土质边坡地震稳定性状态判定方法研究

张江伟; 李小军; 王晓明; 迟明杰; 王玉石

doi:10.11779/CJGE201811016

土质边坡地震稳定性状态判定方法研究 English Version

1. 河北地质大学勘查技术与工程学院,河北石家庄 050031;
2.中国地震局地球物理研究所,北京 100081

基金项目: 国家重点研发计划项目（2017YFC1500400）; 国家自然科学基金项目（51639006）; 河北省高等学校科学技术研究项目（QN2018242）

详细信息

作者简介:
张江伟(1988- ),男,博士,讲师,主要从事地震地质灾害方面的研究工作。E-mail: zjwok1988@sina.com。

中图分类号: TU443
计量
- 文章访问数: 249
- HTML全文浏览量: 14
- PDF下载量: 247
出版历程
- 收稿日期: 2018-04-16
- 发布日期: 2018-11-24

Method for judging seismic stability state of soil slopes

1. College of Prospecting Technology and Engineering, Hebei GEO University, Shijiazhuang 050031, China;
2. Institute of Geophysics, China Earthquake Administration, Beijing 100081, China

摘要

摘要: 基于有限元强度折减法,对地震作用下土质边坡稳定性状态判定方法进行了研究。探讨了地震作用下坡体内部等效塑性应变区贯通率的计算方法,并利用有限元计算和统计分析方法建立了地震作用下坡体内部等效塑性应变区贯通率与边坡动力安全系数的对应关系。根据《建筑边坡工程技术规范》（GB50330—2013）中边坡稳定性状态与边坡安全系数的对应关系,从而实现了利用坡体内部等效塑性应变区贯通率来判别边坡地震稳定性状态的方法。结果表明：当等效塑性应变区贯通率K=100% 时对应边坡稳定性状态为不稳定,当等效塑性应变区贯通率100%>K≥90% 时对应边坡稳定性状态为欠稳定,等效塑性应变区贯通率90%>K≥85% 时对应边坡稳定性状态为基本稳定,等效塑性应变区贯通率K<85% 时对应边坡稳定性状态为稳定。研究结果对于震后边坡稳定性的快速评价将具有重要的借鉴意义。
- 地震 /
- 地震响应 /
- 动力有限元 /
- 土质边坡 /
- 安全评价
Abstract: Based on the strength reduction FEM, the method for judging the stability state of soil slopes under earthquake action is analyzed. The length ratio of equivalent plastic strain zone in the slope is defined, and the corresponding relationship between the length ratio of equivalent plastic strain zone in the slope under earthquake and the safety factor is established through statistical analysis. Then, according to the corresponding relationship between the stability and safety factor of slopes in the Chinese national standard “Technical code for building slope engineering” (GB50330—2013), the method for judging the stability of the slopes under earthquake by the length ratio of equivalent plastic strain zone is realized. The results show that when the length ratio of equivalent plastic strain zone is 100%, the slope is instable; when it is between 90% and 100%, the slope is understable; when it is between 85% and 90%, the slope is basically stable; and when it is below 85%, the slope is stable. The results may have a great reference value to the rapid evaluation work of seismic hazards of slopes．
- earthquake /
- seismic response /
- dynamic FEM /
- soil slope /
- safety evaluation

HTML全文

参考文献(21)

