单桩承载力对刚性桩复合地基路堤稳定性的影响

刘吉福, 郑刚

刘吉福, 郑刚. 单桩承载力对刚性桩复合地基路堤稳定性的影响[J]. 岩土工程学报, 2019, 41(11): 1992-1999. DOI: 10.11779/CJGE201911003
引用本文: 刘吉福, 郑刚. 单桩承载力对刚性桩复合地基路堤稳定性的影响[J]. 岩土工程学报, 2019, 41(11): 1992-1999. DOI: 10.11779/CJGE201911003
shu
LIU Ji-fu, ZHENG Gang. Influences of bearing capacity of piles on stability of embankment with rigid pile composite foundation[J]. Chinese Journal of Geotechnical Engineering, 2019, 41(11): 1992-1999. DOI: 10.11779/CJGE201911003
Citation: LIU Ji-fu, ZHENG Gang. Influences of bearing capacity of piles on stability of embankment with rigid pile composite foundation[J]. Chinese Journal of Geotechnical Engineering, 2019, 41(11): 1992-1999. DOI: 10.11779/CJGE201911003
shu

单桩承载力对刚性桩复合地基路堤稳定性的影响  English Version

  • 1. 广东省交通规划设计研究院股份有限公司,广东 广州 510507;
    2. 天津大学建筑工程学院,天津 300072

基金项目: 国家自然科学基金项目（51078263）
详细信息
    作者简介:

    刘吉福(1971— ),男,博士,教授级高级工程师,主要从事公路设计与科研等工作。E-mail: 617067152@qq.com。

  • 中图分类号: TU470

Influences of bearing capacity of piles on stability of embankment with rigid pile composite foundation

  • 1. Guangdong Province Communication Planning ＆ Design Institute Co., Ltd., Guangzhou 510507, China;
    2. School of Civil Engineering, Tianjin University, Tianjin 300072, China

