Visibility and mechanical properties of transparent clay
-
摘要: 透明土是用于岩土工程模型试验可视化研究的一种重要材料,明确其可视度控制因素与物理力学特性具有重要的意义。采用#15白油与正十二烷作为孔隙液体,无定形硅粉作为固相材料,通过对比不同的孔隙液体配比和掺入硅粉的质量比,发现可视度达到最佳时的配比为15号白油∶正十二烷=10∶3（体积比）,孔隙液体∶无定形硅粉=1.5∶1（质量比）。针对最佳可视度的透明黏土进行了变形与强度特性试验,试验结果表明透明黏土属于高压缩性土,并且与天津滨海软黏土的压缩变形特征相近,二者压缩系数和压缩模量相差在10%以内;固结快剪试验表明当透明黏土的当应力水平较低（不大于200 kPa）时,透明黏土的抗剪强度指标可以取c≈11 kPa,φ=14°~18°,当应力水平较高（大于200 kPa）时,可以取c=20.28~22.62 kPa,φ≈17°。Abstract: The transparent soil is a kind of important material for the visualization researches model tests in geotechnical engineering. It is of great significance to clarify its visibility control factors and physical and mechanical properties. The white oil No. 15 and n-dodecane are used as the pore liquid, and the amorphous silicon powder is used as the solid phase material. By comparing the ratio of different pore liquids and the mass ratio of silicon powder, it is found that the visibility is the best when the ratio of the white oil No. 15 to the n-dodecane is 10:3 (volume ratio) and that of the pore liquid to the amorphous silicon powder is 1.5:1 (mass ratio). The deformation and strength characteristics of the transparent clay with the best visibility are tested. The test results show that the transparent clay is a highly compressive soil, and its compression deformation characteristics are similar to those of Tianjin coastal soft clay, and their differences in compression coefficient and compression modulus are within 10%. The consolidated quick shear tests show that when the stress level of transparent clay is relatively lower (≤200 kPa), the strength indices can be taken as c≈11 kPa, φ=14°~18°, and when the stress level is relatively higher (>200 kPa), the strength indices can be taken as c=20.28 kPa~22.62 kPa, φ≈17°.
-
Keywords:
- transparent clay /
- visibility /
- ratio of pore liquid /
- compression characteristic /
- strength characteristic /
- OCR
-
[1] ALLERSMA H G B. Photo-elastic stress analysis and strain in simple shear[C]// IUTAM Conference on Deformation and Failure of Granular Materials. 1982. [2] KONAGAI K, TAMURA C, RANGELOW P.Laser-aided tomography: a tool for visualization of changes in the fabric of granular assemblage[J]. Struct Eng Earthquake Eng, 1992, 9(3): 193-201. [3] MANNHEIMER R.Slurries you can see through[J]. Technology Today, 1990(3): 2. [4] PINCUS H J, ISKANDER M G, LAI J, et al.Development of a transparent material to model the geotechnical properties of soils[J]. Geotechnical Testing Journal, 1994, 17(4): 425-433. [5] ISKANDER M G, LIU J, SADEK S.Transparent amorphous silica to model clay[J]. Journal of Geotechnical & Geoenvironmental Engineering, 2002, 128(3): 262-273. [6] 孔纲强, 刘璐, 刘汉龙, 等. 玻璃砂透明土变形特性三轴试验研究[J]. 岩土工程学报, 2013, 35(6): 1140-1146.
(KONG Gang-qiang, LIU Lu, LIU Han-long, et al.Triaxial tests on deformation characteristics of transparent glass sand[J]. Chinese Journal of Geotechnical Engineering, 2013, 35(6): 1140-1146. (in Chinese))[7] 宫全美, 周俊宏, 周顺华, 等. 透明土强度特性及模拟黏性土的可行性试验[J]. 同济大学学报(自然科学版), 2016, 44(6): 853-860.
(GONG Quan-mei, ZHOU Jun-hong, ZHOU Shun-hua, et al.Strength property and feasibility test of transparent soil to model clayey soil[J]. Journal of Tongji University (Natural Science) 2016, 44(6): 853-860. (in Chinese))[8] ZHANG Y P, LI L, WANG S Z.Experimental study on pore fluid for forming transparent soil[J]. Journal of Zhejiang University, 2014, 48(10): 1828-834. [9] MANNHEIMER R J, OSWALD, et al. Development of transparent porous media with permeabilities and porosities comparable to soils, aquifers, and petroleum reservoirs[J]. Groundwater, 2010, 31(5): 781-788. [10] 雷华阳, 任倩, 卢海滨, 等. 相对厚度变化下双层软黏土地基固结特性研究[J]. 地下空间与工程学报, 2018, 14(3): 705-711.
(LEI Hua-yang, REN Qian, LU Hai-bin, et al.Research on consolidation property of double layer soft clay foundation under different relative thickness conditions[J]. Chinese Journal of Underground Space and Engineering, 2018, 14(3): 705-711. (in Chinese))[11] 陈婷婷, 高彦斌, 徐超, 等. 结构性对上海软黏土的压缩特性影响[C]// 全国工程地质大会. 上海, 2008.
(CHEN Ting-ting, GAO Yan-bin, XU Chao, et al.Influence of Soil Structure on the Compressibility of Shanghai clay[C]// Chinese National Engineering Geology Conference. Shanghai, 2008. (in Chinese))[12] 殷杰. 土结构性对天然软黏土压缩特性的影响[J]. 岩土力学, 2012, 33(1): 48-52.
(YIN Jie.Effect of soil structure on compression behavior of natural soft clays[J]. Rock and Soil Mechanics, 2012, 33(1): 48-52. (in Chinese))[13] 洪振舜, 刘松玉, 于小军. 关于结构土屈服破坏的探讨[J]. 岩土力学, 2004, 25(5): 684-687.
(HONG Zhen-shun, LIU Song-yu, YU Xiao-jun, et al.On destructuration of structured soils[J]. Rock and Soil Mechanics, 2004, 25(5): 684-687. (in Chinese)) -
