土体小应变剪切模量的现场和室内试验对比及工程应用

陈少杰; 顾晓强; 高广运

doi:10.11779/CJGE2019S2034

土体小应变剪切模量的现场和室内试验对比及工程应用 English Version

陈少杰^{1, 2},
顾晓强^1,2, ,,
高广运^{1, 2}

1. 同济大学地下建筑与工程系,上海 200092;
2. 同济大学岩土及地下工程教育部重点试验室,上海 200092

基金项目: 国家自然科学基金项目（51822809，51738010）

详细信息

作者简介:
陈少杰(1995— ),男,河南周口人,硕士研究生,从事土体小应变刚度特性及基坑开挖变形分析等研究。E-mail: ch_shaojie@tongji.edu.cn。

通讯作者:
顾晓强，E-mail：guxiaoqiang@tongji.edu.cn

计量
- 文章访问数: 390
- HTML全文浏览量: 9
- PDF下载量: 248
出版历程
- 收稿日期: 2019-04-29
- 发布日期: 2019-07-19

Comparison and application of small strain shear moduli from field and laboratory measurements

CHEN Shao-jie^{1, 2},
GU Xiao-qiang^1,2, ,,
GAO Guang-yun^{1, 2}

1. Department of Geotechnical Engineering, Tongji University, Shanghai 200092, China;
2. Key Laboratory of Geotechnical and Underground Engineering of the Ministry of Education, Tongji University, Shanghai 200092, China

摘要

摘要: 土体小应变剪切模量G₀在场地地震响应和基坑变形等计算分析中有着重要作用。统计了上海典型土层的室内共振柱试验和现场原位波速测试测得的小应变剪切模量,给出了两种试验方法下的G₀的经验公式,并对比分析了室内试验和现场原位测试结果的差异。研究结果表明土体的G₀值主要由土体类别、孔隙比和平均有效应力决定,且现场试验的结果远高于室内试验的结果。进一步采用HS-Small本构模型对上海新金桥广场基坑工程的开挖变形进行数值模拟,分析了小应变剪切模量对于基坑工程变形的影响。分析结果表明,采用现场原位测试测得的小应变剪切模量进行基坑变形计算的结果与现场变形监测数据更为接近。
- 小应变剪切模量 /
- 共振柱实验 /
- 现场波速测试 /
- HSS模型 /
- 基坑开挖
Abstract: The small-strain shear modulus plays an important role in the calculations of ground seismic response and deformation in deep excavations. The values of the small strain shear modulus G₀ of Shanghai soils by field and laboratory tests are investigated and compared, and empirical formulas are proposed to predict the values of G₀. The results indicate that G₀ mainly depends on the soil type, void ratio and mean confining pressure. The values of G₀ from field tests are considerately higher than those from laboratory tests. The correlation between the small strain shear moduli from field and laboratory is also proposed. The numerical analysis is also carried out to calculate the deformation in a deep excavation in Shanghai. The small strain hardening model (HSS) is used, together with the measured small strain shear modulus. The values of G₀ are essential for the deformation of the excavation, and the predicted deformation using the G₀ value from field measurement is more accurate than that using the laboratory data based on the measured deformation in the excavation.
- small strain shear modulus /
- resonant column test /
- field shear wave measurement /
- HSS model /
- excavation

HTML全文

参考文献(10)

[1]	ATKINSON J H, SALLFORS G.Experimental determination of stress-strain-time characteristics in laboratory and in-situ tests[C]// Proceedings of 10th European Conference on Soil Mechanics and Foundation Engineering, Balkema, Rotterdam. Netherlands, 1991: 915-956.
[2]	BENZ T.Small-strain stiffness of soils and its numerical consequences[D]. Stuttgart: Institute of Geotechnical Engineering, University of Stuttgart, 2007.
[3]	徐中华, 王卫东. 敏感环境下基坑数值分析中土体本构模型的选择[J]. 岩土力学, 2010, 31(1): 258-264. (XU Zhong-hua, WANG Wei-dong.Selection of soil constitutive models for numerical analysis of deep excavations in close proximity to sensitive properties[J]. Rock and Soil Mechanics, 2010, 31(1): 258-264. (in Chinese))
[4]	王浩然. 上海软土地区深基坑变形与环境影响预测方法研究[D]. 上海: 同济大学, 2012. (WANG Hao-ran.Prediction of deformation and response of adjacent environment of deep excavation in Shanghai soft deposit[D]. Shanghai: Tongji University, 2012. (in Chinese))
[5]	HARDIN B O, DRNEVICH V P.Shear modulus and damping in soils[J]. Journal of the Soil Mechanics and Foundations Division, 1972, 98(7): 667-692.
[6]	HARDIN B O.Vibration modulus of normally consolidated clay[J]. J of the Soil Mechanics & Foundations Division, 1968, 94(2): 353-370.
[7]	KOKUSHO T.In-situ dynamic soil properties and their evaluations[C]// Proc 8th Asian Regional Conf on SMFE. Kyoto, 1987, 2: 215-240.
[8]	顾晓强, 陆路通, 李雄威, 等. 土体小应变刚度特性的试验研究[J]. 同济大学学报 (自然科学版), 2018, 46(3): 312-317. (GU Xiao-qiang, LU Lu-tong, LI Xiong-wei, et al.Experimental study on the small strain stiffness properties of soil[J]. Journal of Tongji University (Natural Science), 2018, 46(3): 312-317. (in Chinese))
[9]	GU X, LU L, YANG J, WU X.Laboratory measurements of the dynamic properties of Shanghai clay[C]// Environmental Vibrations and Transportation Geodynamics, ISEV 2016. Springer, Singapore, 2016: 585-592.
[10]	梁发云, 贾亚杰, 丁钰津, 等. 上海地区软土HSS模型参数的试验研究[J]. 岩土工程学报, 2017(2): 269-278. (LIANG Fa-yun, JIA Ya-jie, DING Yu-jin, et al.Experimental study on parameters of HSS model for soft soil in Shanghai[J]. Chinese Journal of Geotechnical Engineering, 2017(2): 269-278. (in Chinese))
