泥浆零排放处理技术及分离土的工程特性研究

张忠苗; 房凯; 王智杰; 骆嘉成

泥浆零排放处理技术及分离土的工程特性研究 English Version

1. 浙江大学岩土工程研究所，浙江杭州 310058 ； 2. 温州浙南地质工程有限公司，浙江温州 325006

详细信息

作者简介:
张忠苗 (1961 – ) ，男，浙江宁海人，博士，教授，博士生导师，主要从事基础工程与桩基础的研究、教学、检测工作。

中图分类号: TU41
计量
- 文章访问数: 1321
- HTML全文浏览量: 9
- PDF下载量: 717
出版历程
- 发布日期: 2011-09-14

Zero discharge treatment technology for slurry and engineering properties of separated soil

(1. Institute of Geotechnical Engineering, Zhejiang University, Hangzhou 310058, China; 2. Wenzhou South Zhejiang Geological Engineering Co., Ltd., Wenzhou 325006, China)

摘要

摘要: 建筑垃圾已经引起社会越来越多的关注，针对城市建设中泥浆处理所面临的难题，介绍了一种工程钻孔泥浆处理技术，该分离技术以实现污染物零排放为目的，包括泥浆净化，化学絮凝和压滤处理 3 部分，经过处理，泥浆成功分离为土和水；对经过泥水分离后的土的物理力学特性以及土的微观结构进行了分析，结果表明分离土结构致密，压缩模量达到 23 MPa ，计算承载力是沉渣土的 7 倍，说明泥浆分离后有良好的强度和变形特性，已由工程垃圾变为工程材料，具备了再次利用的可能，分离的砂可用于砂浆制备，分离的土饼可用于回填、制砖等。
- 泥浆 /
- 固液分离 /
- 再利用 /
- 工程特性
Abstract: Construction wastes have attracted more and more public attention with the development of the urban construction. A waste drilling slurry treatment process is introduced to solve the problem of slurry treatment. The process, with the aim of zero discharge of pollutants, includes three steps: slurry purification, flocculation and pressure filtration, after which the slurry is separated into soil and water. The engineering properties and microstructure of the separated soil are studied. The experimental results show that the separated soil, with a compact structure, has a modulus of compressibility of 23 MPa and a calculated bearing capacity seven times that of the sediment. It is demonstrated that the separated soil has good properties of deformation and strength. Thus, the waste slurry has changed from the construction waste to the construction material and can be recycled. The separated sand can be used as the raw material for cement mortar while the separated soil can be used for backfill or brick production.
- slurry /
- solid-liquid separation /
- recycle /
- engineering property

HTML全文

参考文献(16)

