黄土地区浅埋暗挖地铁隧道衬砌受力分析

来弘鹏; 谢永利; 刘苗; 许海标

黄土地区浅埋暗挖地铁隧道衬砌受力分析 English Version

1. 长安大学桥梁与隧道陕西省重点实验室，陕西西安 710064 ； 2. 西安市城乡建设委员会，陕西西安 710003 ； 3. 河南省交通规划勘察设计院有限责任公司，河南郑州 450052

详细信息

作者简介:
来弘鹏(1979 – ) ，男，山西平遥人，博士，副教授，主要从事隧道结构方面的研究。

中图分类号: TD853.34
计量
- 文章访问数: 01273
- HTML全文浏览量: 0
- PDF下载量: 0666
出版历程
- 发布日期: 2011-08-14

Mechanical characteristics for linings of shallow excavation metro tunnel in loess region

1. Key Laboratory for Bridge and Tunnel of Shaanxi Province, Chang’an University, Xi’an 710064, China; 2. Xi'an Municipal Construction Committee, Xi’an 710003, China; 3. Henan Provincial Communications Planning Survey Design Institute Co., Ltd., Zhengzhou 450052, China

摘要

摘要: 为了解黄土地区浅埋暗挖地铁隧道衬砌结构的受力特征，得出荷载在衬砌结构各部分中的分担比例，以西安地铁 2 号线实体工程为依托，开展了较大规模的现场测试工作，对围岩与初期支护接触压力、初期支护与二次衬砌接触压力及二次衬砌结构应力进行了研究。结果表明：在三连拱大断面地铁隧道中先开挖洞室初期支护各部位所受的围岩压力均大于后开挖洞室初期支护所承受的压力；左、右线中墙顶、底部初期支护承受的压力较大，表明隧道中隔墙承担了较大的上部土体荷载；初期支护与二次衬砌承受的荷载比例为 52.81% 和 47.19% ；二次衬砌混凝土基本受压，左、右中隔墙二次衬砌混凝土受压最大。在标准断面地铁隧道中左、右线墙脚位置初期支护与围岩之间接触压力较大，表明这两位置承受了大部分垂直压力；初期支护与二次衬砌承受的荷载比例为 40% 和 60% ；二次衬砌混凝土基本受压，拱腰及以上位置应力较大，仰拱处应力较小。
- 黄土地铁隧道 /
- 浅埋暗挖 /
- 衬砌 /
- 现场测试 /
- 受力特征
Abstract: In order to precisely understand the mechanical characteristics for secondary linings of shallow excavation metro tunnels in loess region, large scale field tests are conducted at Xi'an metro line No. 2 site. The contacting pressure on the surrounding rock and the initial support system, contacting pressure on the initial supports and secondary linings and the stress of the secondary linings are monitored. The test results indicate that the surrounding rock pressures of each part in the initial support in earlier excavation chamber are larger than those in later excavation chamber of three-arched metro tunnel, and the pressures at the top and bottom parts of left and right center pillars are the largest due to large load at the upper part. The loading ratio is 52.81% and 47.19% respectively for the initial supports and secondary linings. The stress of the secondary linings is pressure stress, which is the largest at the left and right center pillars. The surrounding rock pressures in the wall foot at the left and right on standard section metro tunnel are the largest due to large load at the upper part. The loading ratio is 40% and 60% respectively for the initial supports and secondary linings. The stress of the secondary lining is pressure stress, which is the largest on the upper arch loin and is smaller on the inverted arch.
- loess metro tunnel /
- shallow excavation /
- lining /
- field test /
- mechanical characteristics

HTML全文

参考文献(12)