摘要

    摘要
  • 摘要: 现行规范中刚性桩复合地基路堤稳定分析方法不能反映单桩承载力、桩帽等对路堤稳定性的影响,计算的路堤稳定安全系数严重偏大,导致部分刚性桩复合地基路堤滑塌。为克服刚性桩复合地基路堤现有稳定分析方法的缺陷,在研究刚性桩复合地基路堤滑塌原因的基础上,分析了路堤滑塌时桩土相互作用,及刚性桩提高路堤稳定性的机理。然后,在分析刚性桩复合地基路堤现有稳定分析方法的缺陷的基础上,将修正密度法完善为修正重度法。最后,为研究单桩承载力对刚性桩复合地基路堤稳定性的影响,利用修正重度法分析了刚性桩长度、间距、扩底、桩帽等对路堤稳定性的影响,对比了不同稳定分析方法计算结果,并对刚性桩复合地基路堤设计提出了建议。研究表明：单桩承载力对密桩复合地基路堤稳定性影响很小,对疏桩复合地基路堤稳定性影响很大;增大单桩承载力比减小桩间距更合理;刚性桩在持力层中扩底比加大桩长更有效;利用桩帽、土拱等措施将大部分路堤荷载转移到桩顶方可发挥单桩承载力对路堤稳定性的作用;软土强度随深度增大不明显时应慎用悬浮桩复合地基。刚性桩复合地基路堤宜采用“强桩大帽”的疏桩复合地基方案。
    Abstract: The influences of bearing capacity and cap of rigid piles on the stability of embankment with rigid pile composite foundation cannot be taken into account in the methods recommended by the existing Chinese codes. Some embankments with rigid pile composite pile foundation slid owing to that the factor of safety gotten by those methods is much larger than the real value. To avoid the defects of the existing methods, the interactions between the piles and the soil among piles during sliding are analyzed, and the mechanism of improving the embankment stability by rigid piles is analyzed by analyzing the causes of slides. Then the revised density method is improved to be the revised weight method by analyzing the defects of the existing stability methods. Finally, the influences of the length, distance, enlarged base and cap of rigid piles on the embankment stability are studied by use of the revised weight method, and the influences of their bearing capacity on embankment stability are evaluated. The analysis results of different methods are compared. Some design proposals for the embankment with rigid pile composite foundation are put forward. It is shown that the influences of bearing capacity of piles on the stability of embankment with dense pile composite foundation are little but great on the embankment with sparse pile composite foundation. Increasing the bearing capacity of piles is more reasonable than decreasing the distance of piles. The belled piles are more efficient than those increasing their length. The rigid piles with large bearing capacity can play an important role to increase the stability of embankment only if most loads of embankment are transferred to the piles by pile caps and soil arch. The hanging piles should not be used if the strength of soft clay increases little along depth. The rigid pile composite foundation under embankment should be designed as the sparse pile composite foundation with large bearing capacity and pile cap.
    • HTML全文
    • 参考文献(22)
  • [1] BS8006—1:2010 Code of practice for strengthened/reinforced soils and other fills[S]. BSI Standards Publication, 2010.
    [2] TB 10106—2010 铁路工程地基处理技术规程[S]. 2010.
    (TB 10106—2010 Technical code for ground treatment of railway engineering[S]. 2010. (in Chinese))
    [3] JTG/T D31—02—2013 公路软土地基路堤设计与施工技术细则[S]. 北京: 人民交通出版社, 2015.
    (JTG/T D31—02—2013 Technical guidelines for design and construction of highway embankment on soft ground[S]. Beijing: China Communications Press, 2015. (in Chinese))
    [4] 朱旭华, 舒国明. 广珠北新围高架桥桥头路基滑移原因分析[J]. 中外公路, 2006, 26(4): 27-29.
    (ZHU Xu-hua, SHU Guo-ming.Causes analysis of embankment slide near Xinwei viaduct of Guangzhou-Zhuhai north expressway[J]. Journal of China & Foreign Highway, 2006, 26(4): 27-29. (in Chinese))
    [5] 黎爱清. CFG桩加固某软土路基的病害分析[J].铁道标准设计, 2012(6): 36-39.
    (LI Ai-qing.Failure analysis on CFG pile used for reinforcement of soft soil embankment[J]. Railway Standard Design, 2012(6): 36-39. (in Chinese))
    [6] 刘吉福, 郑刚, 安关峰. 折减荷载法分析刚性桩复合地基路基绕流滑动稳定性[J]. 广西大学学报, 2013, 38(1): 176-181.
    (LIU Ji-fu, ZHENG Gang, AN Guan-feng.Load reduction method for stability analysis of flow-slide of embankment on rigid-piles composite foundation[J]. Journal of Guangxi University, 2013, 38(1): 176-181. (in Chinese))
    [7] 刘吉福, 郑刚, 安关峰. 刚性桩复合地基路基绕流滑动稳定分析[J]. 工程勘察, 2013, 35(6): 17-22.
    (LIU Ji-fu, ZHENG Gang, AN Guan-feng.Stability analysis of flow-slide of embankment on rigid-piles composite ground[J]. Geotechnical Investigation & Surveying, 2013, 35(6): 17-22. (in Chinese))
