尾矿库中新型复合排渗管排渗特征试验研究

刘胜; 王媛; 冯迪

doi:10.11779/CJGE201912023

尾矿库中新型复合排渗管排渗特征试验研究 English Version

刘胜^1,2,
王媛^1,2, ,,
冯迪^1,2

1. 河海大学岩土力学与堤坝工程教育部重点实验室,江苏南京 210024;
2. 河海大学江苏省岩土工程技术工程研究中心,江苏南京210024

基金项目: 国家重点研发计划项目（2017YFC0804600）

详细信息

作者简介:
刘胜(1994— ),男,博士研究生,主要从事排渗设施淤堵机理及其应对措施等方向的研究。E-mail: liusheng3131@163.com。

通讯作者:
王媛，E-mail：wangyuanhhu@163.com

中图分类号: TU42
计量
- 文章访问数: 263
- HTML全文浏览量: 14
- PDF下载量: 151
出版历程
- 收稿日期: 2018-11-04
- 发布日期: 2019-12-24

Experimental study on drainage characteristics of new composite drainage pipes in tailings pond

LIU Sheng^1,2,
WANG Yuan^1,2, ,,
FENG Di^1,2

1. Key Laboratory of the Ministry of Education for Geomechanics and Embankment Engineering, Hohai University, Nanjing 210024, China;
2. Jiangsu Research Center for Geotechinical Engineering Technology, Hohai University, Nanjing 210024, China

摘要

摘要: 尾矿库中排渗设施的淤堵是常见的现象,也是影响其安全的重要因素。为提高排渗管的排渗能力和抗淤堵性能,开发了一种新型复合排渗管,新型复合排渗管在土工布和排渗花管之间增加了一层格构网。通过室内模型试验,研究格构网的结构和花管开孔率对新型复合排渗管排渗特征的影响,分析了新型复合排渗管的抗淤堵性能,揭示了新型复合排渗管的排渗机理。试验结果表明：外包格构网增加了排渗管的等效开孔面积,优化了排渗管的排渗路径,提高了排渗管的排渗能力。随着花管开孔率的增加,外包格构网对排渗管排渗能力的影响减小。外包格构网提高了排渗管的抗淤堵能力,随着土工布的淤堵,传统外包土工布排渗管和新型复合排渗管的排渗量均有所降低,传统外包土工布排渗管排渗量降低的程度更大。当单向连通格构网的连通方向与排渗管的纵向方向有夹角时,排渗管的排渗能力不增反减。使用单向连通格构网时,须保证格构网的连通方向与排渗管的纵向方向一致。
- 尾矿库 /
- 复合排渗管 /
- 排渗特征 /
- 试验研究
Abstract: The clogging of the drainage facilities in a tailings pond is a common phenomenon, and is also an important factor affecting its safety. In order to improve the drainage capacity and anti-clogging performance of the drainage pipes, new composite drainage pipes are proposed. A layer of lattice net is added between the geotextile and the perforated pipes in the new composite drainage pipes. The indoor model tests are carried out to study the influences of different lattice net structures and opening ratios of the perforated pipes on the drainage characteristics of the new composite drainage pipes. The anti-clogging performance of the new composite drainage pipes is analyzed, and their drainage mechanism is revealed. The results show that the drainage capacity of the composite drainage pipes increases because of larger equivalent opening area and optimized drainage path. With the increase of the opening rate of the perforated pipes, the influences of the lattice net on the drainage capacity of the drainage pipes become smaller. The outsourced lattice network improves the anti-clogging ability of the drainage pipes. With the clogging of geotextiles, the drainage capacities of the ordinary drainage pipes wrapped only with geotextiles and the new composite drainage pipes both decrease, and the reduction of the drainage capacity of the ordinary drainage pipes is more serious. When the connection direction of unidirectional connected lattice net is at an angle with the longitudinal direction of drainage pipes, the drainage capacity of the drainage pipes does not increase but decreases. When using the unidirectional connected lattice net, it is necessary to ensure that the connection direction of the lattice net is consistent with the longitudinal direction of the drainage pipes.
- tailings pond /
- composite drainage pipe /
- drainage characteristic /
- experimental study

HTML全文

参考文献(17)