[1]	王梦恕. 地下工程浅埋暗挖技术通论 [M]. 合肥: 安徽教育出版社, 2004: 683 – 708. ( WANG Meng-shu. Theory and technology of shallow-buried tunnel excavation[M]. Hefei: Anhui Education Press, 2004: 683 – 708. (in Chinese))
[2]	JTG D70 — 2004 公路隧道设计规范 [S]. 2004. (JTG D70 — 2004 Code for design of road tunnel[S]. 2004. (in Chinese))
[3]	TB10003 — 99 铁路隧道设计规范 [S]. 1999. ( TB10003 — 99 Code for design of railway tunnel[S]. 1999. (in Chinese))
[4]	张顶立, 王梦恕, 高军, 等. 复杂围岩条件下大跨隧道修建技术研究 [J]. 岩石力学与工程学报, 2003, 22 (2): 290 – 296. ( ZHANG Ding-li, WANG Meng-shu, GAO Jun, et al. Research on construction technology of large span-tunnel in complex rock[J]. Chinese Journal of Rock Mechanics and Engineering, 2003, 22 (2): 290 – 296. (in Chinese))
[5]	谭忠盛, 喻渝, 王明年, 等. 大断面深埋黄土隧道锚杆作用效果的试验研究 [J]. 岩石力学与工程学报, 2008, 27 (8): 1618 – 1625. ( TAN Zhong-sheng, YU Yu, WANG Ming-nian, et al. Experimental research on bolt anchorage effect on large-section deep-buried tunnel in loess[J]. Chinese Journal of Rock Mechanics and Engineering, 2008, 27 (8): 1618 – 1625. (in Chinese))
[6]	丁文其, 王晓形, 朱合华, 等. 连拱隧道设计荷载的确定方法 [J]. 中国公路学报, 2007, 20 (5): 78 – 82. (DING Wen-qi, WANG Xiao-xing, ZHU He-hua, et al. Defining method for designing load of multi-arch tunnel[J]. China Journal of Highway and Transport, 2007, 20 (5): 78 – 82. (in Chinese))
[7]	王梦恕. 隧道工程浅埋暗挖法施工要点 [J]. 隧道建设, 2006, 26 (5): 1 – 4. (WANG Meng-shu. Outline of tunnel const ruction by means of method of undercutting with shallowoverburden[J]. Tunnel Construction, 2006, 26 (5): 1 – 4. (in Chinese))
[8]	SOUBRA A H, REGENASS P. Three-dimensional passive earth pressures by kinematical approach[J]. Journal of Geotechanical and Geoenvironmental Engineering, 2001, 126 (11): 969 – 978.
[9]	来弘鹏, 林永贵, 谢永利, 等. 支护时机对软弱围岩公路隧道力学特征影响的试验研究 [J]. 岩土工程学报, 2009(3): 390 – 395. (LAI Hong-peng, LIN Yong-gui, XIE Yong-li, et al. Study the relationships between soft-wreak surrounding rocks highway tunnel stress characteristics and supporting opportunity[J]. Chinese Journal of Geotechnical Engineering, 2009(3): 390 – 395. (in Chinese))
[10]	黄强兵, 彭建兵, 门玉明, 等. 地裂缝对地铁明挖整体式衬砌隧道影响机制的模型试验研究 [J]. 岩石力学与工程学报, 2008, 27 (11): 2324 – 2331. (HUANG Qiang-bing, PENG Jian-bing, MEN Yu-ming, et al. Model test study on effect of ground fissure on open-cut metro tunnel with integral lining[J]. Chinese Journal of Rock Mechanics and Engineering, 2008, 27 (11): 2324 – 2331. (in Chinese))
[11]	夏才初, 李永盛. 地下工程测试理论与监测技术 [M]. 上海: 同济大学出版社, 1999. (XIA Cai-chu, LI Yong-sheng. Test theory and measurement technology of the underground engineering[M]. Shanghai: Tongji University Press, 1999. (in Chinese))
[12]	赵占厂, 谢永利, 杨晓华, 等. 黄土公路隧道衬砌受力特性测试研究 [J]. 中国公路学报, 2004, 17 (1): 66 – 69. (ZHAO Zhan-chang, XIE Yong-li, YANG Xiao-hua, et al. Observation research on the mechanical characteristic of highway tunnel lining in loess[J]. China Journal of Highway and Transport, 2004, 17 (1): 66 – 69. (in Chinese))
