Application of braced retaining structures with double-row diaphragm walls in channel expansion project of Qingyuan junction
-
摘要: 正在紧张施工的广东省清远枢纽航道扩容之二线船闸的深基坑工程紧邻一线船闸,覆盖层深厚,地层性质较差,地质条件复杂,坑外设计洪水位较高。考虑到基坑开挖过程中已建船闸和基坑的相互作用,为满足支护结构自身强度及变形要求,避免由于基坑开挖过程中土体卸荷造成邻近已建船闸产生过大变形从而对船闸安全稳定和正常运行带来安全隐患,二线船闸的闸室部分的基坑支护结构采用带撑双排地下连续墙方案。以带撑双排地下连续墙为研究重点,利用迈达斯GTS有限元软件,基于硬化土（HS）土体本构模型,模拟清远二线船闸深基坑施工过程。有限元结果表明,双排地下连续墙支护结构和邻近船闸闸室的水平位移特征与工程实测结果基本吻合,带撑双排地下连续墙支护方案对于二线船闸深基坑工程是可行的。Abstract: The deep foundation pit of the second-line ship lock in the channel expansion project of Qingyuan junction in Guangdong Province is under construction. It is close to the first-line ship lock, with deep overburden, poor formation property, complicated geological condition and high flood level. Considering the interaction between the ship lock and the foundation pit in the excavation process of the foundation pit, the braced retaining structures with double-row diaphragm walls are adopted as those of the foundation pit of the lock chamber part of the second-line ship lock. It is designed to meet the requirements of the strength and deformation of the retaining structures and to avoid the excessive deformation of the adjacent built ship lock, which will bring security risks to the stability and normal operation of the ship lock due to unloading during the excavation of the foundation pit. For the braced retaining structures with double-row diaphragm walls, based on the hardening soil constitutive model, the construction process of the deep foundation pit of the second-line ship lock of Qingyuan junction is simulated by means of the Midas GTS finite element software. The results show that the characteristics of horizontal displacement of the double-row diaphragm walls and the lock chamber of the adjacent ship lock in the excavation of the foundation pit are basically in accordance with the measured results. The scheme of the braced retaining structures with double-row diaphragm walls is feasible in the deep excavation project of the second-line ship lock.
-
Keywords:
- ship lock /
- deep foundation pit /
- retaining structure /
- diaphragm wall /
- application
-
[1] 潘宣何. 采用排桩支护结构的基坑开挖对邻近船闸的影响研究[D]. 长沙: 长沙理工大学, 2010.
(PAN Xuan-he.The impact analysis of a nearby navigation lock by soldier-piles supporting structure foundationpitexcavation[D]. Changsha: Changsha University of Science ＆ Technology, 2010. (in Chinese))[2] 凌威. 嵌岩双排支护桩在邻近船闸深基坑工程中的应用研究及数值分析[D]. 长沙: 长沙理工大学, 2013.
(LING Wei.Application research and bumerical analysis of rock-socketed double-row retaining pile in deep foundation pit of neighboring lock[D]. Changsha: Changsha University of Science ＆ Technology, 2013. (in Chinese))[3] 扈世龙. 坡桩支护基坑开挖对邻近船闸的影响研究[D].长沙: 长沙理工大学, 2015.
(HU Shi-long.The research on impact foundation pit excavation of neighboring lock with support of slopes and row-piles[D]. Changsha: Changsha University of Science ＆ Technology, 2015. (in Chinese))[4] 罗鹏飞, 刘晓平, 曹周红, 等. 邻近船闸基坑开挖安全影响因素[J]. 水运工程, 2016, 14(4): 113-117.
(LUO Peng-fei, LIU Xiao-ping, CAO Zhou-hong, et al.Influential factors on safe excavation of foundation pit near lock[J]. Port & Waterway Engineering, 2016, 14(4): 113-117. (in Chinese))[5] FINNO R J, BLACKBUM J T, ROBOSKI J F.Three-dimensional effects for supported excavations in clay[J]. Journal of Geotechnical &Geoenvironmental Engineering, 2007, 133(1): 30-36. [6] SCHANZ T, VERMEER P A, BONNIER P G.Beyond 2000 in computational geotechnics, chapter formulation and verification of the hardening-soil model[M]. Rotterdam: Balkema, 1999: 281-297. [7] 宋广, 宋二祥. 基坑开挖数值模拟中土体本构模型的选取[J]. 工程力学, 2014, 31(5): 86-94.
(SONG Guang, SONG Er-xiang.Selection of soil constitutive models for numerical simulation of foundation pit excavation[J]. Engineering Mechanics, 2014, 31(5): 86-94. (in Chinese))[8] 谢建斌, 曾宪明, 胡井友, 等. 硬化土模型在桩锚与桩撑组合支护深基坑工程中的应用[J]. 岩土工程学报, 2014, 36(增刊2): 56-63.
(XIE Jian-bin, ZENG Xian-ming, HU Jing-you, et al.Application of hardening soil model in deep excavations supported by pile-anchor and pile-braced composite supporting structures[J]. Chinese Journal of Geotechnical Engineering, 2014, 36(S2): 56-63. (in Chinese))[9] 黄忠铭. 基坑双排桩计算模型的探讨[D]. 广州: 华南理工大学, 2016.
(HUANG Zhong-ming.Discussion on calculation model of double-row piles[D]. Guangzhou: South China University of Technology, 2016. (in Chinese)) -
