考虑滑体中锚拉力扩散效应的锚固边坡稳定性分析方法

雷军; 肖世国

doi:10.11779/CJGE201909017

考虑滑体中锚拉力扩散效应的锚固边坡稳定性分析方法 English Version

雷军¹,
肖世国^1,2, ,

1. 西南交通大学地质工程系,四川成都 610031;
2. 西南交通大学高速铁路线路工程教育部重点实验室,四川成都 610031

基金项目: 国家自然科学基金项目（51278430）

详细信息

作者简介:
雷军(1994― ),男,硕士研究生,主要从事边坡稳定性与支挡结构方面的研究。E-mail: 704471172@qq.com。

通讯作者:
肖世国，E-mail：xiaoshiguo@swjtu.cn

计量
- 文章访问数: 0150
- HTML全文浏览量: 0
- PDF下载量: 0161
出版历程
- 收稿日期: 2018-11-19
- 发布日期: 2019-09-24

Stability analysis method for anchored slopes considering stress dispersion effect in sliding mass due to anchor tensile forces

LEI Jun¹,
XIAO Shi-guo^1,2, ,

1. Department of Geological Engineering, Southwest Jiaotong University, Chengdu 610031, China;
2. Key Laboratory of High-Speed Railway Engineering, Ministry of Education, Southwest Jiaotong University, Chengdu 610031, China

摘要

摘要: 为充分考虑锚拉力在滑体中的应力扩散效应以更合理地分析锚固边坡稳定性,将作用在坡面框架上的锚拉力转化为沿坡面法向与切向的局部条形荷载,基于弹性力学Boussinesq解和Cerruti解,得到在滑面处各点的附加法向与切向作用力,将其引入边坡稳定性分析的极限平衡条分法中,给出了基于Morgenstern-Price法的相关计算公式。实例分析表明,锚拉力在滑面处产生的附加应力并非都起抗滑作用,还存在局部促滑作用,与传统的将锚拉力视为集中力的锚固边坡稳定性计算方法相比,该方法计算的稳定系数偏小,且与数值模拟分析结果更为接近。
- 边坡稳定性 /
- 格构锚固结构 /
- 锚拉力 /
- 应力扩散效应 /
- 稳定系数
Abstract: In order to reasonably analyze the stability of anchored slopes with consideration of stress dispersion effect in the sliding mass due to anchor tensile forces, the anchor forces on the frameworks on the slope face are transformed into the locally normal and tangential strip loading, and the corresponding dispersed normal and shear stress on the slip surface is obtained using the Boussinesq's and Cerruti's solution of elastic mechanics. On this basis, the additional stress results are introduced into the limit equilibrium slice method for slope stability analysis, and the related formulas based on the Morgenstern-Price method is derived. The analysis results of a practical slope reinforced with prestressed anchor cable framework show that the additional stress on the slip surface does not fully provide resistance for the sliding mass, but a few of them are driving the sliding mass. Compared with that of the traditional analysis method for anchored slope stability in which the anchor tensile forces on the sliding mass are assumed simply as a series of single forces on the slip surface, the factor of safety obtained using the proposed method is smaller, and it is more consistent with that computed by the numerical simulation method.
- slope stability /
- anchors with framework /
- anchor tensile force /
- stress dispersion effect /
- factor of safety

HTML全文

参考文献(17)