[1]	彭园 , 杨旭 , 孙长健 . 废弃泥浆无害化处理方法研究 [J]. 环境科学与管理 , 2007, 32 (4): 102 – 104. (PENG Yuan, YANG Xu, SUN Chang-jian. The overview of the way to recycle municipal domestic refuse[J]. Environmental Science and Management, 2007, 32 (4): 102–104. (in Chinese ))
[2]	叶雅文 , 张建国 , 邓皓 . 对国内废泥浆固液分离及后处理的研究 [J]. 江汉石油学院学报 , 1990, 12 (1): 46 – 51. (YE Ya-wen, ZHANG Jian-guo, DEN Hao. An experimental study on solid-liquid separation of some China’s waste drilling muds and their follow-up treatment[J]. Journal of Jianghan Petroleum Institute, 1990, 12 (1): 46 – 51. (in Chinese))
[3]	董娅玮 . 废弃钻井泥浆固化处理技术研究 [D]. 西安 : 长安大学 , 2009. (DONG Ya-wei. Study on solidification treatment technology of waste drilling mud[D]. Xi'an: Changan University, 2009. (in Chinese ))
[4]	董仕明 , 王平全 , 陈志勇 , 等 . 油气田钻井废弃泥浆处理技术 [J]. 天然气工业， 2008, 28 (2): 87 – 89. (DONG Shi-ming, WANG Ping-quan, CHEN Zhi-yong, et al. Treatment technology of oil and gas fields waste drilling muds[J]. Tianranqi Gongye, 2008, 28 (2): 87 – 89. (in Chinese))
[5]	KAWACHI T, DUE P T, KATSUMI T, et al. Treatment and utilization of waste sludge/slurry from construction works in Japan[C]// Environmental Geotechnics, 1996: 832 – 837.
[6]	薄利 . 泥水处理技术在泥水盾构隧道施工中的应用 [J]. 隧道建设 , 2007, 27 (6): 66 – 70. (BO Li. Application of slurry treatment technology in construction of tunnels bored by slurry shield machines[J]. Journal of Engineering Geology, 2007, 27 (6): 66 – 70. (in Chinese ))
[7]	HELMUT GROHS. Cost-efficient regeneration of bore slurry for driving of Weser tunnel[J]. Aufbereitungs Technik/Mineral Processing, 2002, 43 (11): 30-37.
[8]	龙莉波 . 泥浆净化装置在钻孔灌注桩施工中的应用 [J]. 建筑施工， 2007, 29 (6): 392 – 394. (LONG Li-bo. Application of slurry depuration device to bored cast-in-place pile construction [J]. Building Construction, 2007, 29 (6): 392 – 394. (in Chinese ))
[9]	范英宏 , 潘智 , 刘建华 , 等 . 高速铁路桥梁施工废弃泥浆处理工艺研究 [J]. 铁道建筑 , 2009( 12 ) : 21 – 23. (FAN Ying-hong, PAN Zhi, LIU Jian-hua, et al. Study and application of solidification treatment technology of waste drilling mud in high speed railway bridge construction[J]. Railway Engineering, 2009( 12 ) : 21 – 23. (in Chinese))
[10]	胡承雄 , 马华滨 . 京沪高速铁路废弃泥浆处理现场试验 [J]. 铁道劳动安全卫生与环保 , 2009, 36 (3): 112 – 115. (HU Cheng-xiong, MA Hua-bin. Field experiment on waste drilling field treatment of Beijing Shanghai high speed railway[J]. Railway Occupational Safety Health & Environmental Protection, 2009, 36 (3): 112 – 115. (in Chinese ))
[11]	万玉纲 , 余学海 . 桩基工程泥浆水处理技术 [J]. 环境工程， 1999, 17 (1): 14 – 15. (WAN Yu-gang, YU Xue-hai. Treating technology of waste slurry from pile foundation engineering[J]. Environmental Engineering, 1999, 17 (1): 14 – 15. (in Chinese ))
[12]	魏治海 , 娄秀清 , 刘长志 . 带式压滤机在转炉尘泥脱水中的应用 [J]. 科学工程与技术 , 2010, 10 (14): 3549 – 3553. (WEI Zhi-hai, LOU Xiu-qing, LIU Chang-zhi. The application of belt pressure filter in dehydration of converter residue sludge[J]. Science Technology and Engineering, 2010, 10 (14): 3549 – 3553.(in Chinese))
[13]	龚晓南 . 土力学 [M]. 北京 : 中国建筑工业出版社 , 2002. (GONG Xiao-nan. Soil mechanics[M]. Beijing: China Architecture and Building Press, 2002. (in Chinese ))
[14]	张忠苗 . 桩基工程 [M]. 北京 : 中国建筑工业出版社 , 2007. (ZHANG Zhong-miao. Pile foundation engineering[M]. Beijing: China Architecture and Building Press, 2007. (in Chinese))
[15]	施斌 . 黏性土微观结构研究回顾与展望 [J]. 工程地质学报 , 1996, 4 (1): 39 – 44. (SHI Bin. Review and prospect on the microstructure[J]. Journal of Engineering Geology, 1996, 4 (1): 39 – 44. (in Chinese ))
[16]	陈嘉鸥 , 叶斌 , 郭素杰 . 珠江三角洲黏性土微观结构与工程性质初探 [J]. 岩石力学与工程学报 , 2000, 19 (5): 674 – 678. (CHEN Jia-ou, YE Bin, GUO Su-jie. Primary exploration on engineering properties of softground microstructure in Zhujiang Delta[J]. Chinese Journal of Rock Mechanics and Engineering, 2000, 19 (5): 674 – 678. (in Chinese ))
