软黏土中导管架基础水平循环加载离心模型试验

朱姝; 陈仁朋

doi:10.11779/CJGE2018S2041

软黏土中导管架基础水平循环加载离心模型试验 English Version

朱姝,
陈仁朋

湖南大学土木工程学院,湖南长沙 410082

基金项目: 国家重点研发计划项目（2016YFC0800207）; 湖南省重点

详细信息

作者简介:
朱姝(1992- ),女,江苏淮安人,博士研究生,主要从事海洋岩土工程方向的研究工作。E-mail: zhushu@hnu.edu.cn。

中图分类号: TU47
计量
- 文章访问数: 279
- HTML全文浏览量: 2
- PDF下载量: 129
出版历程
- 收稿日期: 2018-07-21
- 发布日期: 2018-10-29

Centrifuge modelling of jacket foundation subjected to cyclic lateral loading in soft clay

Institute of Geotechnical Engineering, Hunan University, Changsha 410082, China

摘要

摘要: 为研究海上风机四腿导管架基础在风、浪等水平循环荷载作用下的受力及变形特性,开展了近海饱和软黏土地基四腿导管架基础水平循环加载离心模型试验。实测获得了水平循环荷载下导管架顶部的位移、基桩顶部的水平位移以及桩身弯矩,并利用实测桩身弯矩推导出桩身变形与桩周土反力。试验结果表明：水平循环荷载作用下导管架顶部的荷载-位移曲线表现出明显的非线性;后排桩的水平位移约为前排桩的80%,且均小于导管架顶部的水平位移,导管架发生了一定角度的倾斜;桩身最大弯矩值出现在泥面下约6D深度处。在此基础上,采用双曲正切型p-y曲线方法拟合试验结果并与API规范作对比,发现API规范p-y曲线的初始刚度和极限土反力均偏小。试验进一步揭示了泥面下5D深度范围内需考虑桩周土反力的弱化现象,且前排桩周土反力的弱化程度明显大于后排桩,在工程设计时应分开考虑下基桩桩周土的强度弱化情况。
- 导管架基础 /
- 离心模型试验 /
- 水平受荷 /
- 循环弱化 /
- 软黏土
Abstract: The centrifugal model tests are carried out on a jacket foundation subjected to cyclic lateral loading in saturated soft clay to investigate the force and deformation characteristics of the jacket foundation under cyclic lateral loading from wind and wave. The forces and displacements of the jacked top, displacements of piles head and bending moments of the pile shaft are measured. Based on the measured bending moments, the lateral displacements and the soil reaction forces around piles are calculated. The test results show that under the cyclic lateral loading, the load-displacement curve of the jacket foundation head exhibits an obvious nonlinearity. The lateral deformation of the trailing-row piles is about 80% of that of the leading-row ones, while both of their deformations are less than those of the jacket top, which leads to a certain angle of inclination on the jacket foundation. The peak bending moment of piles appear around 6D below the soil surface. The hyperbolic tangent p-y curves are used to fit the test results and they are compared with the API code. It is found that the initial stiffness and ultimate shallow layer soil reaction are smaller, and the calculated results are too conservative according to the API code. Furthermore, it is revealed that the cyclic degradation of the soil reaction under soil surface within 5 times the diameter in depth should be taken into account, and the degradation of the leading-row piles is obviously larger compared with that of the trailing-row ones, which should be separately considered in engineering design.
- jacket foundation /
- centrifugal model test /
- lateral load /
- cyclic degradation /
- soft clay

HTML全文

参考文献(14)

[1]	MATLOCK H.Correlarions for design of laterally loaded piles in soft clay[C]// Proc 2nd Annu Offshore Tecnol Conf, 1970: 577-594.
[2]	REESE L C, WELCH R C.Lateral loading of deep foundation in stiff clay[J]. Journal of Geotechnical Engineering Division, American Society of Civil Engineers, 1975, 101(6): 633-649.
[3]	RAJASHREE S S, SUNDARAVADIVELU R, Degradation model for one-way cyclic lateral load on piles in soft clay[J]. Computers and Geotechnics, 1996, 19(4): 289-300.
[4]	POULOS H G.Single pile response to cyclic lateral load[J]. Journal of the Geotechnical Engineering Division, ASCE, 1982, 108(3): 355-375.
[5]	李光銮, 李成军. 饱和黏土中导管架平台单桩水平承载力分析[J]. 石油机械, 2012, 40(10): 63-66. (LI Guang-luan, LI Cheng-jun.Analysis of the horizontal bearing capacity of the jacket platform single pile in saturated clay[J]. China Petroleum Machinery, 2012, 40(10): 63-66. (in Chinese))
[6]	袁志林, 段梦兰, 陈祥余, 等. 水平荷载下导管架平台桩基础的非线性有限元分析[J]. 岩土力学, 2012, 33(8): 2551-2560. (YUAN Zhi-lin, DUAn Meng-lan, CHEN Xiang-yu, et al.Nonlinear finite element analysis of jacket platform pile foundations under lateral loads[J]. Rock and Soil Mechanics, 2012, 33(8): 2551-2560. (in Chinese))
[7]	闫晋辉. 倾斜载荷作用下导管架平台桩基承载力分析[D].上海: 上海交通大学, 2012. (YAN Jin-hui.The bearing capacity analysis of pile foundation of jacket platform under inclined load[D]. Shanghai: Shanghai Jiao Tong University, 2012. (in Chinese))
[8]	张忠苗. 桩基工程[M]. 北京: 中国建筑工业出版社, 2007. (ZHANG Zhong-miao.Pile foundation engineering[M]. Beijing: China Architecture and Building Press, 2007. (in Chinese))
[9]	朱斌, 李涛. 海上四桩导管架基础水平受荷离心模型试验[J]. 岩土工程学报, 2014, 36(10): 1822-1830. (ZHU Bin, LI Tao.Centrifuge modelling on tetrapod jacket foundation subjected to lateral loads[J]. Chinese Journal of Geotechnical Engineering, 2014, 36(10): 1822-1830. (in Chinese))
[10]	American Petroleum Institute.Recommended practice for planning, designing and constructing fixed offshore platforms[M]. Washington D C: [s. n.], 1987.
[11]	JEANJEAN P.Re-assessment of p-y Curve for soft clay from centrifuge testing and finite element modeling[C]// Offshore Technology Conference. Houston, 2009.
[12]	李涛. 近海风机导管架基础水平受荷特性研究[D]. 杭州: 浙江大学, 2015. (LI Tao.Properties of lateral loads on jacket platform foundation of offshore wind turbines[D]. Hangzhou: Zhejinag University, 2015. (in Chinese))
[13]	NICHOLS N W, ROHANI M J.Effect of lateral soil strength and stiffness on jacket foundation integrity and design for south china sea sites[J]. Offshore Technology Conference Asia, Kuala Lumpur City, 2014.
[14]	俞剑, 黄茂松, 张陈荣. 黏土中两种不同直径单桩水平循环加载模型试验与分析[J]. 岩土力学, 2016, 37(4): 973-980. (YU Jian, HUANG Mao-song, ZHANG Chen-rong.Model tests and analysis of single piles with two different diameters subjected to cyclic lateral loadings in clay[J]. Rock and Soil Mechanics, 2016, 37(4): 973-980. (in Chinese))
