改进的膨胀土侧限膨胀试验研究

张锐, 张博亚, 郑健龙, 刘正楠

张锐, 张博亚, 郑健龙, 刘正楠. 改进的膨胀土侧限膨胀试验研究[J]. 岩土工程学报, 2018, 40(12): 2223-2230. DOI: 10.11779/CJGE201812009
引用本文: 张锐, 张博亚, 郑健龙, 刘正楠. 改进的膨胀土侧限膨胀试验研究[J]. 岩土工程学报, 2018, 40(12): 2223-2230. DOI: 10.11779/CJGE201812009
shu
ZHANG Rui, ZHANG Bo-ya, ZHENG Jian-long, LIU Zheng-nan. Modified lateral confined swelling tests on expansive soils[J]. Chinese Journal of Geotechnical Engineering, 2018, 40(12): 2223-2230. DOI: 10.11779/CJGE201812009
Citation: ZHANG Rui, ZHANG Bo-ya, ZHENG Jian-long, LIU Zheng-nan. Modified lateral confined swelling tests on expansive soils[J]. Chinese Journal of Geotechnical Engineering, 2018, 40(12): 2223-2230. DOI: 10.11779/CJGE201812009
shu

改进的膨胀土侧限膨胀试验研究  English Version

  • 1. 长沙理工大学公路养护技术国家工程实验室,湖南 长沙 410114;
    2. 长沙理工大学交通运输工程学院,湖南 长沙 410114

基金项目: 国家自然科学基金项目（51108049,51608053）; 国家重点研发计划项目（2017YFC0805300）; 交通运输部公路工程行业标准制修订项目（JTG-201507）
详细信息
    作者简介:

    张 锐(1980- ),男,副教授,博士,主要从事特殊土及其路基工程问题的研究工作。E-mail: zr@csust.edu.cn。

  • 中图分类号: TU43

Modified lateral confined swelling tests on expansive soils

  • 1. National Engineering Laboratory for Highway Maintenance Technology, Changsha University of Science & Technology, Changsha 410114, China;
    2. School of Traffic and Transport Engineering, Changsha University of Science & Technology, Changsha 410114, China;

