 457. ( LIU Han-long, TAN Hui-ming, PENG Jie, et al. Development of large scale pile foundation model test system[J]. Chinese Journal of Geotechnical Engineering, 2009, 31 (3): 452 – 457. (in Chinese))
[18]	中华人民共和国建设部 . GB50007 — 2002 建筑地基基础设计规范 [S]. 北京 : 中国建筑工业出版社 , 2002. ( The People's Republic of China Ministry of Construction. GB 50007 — 2002 Code for design of building foundation[S]. Beijing: China Building Industry Press, 2002. (in Chinese))
[19]	中华人民共和国建设部 . JGJ94 — 2008 建筑桩基技术规范 [S]. 北京 : 中国建筑工业出版社 , 2008. (The People's Republic of China Ministry of Construction. JGJ94 — 2008 Technical code for building pile foundations[S]. Beijing: China Building Industry Press, 2008. (in Chinese))
[20]	刘汉龙 , 刘芝平 , 雍君 , 等 . 现浇 X 型混凝土桩的荷载传递机理初探 [J] . 防灾减灾工程学报 , 2009, 29 (3): 267 – 272. (LIU Han-long, LIU Zhi-ping, YONG Jun, et al. Study on load transfer mechanism of cast-in-place x-shaped piles[J]. Journal of Disaster Prevention and Mitigation Engineering, 2009, 29 (3): 267 – 272. (in Chinese))