[1]	于广明, 宋传旺, 潘永战, 等. 尾矿坝安全研究的国外新进展及我国的现状和发展态势[J]. 岩石力学与工程学报, 2014, 33(增刊1): 3238-3248. (YU Guang-ming, SONG Chuan-wang, FAN Yong-zhan, et al.Review of new progress in tailing dam safety in foreign research and current state with development trent in China[J]. Chinese Journal of Rock Mechanics and Engineering, 2014, 33(S1): 3238-3248. (in Chinese))
[2]	门永生, 柴建设. 我国尾矿库安全现状及事故防治措施[J]. 中国安全生产科学技术, 2009, 5(1): 48-52. (MEN Yong-sheng, CHAI Jian-she.The current safety situation of tailing reservoir in China and preventive measures[J]. Journal of Safety Science and Technology, 2009, 5(1): 48-52. (in Chinese))
[3]	RICO M, BENITO G, SALGUEIRO A R, et al.Reported tailings dam failures: a review of the European incidents in the worldwide context[J]. Journal of Hazardous Materials, 2008, 152(2): 846-852.
[4]	敬小非. 尾矿坝溃决泥沙流动特性及灾害防护研究[D]. 重庆: 重庆大学, 2011. (JING Xiao-fei.Study on flow characteristics of the sediment produced from tailings dam breach and disaster prevention[D]. Chongqing: Chongqing University, 2011. (in Chinese))
[5]	王东, 沈振中, 陶小虎. 尾矿坝渗流场三维有限元分析与安全评价[J]. 河海大学学报(自然科学版), 2012, 40(3): 307-312. (WANG Dong, SHEN Zhen-zhong, TAO Xiao-hu.Three-dimensional finite element analysis and safety assessment for seepage field of a tailings dam[J]. Journal of Hohai University (Natural Sciences), 2012, 40(3): 307-312. (in Chinese))
[6]	SHAMSAI A, PAK A, BATENI S M, et al.Geotechnical characteristics of copper mine tailings: a case study[J]. Geotechnical & Geological Engineering, 2007, 25(5): 591-602.
[7]	尹光志, 魏作安, 万玲. 龙都尾矿库地下渗流场的数值模拟分析[J]. 岩土力学, 2003, 24(增刊2): 25-28. (YIN Guang-zhi, WEI Zuo-an, WAN Ling.Numerical simulation analysis about seepage field of Longdu tail bay[J]. Rock and Soil Mechanics, 2003, 24(S2): 25-28. (in Chinese))
[8]	金松丽, 徐宏达, 张伟, 等. 尾矿坝排渗技术的研究现状[J]. 现代矿业, 2012(7): 35-38. (JIN Song-li, XU Hong-da, ZHANG Wei, et al.Research situation of drainage technology of tailings dam[J]. Morden Mining, 2012(7): 35-38(in Chinese))
[9]	彭易华, 张明云. 垂直、水平联合自流排渗法加固坝体的研究[J]. 土工基础, 2000, 14(2): 15-19. (PENG Yi-hua, ZHANG Ming-yun.Study on dam reinforcement by vertical-horizontal jointed artesian drainage[J]. Soil Engineering and Foundation, 2000, 14(2): 15-19. (in Chinese))
[10]	汪良峰, 朱君星, 项宏海, 等. 尾矿库排渗辐射井的设计探讨[J]. 金属矿山, 2010(2): 55-56. (WANG Liang-feng, ZHU Jun-xing, XIANG Hong-hai, et al.Discussion on design of radiation wells for tailings seepage drainage[J]. Metal Mine, 2010(2): 55-56. (in Chinese))
[11]	STUYT L C P M, DIERICKX W. Design and performance of materials for subsurface drainage systems in agriculture[J]. Agricultural Water Management, 2006, 86(1): 50-59.
[12]	杨春和, 阎金安. 土工织物在尾矿坝排渗处理中的应用[J]. 水力发电学报, 1991(4): 64-68. (YANG Chun-he, YAN Jin-an.Application of geotextile in the treatment of tailings dam drainage[J]. Journal of Hydroelectric Engineering, 1991(4): 64-68. (in Chinese))
[13]	金松丽, 徐宏达, 张伟, 等. 细粒尾矿坝槽孔管排渗机理及其计算方法[J]. 金属矿山, 2013(3): 42-44. (JIN Song-li, XU Hong-da, ZHANG Wei, et al.Calculation method and drainage mechanism of slotted pipe in fine-grained tailings dam[J]. Metal Mine, 2013(3): 42-44. (in Chinese))
[14]	KOERNER R M, KOERNER G R.Lessons learned from geotextile filter failures under challenging field conditions[J]. Geotextiles & Geomembranes, 2015, 43(3): 272-281.
[15]	付文堂, 李湘滨, 李恒军, 等. 浅谈尾矿坝排渗管的埋设[J]. 金属矿山, 2010(增刊): 44-46. (FU Wen-tang, LI Xiang-bin, LI Heng-jun, et, al. Discussion on embedment of drainage pipes for tailings dam[J]. Metal Mine, 2010(S): 44-46. (in Chinese))
[16]	杨燕, 唐泽勋, 魏作安. 上向弯曲双向槽孔排渗管技术在新厂沟尾矿库的应用[J]. 中国地质灾害与防治学报, 2013, 24(1): 65-69. (YANG Yan, TANG Ze-xun, WEI Zuo-an.Application of up-curved two-way hole-slot drainage tube technology into the Xinchanggou tailings dam[J]. Chinese Journal of Geological Hazard and Control, 2013, 24(1): 65-69. (in Chinese))
[17]	裴晓东, 钱有军, 高莉. 马坑磁铁矿石高压辊磨—湿式中磁预选—阶段磨选工艺试验[J]. 金属矿石, 2016(8): 81-84. (PEI Xiao-dong, QIAN You-jun, GAO Li.Experiment of HPGR crushing-wet mid intensity magnetic preconcentration- stage grinding and separation on a magnetite ore from makeng[J]. Metal Mine, 2016(8): 81-84. (in Chinese))