摘要

    摘要
  • 摘要: 为量测膨胀土在侧限浸水和不同上覆荷载下的竖向膨胀率和侧向膨胀力,通过改进常规侧限膨胀试验装置和方法,确保了施加上覆荷载后试样浸水前初始湿密状态不变,消除了制样产生的初始水平应力,并将侧向膨胀力从总的侧向力中区分出来。采用改进的试验装置和方法,以特定初始湿密状态下的广西百色中等膨胀土为研究对象,分别进行了常规侧限膨胀试验和改进的侧限膨胀平行性试验。试验结果表明：常规侧限膨胀试验中的上覆荷载会改变试样初始湿密状态,测得的竖向膨胀率偏小7%~95%;因制样产生的初始水平应力会使最终侧压力偏小16.1%~43.5%;分级加载和逐级卸载的改进侧限膨胀试验结果具有良好的一致性和可重复性;竖向膨胀率随着上覆荷载逐渐减小,引入相对膨胀率和相对压力,可建立反映极限膨胀状态的幂函数拟合公式;侧向膨胀力与上覆荷载相关并随之增大而逐渐增大,当上覆荷载增至竖向膨胀力时侧向膨胀力达到最大,两者之间可用双曲线较好拟合。研究成果可为膨胀模型的建立以及膨胀土地区支挡结构物设计计算提供参考。
    Abstract: In order to measure the vertical swelling ratio and lateral swelling pressure under different vertical loading and confined conditions during soaking, the conventional confined swelling test apparatus and method are modified to ensure the consistency of the initial water content and the dry density of specimens before soaking and loading, getting rid of the initial horizontal stress caused by specimen preparation and distinguishing the lateral swelling pressure from the total lateral pressure. Using the modified apparatus and method, the conventional and modified confined swelling parallel tests are respectively carried out on the expansive soils with medium swelling potential from Baise County in Guangxi Province with specific water content and dry density. The test results show that the initial water content and dry density will change due to vertical loading during conventional tests, resulting in underestimating vertical swelling ratio measured by 7% to 95%, and that the existence of the initial horizontal stress produced by specimen preparation will underestimate the lateral pressure measured by 16.1% to 43.5%. The results of multi-stage loading and step unloading tests show the great consistency and repeatability. The vertical swelling ratio decreases with the increase of the vertical loads, and a fitting formula performing the ultimate swelling state based on power function is set up by relative swelling ratio and relative swelling pressure. While the lateral swelling pressure increases with the increase of the vertical loads, reaching its maximum value with the increasing vertical loads to the vertical swelling pressure, a hyperbolic function can fit well between the upper loads and the lateral swelling pressures. The achievements may provide references for establishing a swelling model and designing retaining structures in expansive soil areas.
    • HTML全文
    • 参考文献(19)
  • [1] 郑健龙. 公路膨胀土工程理论与技术[M]. 北京: 人民交通出版社, 2013.
    (ZHENG Jian-long.The theory and technology for highway expansive soil engineering[M]. Beijing: Renmin Communication Press, 2013. (in Chinese))
    [2] 郑健龙, 张锐. 公路膨胀土路基变形预测与控制方法[J]. 中国公路学报, 2015, 28(3): 1-10.
    (ZHENG Jian-long, ZHANG Rui.Prediction and control method for deformation of highway expansive soil subgrade[J]. China Journal of Highway and Transport, 2015, 28(3): 1-10. (in Chinese))
    [3] LIU Y L, VANAPALLI S K.Influence of lateral swelling pressure on the geotechnical infrastructure in expansive soils[J]. Journal of Geotechnical & Geoenvironmental Engineering, 2017, 143(6): 1-19.
    [4] 杨和平, 张锐, 郑健龙. 有荷条件下膨胀土的干湿循环胀缩变形及强度变化规律[J]. 岩土工程学报, 2006, 28(11): 1936-1941.
    (YANG He-ping, ZHANG Rui, ZHENG Jian-long.Variation of deformation and strength of expansive soil during cyclic wetting and drying under loading condition[J]. Chinese Journal of Geotechnical Engineering, 2006, 28(11): 1936-1941. (in Chinese))
    [5] ROSENBALM D, ZAPATA C E.Effect of wetting and drying cycles on the behavior of compacted expansive soils[J]. Journal of Materials in Civil Engineering, 2016: 04016191.
    [6] YUAN S, LIU X, SLOAN S W, et al.Multi-scale characterization of swelling behaviour of compacted Maryland clay[J]. Acta Geotechnica, 2016, 11(4): 789-804.
    [7] 张福海, 王保田, 刘汉龙. 压实膨胀土路基的膨胀变形规律研究[J]. 岩土力学, 2010, 31(1): 206-210.
    (ZHANG Fu-hai, WANG Bao-tian, LIU Han-long, et al.Research on deformation disciplines of compacted expansive soils[J]. Rock and Soli Mechanics, 2010, 31(1): 206-210. (in Chinese))
    [8] 章为民, 王年香, 顾行文, 等. 膨胀土的膨胀模型[J]. 水利水运工程学报, 2010(1): 69-72.
    (ZHANG Wei-min, WANG Nian-xiang, GU Xing-wen, et al.An expansive model for expansive soil[J]. Hydro-Science and Engineering, 2010(1): 69-72. (in Chinese))
    [9] PUPPALA A J, PEDARLA A, PINO A, et al.Diffused double-layer swell prediction model to better characterize natural expansive clays[J]. Journal of Engineering Mechanics, 2017, 143(9): 1-10.
    [10] UZUNDURUKAN S, KESKIN S N, YILDIRIM H, et al.Suction and swell characteristics of compacted clayey soils[J]. Arabian Journal for Science & Engineering, 2014, 39(2): 747-752.
    [11] AL-YAQOUB T H, PAROL J, ZNIDARCIC D. Experimental investigation of volume change behavior of swelling soil[J]. Applied Clay Science, 2017, 137: 22-29.
    [12] GB/T50279—98 岩土工程基本术语标准[S]. 1998.
    (GB/T50279—98 Standard for fundamental terms of geotechnical engineering[S]. 1998. (in Chinese))
    [13] 谢云, 陈正汉, 孙树国, 等. 重塑膨胀土的三向膨胀力试验研究[J]. 岩土力学, 2007, 28(8): 1636-1642.
    (XIE Yun, CHEN Zheng-han, Sun Shu-guo, et al.Test research on three-dimensional swelling pressure of remolded expansive clay[J]. Rock and Soil Mechanics, 2007, 28(8): 1636-1642. (in Chinese))
    [14] AVSAR E, ULUSAY R, SONMEZ H.Assessments of swelling anisotropy of Ankara clay[J]. Engineering Geology, 2009, 105(1/2): 24-31.
    [15] IKIZLER S B, VEKLI M, DOGAN E, et al.Prediction of swelling pressures of expansive soils using soft computing methods[J]. Neural Computing & Applications, 2014, 24(2): 473-485.
    [16] 杨庆, 焦建奎, 栾茂田. 膨胀岩土侧限膨胀试验新方法与膨胀本构关系[J]. 岩土工程学报, 2001, 23(1): 49-52.
    (YANG Qing, JIAO Jian-kui, LUAN Mao-tian.Study on a new method of confined swelling tests and swelling constitutive relationship for swelling rocks[J]. Chinese Journal of Geotechnical Engineering, 2001, 23(1): 49-52. (in Chinese))
    [17] 张锐, 郑健龙, 刘正楠, 等.环刀、含该环刀的土体侧向膨胀力测量装置及测量方法: 中国, ZL201710044763.X[P]. 2017.06.09.(ZHANG Rui, ZHENG Jian-long, LIU Zheng-nan, et al. A cutting ring, an apparatus and method of measuring lateral swelling stress of soil: China, ZL201710044763.X[P]. 2017.06.09. (in Chinese))
    [18] 王年香, 章为民, 顾行文, 等. 膨胀土挡墙侧向膨胀压力研究[J]. 水利学报, 2008, 39(5): 580-587.
    (WANG Nian-xiang, ZHANG Wei-min, GU Xing-wen, et al.Lateral swelling pressure of expansive soil acting on retaining wall due to inundation[J]. Journal of Hydraulic Engineering, 2008, 39(5): 580-587. (in Chinese))
    [19] 杨果林, 滕珂, 秦朝辉. 膨胀土侧向膨胀力原位试验研究[J]. 中南大学学报(自然科学版), 2014, 45(7): 2326-2332.
    (YANG Guo-lin, TENG Ke, QIN Zhao-hui.An in-situ Experimental research of lateral swelling pressure on expansive soils[J]. Journal of Central South University (Science and Technology), 2014, 45(7): 2326-2332. (in Chinese))
