冠梁标高对基坑周边环境的影响分析

王正振; 龚维明; 戴国亮; 周勇; 徐峰

doi:10.11779/CJGE2018S1033

冠梁标高对基坑周边环境的影响分析 English Version

王正振^{1, 2},
龚维明^{1, 2},
戴国亮^{1, 2},
周勇^{3, 4},
徐峰^{1, 2}

1. 东南大学混凝土及预应力混凝土结构教育部重点实验室,江苏南京 210096;
2.东南大学土木工程学院,江苏南京 210096;
3. 兰州理工大学甘肃省土木工程防灾减灾重点实验室,甘肃兰州 730050;
4. 兰州理工大学西部土木工程防灾减灾教育部工程研究中心,甘肃兰州 730050

基金项目: “十二五”交通运输重大科技专项项目（2011318494160）; 2016年度省建设系统科技项目（计划项目）（2016JH05）; 江苏省研究生科研与实践创新计划项目（KYCX17_0117）; 中央高校基本科研业务费专项资金项目

详细信息

作者简介:
王正振(1989- ),男,博士研究生,主要从事沉井、桩基础、深基坑等岩土工程研究工作。E-mail：230159416@seu.edu.cn。

中图分类号: TU47
计量
- 文章访问数: 367
- HTML全文浏览量: 2
- PDF下载量: 399
出版历程
- 收稿日期: 2017-06-10
- 发布日期: 2018-08-24

Influence analysis of top beam elevation on surroundings around deep pits

WANG Zheng-zhen^{1, 2},
GONG Wei-ming^{1, 2},
DAI Guo-liang^{1, 2},
ZHOU Yong^{3, 4},
XU Feng^{1, 2}

1. Key Laboratory of Concrete and Prestressed Concrete Structure of Ministry of Education, Southeast University, Nanjing 210096, China;
2. Department of Civil Engineering, Southeast University, Nanjing 210096, China;
3. Key Laboratory of Disaster Prevention and Mitigation in Civil Engineering of Gansu Province, Lanzhou University of Technology, Lanzhou 730050, China;
4. Western Engineering Research Center of Disaster Mitigation in Civil Engineering of Ministry of Education, Lanzhou University of Technology, Lanzhou 730050, China

摘要

摘要: 降低冠梁顶标高以减少基坑工程造价是目前比较盛行的一种做法,但其往往导致基坑周边环境变形过大。以某建筑深基坑工程为例,通过对比该基坑开挖期间周围道路沉降、管线沉降、建筑物沉降、桩顶变形和支撑轴力的实测数据来分析支护结构安全有效、建筑物沉降满足要求,但地表沉降过大现象的原因,认为冠梁标高降低会对基坑顶部土体变形产生较大影响。通过有限元模拟对降低冠梁顶标高对基坑坡顶土体变形的影响进行深入分析。结果表明：坑顶土体变形过大并不意味着支护结构失效;冠梁顶标高降低后,由于坡顶土体失去侧向约束,在坡顶竖向荷载作用下,会产生较大的沉降和水平变形;土体沉降与水平变形具有相关性,但冠梁顶标高对坡顶土体水平变形的影响程度远远超过其对沉降的影响。建议当基坑周围有道路或管线存在时,谨慎降低冠梁标高,如必须降低,应采取其他有效措施约束土体的变形。
- 基坑监测 /
- 冠梁标高 /
- 变形 /
- 影响分析 /
- 数值模拟
Abstract: Decreasing the top beam elevation to reduce the project cost, which often leads to larger displacement of the surroundings, is very popular in the design of foundation pits. Based on a deep foundation pit project, the phenomenon that the supporting structure is effective, the settlement of buildings meets the design requirements, while the ground settlement is out of control is analyzed by comparing the measured data of the strut forces, displacements of the surroundings and displacements of retaining pile tops. The decrease of top beam elevation is supposed to be a main influence factor for the larger ground settlement. Finally, the finite element simulation method is used to analyze the influence of top beam elevation on the surroundings deeply. The results show that whether the supporting structure is effective or not should not be judged by the displacement of soil at top of the foundation pit. Under the vertical load, large displacement will take place for the soil at top of the foundation pit because of the loss in the lateral restraint caused by the decreasing of top beam elevation. There exists a relationship between the settlement and the horizontal displacement of soil, but the decreasing of top beam elevation has a larger impact on the horizontal displacement than on the settlement. The top beam elevation should not be decreased when roads, pipelines and structures are near to the deep pit, and the effective measures must be taken to restrain the displacement of soil when the top beam elevation is decreased.
- monitoring of deep pit /
- top beam elevation /
- displacement /
- influence analysis /
- numerical simulation

HTML全文

参考文献(16)

