反滤料级配设计的思考

孙君实; 相彪

反滤料级配设计的思考 English Version

孙君实,
相彪

中国水电昆明勘测设计研究院，云南昆明 650051

详细信息

作者简介:
孙君实 (1942 – ) ，男，湖北黄梅人，高级工程师，主要从事水工设计方法的研究。

中图分类号: TU521
计量
- 文章访问数: 1657
- HTML全文浏览量: 2
- PDF下载量: 1174
出版历程
- 收稿日期: 2010-06-03
- 发布日期: 2011-08-14

Thoughts on gradation design of filter materials

HydroChina Kunming Engineering Corporation, Kunming 650051, China

摘要

摘要: 反滤料的级配设计是土石坝设计的核心问题之一。反滤料设计除了要满足规范中滤土、排水、保护被保护土裂后自愈的要求外，还应能适应较大剪切变形，起到变形过渡的作用。将土料分为“骨架粗料”和“填充细料”两部分，并用此模糊概念，将《碾压式土石坝设计规范》的反滤料设计观念具体化：①探讨了含有大于 5 mm 颗粒的防渗混合土的宏观概念，指出其细粒组含量 η 0.075 与大于 5 mm 颗粒的含量 P 5 是一对“因土而异”的特征值，可沿用美国垦务局的反滤准则中对被保护基土的四个分类及各类的反滤关系，但得到的反滤料的 D 15 应视为反滤料“填充细料”的 D 15 ；②从刘杰对渗透变形的分类研究中，可引伸出反滤料的 “骨架粗料”和“填充细料” 的分界粒径 d f 和“填充细料”的临界含量 η f ，并将反滤料的设计依据归结为九项条件；③通过实例，详细地解说了反滤料的实用设计方法。
- 土石坝 /
- 反滤料 /
- 级配设计 /
- 骨架粗料 /
- 填充细料
Abstract: The gradation design of filter materials is one of the key problems in design of earth rockfill dams. The design of the filter materials, besides meeting the standard requirements of soil filtering, water drainage and protecting the protected soil by self-healing after cracking, should adapt to large shear deformation and make the effect of deformation transition. The soil materials are divided into two parts, coarse skeleton materials and fine filling materials. Based on this fuzzy concept, the design idea of the filter materials in the design code for rolled earth-rock fill dams (SDJ218-84) in China is specified as follows: (1) The macroscopic concept of mixed impervious soil containing particles which exceed 5 mm in diameter is discussed. The content η_0.075 for fine particles and the content P₅ for particles exceeding 5 mm in diameter are a pair of eigenvalues and different for different soils. The four classifications of protected soils and their filter relationship in each classification in the filter criterion of US Bureau of Reclamation can still be used, but the particle size D₁₅ should be that of the fine filling materials in filter soil instead; (2) From the classification of leakage deformation in Liujie’s study, the demarcation particle size d _f between the coarse skeleton materials and the fine filling materials, and the critical content η _f for the fine filling materials are proposed. Furthermore, the design basis of filter materials is summarized to be nine conditions; (3) through an example, the practical design method for the filter materials is introduced.
- earth rockfill dam /
- filter material /
- gradation design /
- coarse skeleton material /
- fine filling material

HTML全文

参考文献(9)

[1]	水利部科技教育司, 水利水电规划设计总院. 国外水利水电标准文献译文 [8]: “ 填筑坝 - 第二章填筑坝设计 ”[S]. 1994. (Science and Technology Education Department Of Water Resources Ministry, Planning and design institute of water conservancy and hydropower. The literature translation of foreign water conservancy and hydropower standards[8]: “Embankment dams-Chapter 2 embankment design”[S]. 1994. (in Chinese))
[2]	SHERARD J L, DUNNIGAN L P, TALBOT J R. Basic properties of sand and gravel filters[J]. Journal of the Geotechnical Engineering Division, ASCE, 1984, 110 (6): 684 – 700.
[3]	SHERARD J L, DUNNIGAN L P, TALBOT J R. Filters for silts and clays[J]. Journal of the Geotechnical Engineering Division, ASCE, 1984, 110 (6): 701 – 718.
[4]	刘杰. 土的渗透稳定与渗流控制 [M]. 北京: 中国水利水电出版社, 1992. (LIU Jie. Leakage stability and seepage control of soil[M]. Beijing: China Water Power Press, 1992. (in Chinese))
[5]	刘杰. 土石坝渗流控制理论基础, 工程经验教训 [M]. 北京: 中国水利水电出版社, 2005. (LIU Jie. Theoretical basis of seepage control of earth-rock dams, engineering experience and lessons[M]. Beijing: China Water Power Press, 2005. (in Chinese))
[6]	日本电力土木技术协会. 最新土石坝工程学 ( 修定版 )[M]. 陈慧远, 等译. 北京: 水利电力出版社, 1986. (Technical Association of Electric Power and Civil Engineering of Japan. The latest earth rockfill dam engineering (revised edition)[M]. CHEN Hui-yuan, et al trans. Beijing: Water Conservancy and Electric Power Press, 1986. (in Chinese))
[7]	屈智炯, 何昌荣, 刘双光, 等. 新型石渣坝: 粗粒土筑坝的理论与实践 [M]. 北京: 中国水利水电出版社, 2002. (QU Zhi-jiong, HE Chang-rong, LIU Shuang-guang, et al. A new-style rock ballast dam: the theory and application of dam construction for coarse grained soil[M]. Beijing: China Water Power Press, 2002. (in Chinese))
[8]	郭庆国. 粗粒土的工程特性及应用 [M]. 郑州: 黄河水利出版社, 1998. (GUO Qing-guo. The engineering properties and application of coarse grained soil[M]. Zhengzhou: Yellow River Conservancy Press, 1998. (in Chinese))
[9]	毛昶熙. 渗流计算分析与控制 [M]. 第二版. 北京: 中国水利水电出版社, 2003. (MAO Chang-xi. Seepage calculation analysis and seepage control[M]. 2nd ed. Beijing: China Water Power Press, 2003. (in Chinese))