    [8] 刘吉福, 郭舒洋, 肖昌建. 修正密度法分析混凝土桩复合地基路基绕流滑动稳定性[J]. 广东公路交通, 2016(5): 12-20.
    (LIU Ji-fu, GUO Shu-yang, XIAO Chang-jian.Revised density method for stability analysis of flow slide of embankment with concrete-pile composite foundation[J]. Guangdong Highway Communications, 2016(5): 12-20. (in Chinese))
    [9] 郑刚, 杨新煜, 周海祚. 基于渐进破坏的路堤下刚性桩复合地基的稳定性分析及控制[J]. 岩土工程学报, 2017, 39(4): 581-591.
    (ZHENG Gang, YANG Xin-yu, ZHOU Hai-zuo.Stability and control strategy of ground improved with rigid piles to support embankments based on progressive failure[J]. Chinese Journal of Geotechnical Engineering, 2017, 39(4): 581-591. (in Chinese))
    [10] 郑刚, 刘力, 韩杰. 刚性桩加固软弱地基上路堤的稳定性问题(Ⅱ): 群桩条件下的分析[J]. 岩土工程学报, 2010, 32(12): 1811-1820.
    (ZHENG Gang, LIU Li, HAN Jie.Stability of embankment on soft subgrade reinforced by rigid piles(Ⅱ): group piles analysis[J]. Chinese Journal of Geotechnical Engineering, 2010, 32(12): 1811-1820. (in Chinese))
    [11] 李帅. 刚性桩复合地基支撑路堤的失稳破坏机理及其稳定分析方法研究[D]. 天津: 天津大学, 2012.
    (LI Shuai.Research on failure mechanisms and stability analysis method of embankment supported on composite ground reinforced with rigid piles[D]. Tianjin: Tianjin University, 2012. (in Chinese))
    [12] 刘力. 刚性桩加固路堤稳定分析方法研究[D]. 天津: 天津大学, 2010.
    (LIU Li.Research on the stability analysis of rigid pile supported embankment[D]. Tianjin: Tianjin University, 2010. (in Chinese))
    [13] 熊传祥, 王艺霖, 陈福全. 路堤荷载下刚性桩复合地基稳定性计算[J]. 中南大学学报, 2017, 48(10): 2745-2752.
    (XIONG Chuan-xiang, WANG Yi-lin, CHEN Fu-quan.Stability calculation of rigid pile composite foundation under embankment load[J]. Journal of Central South University, 2017, 48(10): 2745-2752. (in Chinese))
    [14] 王哲明. 桩承式软基路堤侧滑变形机理及稳定分析[D]. 福州: 福州大学, 2015.
    (WANG Zhe-ming.Side slide deformation mechanism and stability analysis of pile supported embankment on soft foundation[D]. Fuzhou: Fuzhou University, 2015. (in Chinese))
    [15] 刘吉福, 郑刚, 龚晓南, 等. 柔性荷载刚性桩复合地基修正密度法稳定分析改进[J]. 岩土工程学报, 2017, 39(增刊2): 33-36.
    (LIU Ji-fu, ZHENG Gang, GONG Xiao-nan, et al.Improvement of revised density method for stability analysis of rigid-pile composite foundation with flexible load[J]. Chinese Journal of Geotechnical Engineering, 2017, 39(S2): 33-36. (in Chinese))
    [16] 俞建霖, 李俊圆, 王传伟. 考虑桩体破坏模式差异的路堤下刚性桩复合地基稳定分析方法研究[J]. 岩土工程学报, 2017, 39(增刊2): 37-40.
    (YU Jian-lin, LI Jun-yuan, WANG Chuan-wei.Stability of composite foundation improved by rigid piles under embankment considering different failure modes of piles[J]. Chinese Journal of Geotechnical Engineering, 2017, 39(S2): 37-40. (in Chinese))
    [17] GDJTG/T E01—2011 广东省公路软土地基设计与施工技术规定[S]. 北京: 人民交通出版社, 2011.
    (GDJTG/T E01—2011 Design and construction specification of soft clay ground of Guangdong highway[S]. Beijing: China Communications Press, 2011. (in Chinese))
    [18] JGJ79—2012 建筑地基处理技术规范[S]. 北京: 中国建筑工业出版社, 2013.
    (JGJ79—2012 Technical code for ground treatment of buildings[S]. Beijing: China Architecture & Building Press, 2013. (in Chinese))
    [19] 苗德山, 刘吉福. 基于离心模型试验的路堤下CFG桩破坏模式研究[J]. 广东公路交通, 2016(4): 10-13.
    (MIAO De-shan, LIU Ji-fu.Study of failure mode of CFG pile in composite foundation under embankment by centrifugal model test[J]. Guangdong Highway Communications, 2016(4): 10-13. (in Chinese))
    [20] 陈云敏, 贾宁, 陈仁朋. 桩承式路堤土拱效应分析[J]. 中国公路学报, 2004, 17(4): 1-6.
    (CHEN Yun-min, JIA Ning, CHEN Ren-peng.Soil arch analysis of pile supported embankments[J]. China Journal of Highway and Transport, 2004, 17(4): 1-6. (in Chinese))
    [21] ROGBECK Y, FRANZÉN G, SCANDIACONSULT C A, et al. Nordic guideline for reinforced soils and fills[R]. Baraboo: Nordic Geotechnical Group, 2005.
    [22] 刘吉福, 郑刚, 龚晓南. 附加应力法计算刚性桩复合地基路基沉降[J]. 岩土工程学报, 2018, 40(11): 1995-2002.
    (LIU Ji-fu, ZHENG Gang, GONG Xiao-nan.Superimposed stress method to calculate settlement of embankment with rigid-pile composite foundation[J]. Chinese Journal of Geotechnical Engineering, 2018, 40(11): 1995-2002. (in Chinese))