[1]	俞建霖, 龚晓南. 基坑工程变形性状研究[J]. 土木工程学报, 2002, 35(4): 86-90. (YU Jian-lin, GONG Xiao-nan.Research on deformation of foundation pit engineering[J]. China Civil Engineering Journal, 2002, 35(4): 86-90. (in Chinese))
[2]	OU Chang-yu.Deep excavation: theory and practice[M]. London: Taylor and Francis, 2006.
[3]	刘国彬, 黄院雄, 侯学渊. 基坑工程下已运行地铁区间隧道上抬变形的控制研究与实践[J]. 岩石力学与工程学报, 2001, 20(2): 202-207. LIU Guo-bin, HUANG Yuan-xiong, HOU Xue-yuan. The prediction and control of rebound deformation of the existed tunnels right under excavation[J]. Chinese Journal of Rock Mechanics and Engineering, 2001, 20(2): 202-207.
[4]	俞缙, 许琼鹤, 邢崴崴, 等. 基坑工程下地铁隧道隆起位移数值模拟分析[J]. 岩土力学, 2007, 28(增刊): 653-657. (YU Jin, XU Qiong-he, XING Wei-wei, et al.Numerical analysis of upwarping deformation of existing tunnels under a new tunnel's excavation[J]. Rock and Soil Mechanics, 2007, 28(S0): 653-657. (in Chinese))
[5]	陈泽昌. 成都地铁2号线站东广场站基坑监测及位移反分析[D]. 成都: 西南交通大学, 2011. (CHEN Ze-chang.Monitoring and Back Analysis on Displacement of the Foundation Pit of Zhandong Guangchang Station in Line 2 of Chengdu Metro[D]. Chengdu: Southwest Jiaotong University, 2011. (in Chinese))
[6]	安关峰, 宋二祥. 广州地铁琶州塔站工程基坑监测分析[Jl. 岩土工程学报, 2005, 26(3): 333-337. (AN Guan-feng, SONG Er-xiang.The analysis of excavation monitoring for the Pazhouta subway station in Guangzhou[J]. Chinese Journal of Geotechnical Engineering, 2005, 26(3): 333-337. (in Chinese))
[7]	李磊, 段宝福. 地铁车站深基坑工程的监控量测与数值模拟[J]. 岩石力学与工程学报, 2013, 32(增刊1): 2684-2691. (LI Lei, DUAN Bao-fu.Monitoring measurement and numerical simulation for deep foundation pit of subway station[J]. Chinese Journal of Rock Mechanics and Engineering, 2013, 32(S1): 2684-2691. (in Chinese))
[8]	王旭军. 上海中心大厦裙房深大基坑变形特性及盆式开挖技术研究[D]. 上海: 同济大学, 2014. (WANG Xu-jun.Deformation Characteristics of Shanghai Tow Podium Pit and Analysis of Basin Excavation Technique[D]. Shanghai: Tongji University, 2014. (in Chinese))
[9]	MOORMANN C.Analysis of wall and ground movements due to deep excavations in soft soil based on a new worldwide database[J]. Soils and Foundations, 2004, 44(1): 87-98.
[10]	赖冠宙, 房营光, 史宏彦. 深基坑排桩支护结构空间共同变形分析[J]. 岩土力学, 2007, 28(8): 1749-1752. (LAI Guan-zhou, FANG Ying-guang, SHI Hong-yan.Spatial mutual deformation analysis method for row of piles of deep excavation[J]. Rock and Soil Mechanics, 2007, 28(8): 1749-1752. (in Chinese))
[11]	LEUNG E H Y, NG C W W. Wall and ground movements associated with deep excavations supported by cast in situ wall in mixed ground conditions[J]. Journal of Geotechnical & Geoenvironmental Engineering, 2007, 133(2): 129-143.
[12]	秦昊. 地铁车站基坑开挖对邻近地下管线的影响研究[D]. 北京: 中国地质大学(北京), 2010. (QIN Hao.Study on effect of underground pipelines due to metro station foundation pit excavation[D]. Beijing: China University of Geosciences, 2010. (in Chinese))
[13]	WANG J H, XU Z H, WANG W D.Wall and ground movements due to deep excavations in Shanghai soft soils[J]. Journal of Geotechnical & Geoenvironmental Engineering, 2010, 136(7): 985-994.
[14]	HSIEH P G, OU C Y.Shape of ground surface settlement profiles caused by excavation[J]. Canadian Geotechnical Journal, 2011, 35(6): 1004-1017.
[15]	张小伟, 姚笑青. 基坑工程变形的渗流应力耦合有限元分析[J]. 地下空间与工程学报, 2012, 8(2): 339-44. (ZHANG Xiao-wei, YAO Xiao-qing.The seepage-stress coupled finite element analysis of foundation pit deformation[J]. Chinese Journal of Underground Space and Engineering, 2012, 8(2): 339-44. (in Chinese))
[16]	木林隆, 黄茂松. 基坑开挖引起的周边土体三维位移场的简化分析[J]. 岩土工程学报, 2013, 35(5): 820-827. (MU Lin-long, HUANG Mao-song, Simplified method for analysis of soil movement induced by excavations[J]. Chinese Journal of Geotechnical Engineering, 2013, 35(5): 820-827. (in Chinese))
