不同填料土工织物散体桩桩体单轴压缩试验

陈建峰, 花嘉嘉, 冯守中

陈建峰, 花嘉嘉, 冯守中. 不同填料土工织物散体桩桩体单轴压缩试验[J]. 岩土工程学报, 2019, 41(1): 148-153. DOI: 10.11779/CJGE201901016
引用本文: 陈建峰, 花嘉嘉, 冯守中. 不同填料土工织物散体桩桩体单轴压缩试验[J]. 岩土工程学报, 2019, 41(1): 148-153. DOI: 10.11779/CJGE201901016
shu
CHEN Jian-feng, HUA Jia-jia, FENG Shou-zhong. Uniaxial compression tests on geosynthetic-encased stone columns with different fills[J]. Chinese Journal of Geotechnical Engineering, 2019, 41(1): 148-153. DOI: 10.11779/CJGE201901016
Citation: CHEN Jian-feng, HUA Jia-jia, FENG Shou-zhong. Uniaxial compression tests on geosynthetic-encased stone columns with different fills[J]. Chinese Journal of Geotechnical Engineering, 2019, 41(1): 148-153. DOI: 10.11779/CJGE201901016
shu

不同填料土工织物散体桩桩体单轴压缩试验  English Version

  • 1.同济大学地下建筑与工程系,上海 200092;
    2.武汉广益交通科技股份有限公司,湖北 武汉 430074

基金项目: 国家自然科学基金项目（41572266,41772289）
详细信息
    作者简介:

    陈建峰(1972- ),男,浙江余姚人,工学博士,教授,主要从事加筋土结构与边坡支护、岩体力学与工程等方面的教学与研究工作。E-mail: jf_chen@tongji.edu.cn。

  • 中图分类号: TU470

Uniaxial compression tests on geosynthetic-encased stone columns with different fills

  • 1.Department of Geotechnical Engineering, School of Civil Engineering, Tongji University, Shanghai 200092, China;
    2.Wuhan Guangyi Transportation Science and Technology Co., Ltd., Wuhan 430074, China