[1]	肖世国, 周德培. 岩石高边坡一种预应力锚索框架型地梁的内力计算[J]. 岩土工程学报, 2002, 24(4): 479-482. (XIAO Shi-guo, ZHOU De-pei.A calculation method for internal force of prestressed anchor-rope and frame beam-on-foundation on high rock slope[J]. Chinese Journal of Geotechnical Engineering, 2002, 24(4): 479-482. (in Chinese))
[2]	JTGD30—2004 公路路基设计规范[S]. 2004. (JTGD30—2004 Specifications for design of highway subgrade[S]. 2004. (in Chinese))
[3]	王邓峮, 朱彦鹏. 附加应力法在预应力锚杆支护结构稳定性分析中的应用[J]. 工程力学, 2014, 31(4): 196-202. (WANG Deng-qun, ZHU Yan-peng.Additional stress apply to analyzing the stability of prestressed anchor support[J]. Engineering Mechanics, 2014, 31(4): 196-202. (in Chinese)
[4]	贾金青, 郑卫锋. 预应力锚杆柔性支护法的研究与应用[J]. 岩土工程学报, 2005, 27(11): 1257-1261 (JIA Jin-qing, ZHENG Wei-feng. Study and application of flexible retaining method with prestressed anchor[J]. Chinese Journal of Geotechnical Engineering, 2005, 27(11): 1257-1261. (in Chinese))
[5]	赵晓彦, 熊自英. 框架锚固类土质边坡预应力传递规律的研究[J]. 岩土力学, 2011, 32(7): 2146-2152. (ZHAO Xiao-yan, XIONG Zi-ying.Study of transferring mode of prestressed force in frame-anchored soil-like slopes[J]. Rock and Soil Mechanics, 2011, 32(7): 2146-2152. (in Chinese))
[6]	何思明, 杨雪莲, 周永江. 预应力锚索地梁与地基共同作用分析[J]. 岩土力学, 2006, 27(1): 83-88. (HE Si-ming, YANG Xue-lian, ZHOU Yong-jiang.Analysis of interaction of prestressed anchor rope foundation beam and foundation[J]. Rock and Soil Mechanics, 2006, 27(1): 83-88. (in Chinese))
[7]	朱大勇, 李焯芬, 黄茂松, 等. 对3种著名边坡稳定性计算方法的改进[J]. 岩石力学与工程学报, 2005, 24(2): 183-194. (ZHU Da-yong, LEE C F, HUANG Mao-song, et al.Modifications to three well-known methods of slope stability analysis[J]. Chinese Journal of Rock Mechanics and Engineering, 2005, 24(2): 183-194. (in Chinese))
[8]	TB10025—2006 铁路路基支挡结构设计规范[S]. 2014. (TB10025—2006 Code for design on retaining engineering structure of railway subgrade[S]. 2014. (in Chinese))
[9]	沈珠江. 理论土力学[M]. 北京: 中国水利水电出版社, 2000. (SHEN Zhu-jiang.Theory of soil mechanics[M]. Beijing: China Water Power Press, 2000. (in Chinese))
[10]	袁聚云, 钱建固, 张宏鸣, 等. 土质学与土力学[M]. 4版.北京: 人民交通出版社, 2009. (YUAN Ju-yun, QIAN Jian-gu, ZHANG Hong-ming, et. al. Soil properties and soil mechanics[M]. 4th ed. Beijing: China Communications Press, 2009. (in Chinese))
[11]	李元松. 高等岩土力学[M]. 武汉: 武汉大学出版, 2013. (LI Yuan-song.Advanced rock and soil mechanics[M]. Wuhan: Wuhan University Press, 2013. (in Chinese))
[12]	MORGENSTERN N R, PRICE V E.The analysis of the stability of general slip surfaces[J]. Géotechnique, 1965, 15(1): 79-93.
[13]	SPENCER E.A method of analysis of the stability of embankments assuming parallel interslice forces[J]. Géotechnique, 1967, 17(1): 11-26.
[14]	JANBU N.Slope stability computations[M]// Embankment Dam Engineering, Hirschfield E, ed. New York: John Wiley, 1973: 47-86.
[15]	BISHOP A W.The use of the slip circle in the stability analysis of slopes[J]. Géotechnique, 1955, 5(1): 7-17.
[16]	梁冠亭, 陈昌富, 朱剑锋, 等. 基于M-P法的抗滑桩支护边坡稳定性分析[J]. 岩土力学, 2015, 36(2): 451-456. (LIANG Guan-ting, CHEN Chang-fu, ZHU Jian-feng, et al.Stability analysis of pile stabilized slope based on Morgenstern-Price method[J]. Rock and Soil Mechanics, 2015, 36(2): 451-456. (in Chinese))
[17]	欧源. 预应力锚索地梁下坡体压力的研究[D]. 成都: 西南交通大学, 2009. (OU Yuan.Study on slope pressure on prestressed anchor-cable beam-on-foundation[D]. Chengdu: Southwest Jiaotong University, 2009. (in Chinese))