[1]	ZIENKIEWICZ O C, HUMPHESON C, LEWIS R W.Associated and non-associated visco-plasticity and plasticity in soil mechanics[J]. Géotechnique, 1975, 25(4): 671-689.
[2]	GRIFFITHS D V, LANE P A.Slope stability analysis by finite elements[J]. Géotechnique, 1999, 49(3): 671-689.
[3]	UGAI K.A method of calculation of total factor of safety of slopes by Elasto-Plastic FEM[J]. Soils and Foundations, 1989, 29(2): 190-195.
[4]	MATSUI T, SAN K C.Finite element slope stability analysis by shear strength reduction technique[J]. Soils and Foundations, 1992, 32(1): 59-70.
[5]	DUNCAN J M.State of the art: limit equilibrium and finite-element analysis of slopes[J]. Journal of Geotechnical Engineering, ASCE, 1996, 122(7): 577-596.
[6]	DAWSON E M, ROTH W H, DRESCHER A.Slope stability analysis by strength reduction[J]. Géotechnique, 1999, 49(6): 835-840.
[7]	郑颖人, 赵尚毅. 有限元强度折减法在土坡与岩坡中的应用[J]. 岩石力学与工程学报, 2004, 23(19): 3381-3388. (ZHENG Ying-ren, ZHAO Shang-yi.Application of strength reduction FEM in soil and rock slope[J]. Chinese Journal of Rock Mechanics and Engineering, 2004, 23(19): 3381-3388. (in Chinese))
[8]	郑颖人, 赵尚毅. 岩土工程极限分析有限元法及其应用[J]. 土木工程学报, 2005, 38(1): 91-98, 104. (ZHENG Ying-ren, ZHAO Shang-yi. Limit state finite element method for geotechnical engineering analysis and its applications[J]. China Cinil Engineering Journal, 2005, 38(1): 91-98, 104. (in Chinese))
[9]	赵尚毅, 郑颖人, 时卫民, 等. 用有限元强度折减法求边坡稳定安全系数[J]. 岩土工程学报, 2002, 24(3): 343-346. (ZHAO Shang-yi, ZHENG Ying-ren, Shi Wei-min, et al.Analysis on safety factor of slop by strength reduction FEM[J]. Chinese Journal of Geotechnical Engineering, 2002, 24(3): 343-346. (in Chinese))
[10]	赵尚毅, 郑颖人, 张玉芳. 极限分析有限元法讲座Ⅱ——有限元强度折减法中边坡失稳的判据探讨[J]. 岩土力学, 2005, 26(2): 332-336. (ZHAO Shang-yi, ZHEG Ying-ren, ZHANG Yu-fang.Study on slope failure criterion in strength reduction finite element method[J]. Rock and Soil Mechanics, 2005, 26(2): 332-336.
[11]	连镇营, 韩国城, 孔宪京, 等. 强度折减有限元法研究开挖边坡的稳定性[J]. 岩土工程学报, 2001, 23(4): 407-41l. (LIAN Zhen-ying, HAN Guo-cheng, KONG Xian-jing, et al.Stablity analysis of excavation by strength reduction FEM[J]. Chinese Journal of Geotechnical Engineering, 2001, 23(4): 407-411. (in Chinese))
[12]	栾茂田, 武亚军, 年廷凯. 强度折减有限元法中边坡失稳的塑性区判据及其应用[J]. 防灾减灾工程学报, 2003, 23(3): 1-8. (LUAN Mao-tian, WU Ya-jun, NIAN Ting-kai, et al.A criterion for evaluating slope stability based on development of plastic zone by shear strength reduction FEM[J]. Journal of Disaster Prevention and Mitigation Engineering, 2003, 23(3): 1-8. (in Chinese))
[13]	陈国庆, 黄润秋, 石豫川, 等. 基于动态和整体强度折减法的边坡稳定性分析[J]. 岩石力学与工程学报, 2014, 33(2): 243-256. (CHEN Guo-qing, HUANG Run-qiu, SHI Yu-chuan, et al.Stability analysis of slope based on dynamic and whole strength reduction methods[J]. Chinese Journal of Rock Mechanics and Engineering, 2014, 33(2): 243-256. (in Chinese))
[14]	蒋水华, 李典庆, 黎学优, 等. 锦屏一级水电站左岸坝肩边坡施工期高效三维可靠度分析[J]. 岩石力学与工程学报, 2015, 34(2): 349-361. (JIANG Shui-hua, LI Dian-qing, LI Xue-you, et al.Efficient three-dimensional reliability analysis of an abutment slope at the left bank of Jinping I Hydropower Station during construction[J]. Chinese Journal of Rock Mechanics and Engineering, 2015, 34(2): 349-361. (in Chinese))
[15]	袁葳, 常晓林, 段寅, 等.考虑抗剪强度参数空间变异性的边坡稳定性分析[J]. 中南大学学报(自然科学版), 2016, 47(11): 3899-3908. (YUAN Wei, CHANG Xiao-lin, DUAN Yin, et al.Stability analysis of slope considering spatial variation of shear strength parameters[J]. Journal of Central South University (Science and Technology), 2016, 47(11): 3899-3908. (in Chinese))
[16]	史卜涛, 张云, 张巍. 边坡稳定性分析的物质点强度折减法[J]. 岩土工程学报, 2016, 38(9): 1678-1684. (SHI Bu-tao, ZHANG Yun, ZHANG Wei.Strength reduction material point method for slope stability[J]. Chinese Journal of Geotechnical Engineering, 2016, 38(9): 1678-1684. (in Chinese))
[17]	赵成刚, 白冰, 王运霞. 土力学原理[M]. 北京: 清华大学出版社, 北京交通大学出版社, 2009. (ZHAO Cheng-gang, BAI Bing, WANG Yun-Xia.Fundamentals of soil mechanics[M]. Beijing: Tsinghua University Press, Beijing Jiatong University Press, 2009. (in Chinese))
[18]	郑颖人, 赵尚毅, 张鲁渝. 用有限元强度折减法进行边坡稳定性分析[J]. 中国工程科学, 2003, 10(4): 57-61. (ZHENG Ying-ren, ZHAO Shang-yi, ZHANG Lu-yu.Slope stability analysis by strength reduction FEM[J]. Engineering Science, 2003, 10(4): 57-61. (in Chinese))
[19]	万少石, 年廷凯, 蒋景彩, 等. 边坡稳定强度折减有限元分析中的若干问题讨论[J]. 岩土力学, 2010, 31(7): 2283-2288, 2316. (WAN Shao-shi, NIAN Ting-kai, JIANG Jing-cai, et al.Discussion on several issues in slope stability analysis based on shear strength reduction finite element methods(SSR-FEM)[J]. Rock and Soil Mechanics, 2010, 31(7): 2283-2288, 2316. (in Chinese))
[20]	郑颖人, 赵尚毅, 李安洪, 等.有限元极限分析法及其在边坡中应用[M]. 北京: 人民交通出版社, 2011: 205-224. (ZHENG Ying-ren, ZHAO Shang-yi, LI An-hong, et a1. FEM limit analysis and its application in slope engineering[M]. Beijing: China Communications Press, 2011: 205-224. (in Chinese))
[21]	GB50330—2013建筑边坡工程技术规范[S]. 2013. (GB50330—2013 Technical code for building slope engineering[S]. 2013. (in Chinese))