摘要

    摘要
  • 摘要: 选用碎石、圆砾和砂3种填料,以及5种不同强度的聚丙烯土工编织布套筒,制备成15组尺寸为ϕ300 mm×600 mm,填料压实度λ=0.9的土工织物散体桩,对桩体进行单轴压缩试验,以研究不同填料土工织物散体桩在轴向荷载作用下的强度特性。研究结果表明：不同填料桩体在单轴压缩下具有不同的破坏模式,碎石填料局部刺破编织布套筒形成较大破口,圆砾填料致套筒横向筋丝断裂、纵向筋丝分离,而砂填料致套筒横向筋丝断裂较均匀且无明显破口。桩体强度与筋材和填料强度均呈正相关关系,3种填料桩体轴向应力-应变曲线在加载初期因填料受到初始压密而略有上凹,而后近似线性增长至桩体强度,峰值强度后呈现应变软化现象;综合本文试验数据及前期所做的单轴、三轴压缩试验数据,修正了桩体强度理论计算公式,得到的桩体强度修正值与试验值吻合较好。
    Abstract: 15 samples of geosynthetic-encased stone columns (GESCs) with a dimension of ϕ300 mm×600 mm and degree of compaction of 0.9 are made using three types of fills of crushed stone, pebble and sand and five different strength woven sleeves made of polypropylene geotextiles. The uniaxial compression tests are performed on the samples to investigate the characteristics of strength of GESCs. The results show that different failure modes happen to the GESC body with different fills under uniaxial compression. The crushed stone can partly puncture the woven sleeves to produce obvious holes and pebble is extruded to break the transverse polypropylene slices, while the longitudinal slices are separated. The sand evenly breaks the transverse slices with no obvious holes on sleeves. The strength of the GESC body has a positive relationship with the strength of the sleeves and the fills. The stress-strain curve of GESC body at preliminary loading stage is mildly concave down due to the initial densification, then increases linearly up to the peak stress, and subsequently decreases, showing strain-softening characteristics. Based on the present data and those of uniaxial and triaxial compression tests carried out by the authors before, the theoretical formula for the strength of the GESC body is amended, and the results of the modified formulas are proved to be in good agreement with the experimental ones.
    • HTML全文
    • 参考文献(16)
  • [1] RAITHEL M, KÜSTER V, LINDMARK A. Geotextile encased columns-a foundation system for earth structures, illustrated by a dyke project for a works extension in Hamburg[C]// Nordic Geotechnical Meeting. Linköping, 2004: 1-10.
    [2] MURUGESAN S, RAJAGOPAL K.Studies on the behavior of single and group of geosynthetic encased stone columns[J]. Journal of Geotechnical and Geoenvironmental Engineering, 2009, 136(1): 129-139.
    [3] GNIEL J, BOUAZZA A.Construction of geogrid encased stone columns: a new proposal based on laboratory testing[J]. Geotextiles and Geomembranes, 2010, 28(1): 108-118.
    [4] 赵明华, 顾美湘, 张玲, 等. 竖向土工加筋体对碎石桩承载变形影响的模型试验研究[J]. 岩土工程学报, 2014, 36(9): 1587-1593.
    ((ZHAO Ming-hua, GU Mei-xiang, ZHANG Ling, et al.Model tests on influence of vertical geosynthetic-encasement on performance of stone columns[J]. Chinese Journal of Geotechnical Engineering, 2014, 36(9): 1587-1593. (in Chinese))
    [5] 陈建峰, 王波, 魏静, 等. 加筋碎石桩复合地基路堤模型试验[J]. 中国公路学报, 2015, 28(9): 1-8.
    (CHEN Jian-feng, WANG Bo, WEI Jing, et al.Model tests of embankments on soft foundation reinforced with geosynthetic-encased stone columns[J]. China Journal of Highway and Transport, 2015, 28(9): 1-8. (in Chinese))
    [6] RAITHEL M, KIRCHNER A, SCHADE C, et al.Foundation of constructions on very soft soils with geotextile encased columns-state of the art[C]// Proceedings of GeoFrontiers. Reston, 2005: 1-11.
    [7] LEE D Y, YOO C, PARK S, et al.Field load tests of geogrid encased stone columns in soft ground[C]// Proceedings of the Eighteenth International Offshore and Polar Engineering Conference. Vancouver, 2008: 521-524.
    [8] GNIEL J, BOUAZZA A.Improvement of soft soils using geogrid encased stone columns[J]. Geotextiles and Geomembranes, 2009, 27(3): 167-175.
    [9] ARAUJO G L S, PALMEIRA E M, CUNHA R P. Behaviour of geosynthetic-encased granular columns in porous collapsible soil[J]. Geosynthetics International, 2009, 16(6): 433-451.
    [10] CHEN J F, LI L Y, XUE J F, et al.Failure mechanism of geosynthetic-encased stone columns in soft soils under embankment[J]. Geotextiles and Geomembranes, 2015, 43(5): 424-431.
    [11] WU C S, HONG Y S.A simplified approach for evaluating the bearing performance of encased granular columns[J]. Geotextiles and Geomembranes, 2014, 42(4): 339-347.
    [12] GNIEL J, BOUAZZA A.Construction of geogrid encased stone columns: a new proposal based on laboratory testing[J]. Geotextiles and Geomembranes, 2010, 28(1): 108-118.
    [13] MIRANDA M, COSTA A D.Laboratory analysis of encased stone columns[J]. Geotextiles and Geomembranes, 2016, 44(3): 269-277.
    [14] 陈建峰, 曾岳, 冯守中, 等. 土工织物散体桩单轴压缩试验研究[J]. 中国公路学报, 2018, 31(6): 181-187.
    (CHEN Jian-feng, ZENG Yue, FENG Shou-zhong, et al.Uniaxial compression test of geosynthetic-encased stone columns[J]. China Journal of Highway and Transport, 2018, 31(6): 181-187. (in Chinese))
    [15] 陈建峰, 王兴涛, 曾岳, 等. 土工织物散体桩桩体大三轴试验研究[J]. 岩土工程学报, 2017, 39(12): 2212-2118.
    (CHEN Jian-feng, WANG Xing-tao, ZENG Yue, et al.Study on large triaxial compression tests of geosynthetic-encased stone column body[J]. Chinese Journal of Geotechnical Engineering, 2017, 39(12): 2212-2118. (in Chinese))
    [16] BATHURST R J, ALLEN T M, WALTERS D L.Reinforcement loads in geosynthetic walls and the case for a new working stress design method[J]. Geotextiles and Geomembranes, 2005, 23(4): 287-322.
    • 相关文章
    • 施引文献(8)

  • 期刊类型引用(4)

    1. 勒治华，于庆磊，蒲江涌. 充填散体材料侧限压缩试验径径比的确定方法. 中南大学学报(自然科学版). 2023(03): 1054-1061 . 百度学术
    2. 宋飞，朱婕，付娆. 考虑蠕变变形的格室加筋土力学性质研究. 地下空间与工程学报. 2023(S1): 165-173 . 百度学术
    3. 付娆，宋飞. 格室加筋土等效强度计算方法对比研究. 地基处理. 2021(03): 188-194 . 百度学术
    4. 朱家宏. 勘察土工试验数据科学性及准确性的提升策略分析——以岩土工程为例. 冶金管理. 2021(17): 126-127 . 百度学术

    其他类型引用(4)

    • 资源附件(0)
计量
  • 文章访问数:  264
  • HTML全文浏览量:  7
  • PDF下载量:  125
  • 被引次数: 8
出版历程
  • 收稿日期:  2017-12-31
  • 发布日期:  2019-01-24
