齐姝霞, 刘一苇, 唐旭海, 张俊楷, 严成增, 刘泉声. 基于纳米压痕的玄武岩微观弹性模量测定及参数尺度升级研究[J]. 岩土工程学报. DOI: 10.11779/CJGE20240541
引用本文: 齐姝霞, 刘一苇, 唐旭海, 张俊楷, 严成增, 刘泉声. 基于纳米压痕的玄武岩微观弹性模量测定及参数尺度升级研究[J]. 岩土工程学报. DOI: 10.11779/CJGE20240541
Prediction of Elastic Modulus and Uniaxial Compression Failure of Basalt Based on Nanoindentation Experiment and Upscaling methods[J]. Chinese Journal of Geotechnical Engineering. DOI: 10.11779/CJGE20240541
Citation: Prediction of Elastic Modulus and Uniaxial Compression Failure of Basalt Based on Nanoindentation Experiment and Upscaling methods[J]. Chinese Journal of Geotechnical Engineering. DOI: 10.11779/CJGE20240541

基于纳米压痕的玄武岩微观弹性模量测定及参数尺度升级研究

Prediction of Elastic Modulus and Uniaxial Compression Failure of Basalt Based on Nanoindentation Experiment and Upscaling methods

  • 摘要: 玄武岩力学特性与未来海洋资源开采、探月工程和火星基地建设息息相关,由于深海和深空环境下获取完整岩心难度较大,难以通过传统宏观岩石力学试验来准确测定其力学参数。为此,本研究基于微观岩石力学试验与精确矿物晶体模型(accurate grain-based modeling, AGBM),提出了一种适用于非标准尺寸和形状玄武岩样本力学参数测试方法。利用矿物自动定量分析系统(TESCAN Integrated Mineral Analyzer, TIMA)和纳米压痕测试,分别获取玄武岩的矿物成分、微观结构信息和成岩矿物的微观弹性模量。基于TIMA和纳米压痕得到的微观参数,构建玄武岩精确矿物晶体模型,通过数值模拟玄武岩单轴压缩过程得到玄武岩的宏观弹性模量,进而实现任意小尺寸玄武岩样本的弹性模量测定。研究表明,基于AGBM的数值模拟所得玄武岩弹性模量与宏观试验结果最为接近,显著优于传统的均质化方案,包括Voigt-Reuss-Hill方案、Mori-Tanaka方案及稀释方案。最后,讨论了晶间相力学性质、孔隙率及孔隙填充对AGBM模型尺度升级效果的影响。本研究为小尺寸非标准玄武岩样本的力学性质预测提供了技术支持。



    Abstract: The mechanical properties of basalt are crucial for future marine resource extraction, lunar exploration, and Mars base development. However, obtaining intact basalt cores is challenging due to the difficulties of sampling in deep-sea and deep-space environments, making it impractical to determine their mechanical properties using traditional macroscopic rock mechanics tests. In this study, a new method to assess the mechanical properties of non-standard basalt specimens based on micro-rock mechanics experiments and accurate grain-based modeling (AGBM) was proposed. The TESCAN Integrated Mineral Analyzer (TIMA) was used to analyze the mineral composition and microstructure of basalt. Nanoindentation tests determined the elastic moduli of rock-forming minerals. AGBM model of basalt was constructed based on digital images obtained by TIMA and mechanical parameters derived from nanoindentation. It is found that the elastic modulus of basalt obtained through AGBM-based numerical simulation of uniaxial compression closely aligns with those from macroscopic experiments. In contrast, homogenization methods, including the Voigt-Reuss-Hill scheme, the Mori-Tanaka scheme, and dilution scheme, show considerable discrepancies. Finally, the study examines the impacts of interphase mechanical properties, porosity, and pore filling on the upscaling results of the AGBM model. The proposed method provides an approach for predicting the mechanical properties of basalt samples in arbitrary shapes and small sizes.



/
